C50S.XXX.SD(.SE) SCANDINAVIAN OVAL AND FINNISH RETROFIT CYLINDER
USER GUIDE
Before installing
1. The instructions should be carefully followed during installation. These instructions and any
maintenance instructions should be passed on by the installer to the user.
2. iLOQ C50S cylinders must be installed and used carefully without excessive force.
3. The product should not be modified in any way except in accordance with the modifications described
in these instructions.
4. Where the C50S cylinder is manufactured in more than one size it is critical that the correct size
is selected.
5. Care should be taken to ensure that any seals or weather-stripping fitted to the complete door
assembly, does not inhibit the correct operations of C50S cylinder.
6. Care should be taken to ensure that no projection of the C50S cylinder and associated parts,
can prevent the door swinging freely.
7. All components necessary for the specific installation should be fitted in order to ensure
compliance with EN15684 standard.
8. Before fitting C50S cylinder to a fire/smoke resisting door, the fire certification should be
examined, to ensure conformity.
Care
The product is designed to be maintenance-free. It doesn't require any regular maintenance.
iLOQ Oy • Oulu, Finland • www.iLOQ.com • iLOQ is registered trademark of iLOQ Oy •
©2018 iLOQ Oy. All Rights Reserved •
Advertisement
Table of Contents
Summary of Contents for iLoq C50S SD Series
- Page 1 Care The product is designed to be maintenance-free. It doesn’t require any regular maintenance. iLOQ Oy • Oulu, Finland • www.iLOQ.com • iLOQ is registered trademark of iLOQ Oy • ©2018 iLOQ Oy. All Rights Reserved •...
- Page 2 3. Test the cylinder functionality after installation to ensure that it doesn’t prevent the lock case from working properly. iLOQ S50 lock cylinders feature an automatic reset back to a locked state. It is therefore necessary to perform the following test: •...
- Page 3 Installation with oval/finnish retrofit cylinder centering piece If the lock case requires a tail piece to be left in a horizontal position, use the iLOQ AC50.1 accessory with the cylinder. A. Remove the tail piece from the tail plug B. Connect the removed tail piece to the AC50...
- Page 4 Remove the fixing screw. The tail plug can now be adjusted. iLOQ Oy • Oulu, Finland • www.iLOQ.com • iLOQ is registered trademark of iLOQ Oy • ©2018 iLOQ Oy. All Rights Reserved •...
- Page 5 H. If the lock case still gets stuck, repeat these instructions and turn the tail plug clockwise by -22 degrees. iLOQ Oy • Oulu, Finland • www.iLOQ.com • iLOQ is registered trademark of iLOQ Oy • ©2018 iLOQ Oy. All Rights Reserved •...
- Page 6 2. Turn the lock-reader knob to unlock the door. 3. Open the door. iLOQ Oy • Oulu, Finland • www.iLOQ.com • iLOQ is registered trademark of iLOQ Oy • ©2018 iLOQ Oy. All Rights Reserved •...
