GW Instek GDS-122 Quick Start Manual

G G G G D D D D S S S S - - - - 1 1 1 1 2 2 2 2 2 2 2 2 R R R R
B B B B
ATTERY ATTERY
ATTERY ATTERY
Safety Summary Safety Summary Safety Summary Safety Summary
To avoid potential hazards, use this product only as specified.
Recharge Battery
Properly
Do not operate
without covers:
Do not operate with
suspected failures
Do not operate in
wet/damp
conditions.
Do not operate in
an explosive
atmosphere.
Keep oscilloscope
surfaces clean and
dry.
Battery Recycling Battery Recycling
Battery Recycling Battery Recycling
ECHARGEABLE ECHARGEABLE
ECHARGEABLE ECHARGEABLE
P P P P
ACK ACK
ACK ACK
Part No. 82DS-12201M0
This battery pack is for use with the GDS-122 oscilloscope.
The 7.4VDC/3500mAh battery pack consists of an array of
Lithium ion battery cells.
The GDS-122 oscilloscope is designed to work with the
rechargeable battery pack. A fully charged pack will
provide three hours of battery life. Please read the
following notes before operation.
Recharge the battery pack only from the oscilloscope at
the recommended temperature (0℃~50℃).
Do not operate this product with covers or panels
removed.
If you suspect there is damage to this oscilloscope, have it
inspected by qualified service personal.
This battery pack contains two Lithium ion (Li-ion)
batteries which must be recycled or disposed of properly at
the end of battery's life. There may be specific legal
requirements for battery collection and disposal in your
area. Contact your local electronics recycler, relevant legal
GDS-122 Rechargeable Battery Pack
