Instructions
EQUIPPED WITH A DIGILOCK
All Digital KeKabs
•
To avoid a potential lockout, remove the back plate from the lock housing, connect the batteries, and test the
digital lock BEFORE shutting the door.
• As soon as possible, reset all codes making the factory default codes inoperable.
•
Keep these instructions and all codes in a safe, retrievable place for future reference.
•
Keep original HPC Bar Code Label as proof of purchase in case factory assistance is needed.
111210
35T00-234-00
© 2010 • HPC, Inc. • Schiller Park, IL • 60176 • USA • www.hpcworld.com
Digital KeKab
DIGITAL LOCK
®
DO NOT SHUT CABINET
BEFORE TESTING THE
FACTORY CODES!
are tested in the factory and the batteries are DISCONNECTED before shipping.
®
®
(1)
No. KEKAB-DL65
KEKAB-DL95X
KEKAB-DL265
(continued)
Advertisement
Table of Contents
Summary of Contents for HPC KEKAB Series
- Page 1 • As soon as possible, reset all codes making the factory default codes inoperable. • Keep these instructions and all codes in a safe, retrievable place for future reference. • Keep original HPC Bar Code Label as proof of purchase in case factory assistance is needed. (continued) 111210 35T00-234-00...
- Page 2 5. Replace plate and (3) small screws. See Fig. 4. Fig. 2 6. Remove tape from latch. See Fig. 5. Fig. 3 Fig. 5 Fig. 4 (continued) © 2010 • HPC, Inc. • Schiller Park, IL • 60176 • USA • www.hpcworld.com...
- Page 3 9-volt battery via the override terminals on the face of the lock. (See instructions for KEKAB-DLJH on page 5.) (continued) © 2010 • HPC, Inc. • Schiller Park, IL • 60176 • USA • www.hpcworld.com...
- Page 4 TO CHANGE THE USER CODE WITH THE USER CODE: (Existing Four Digit User Code) 2. PRESS: (New Four Digit User Code) (Repeat The New Four Digit User Code) (continued) © 2010 • HPC, Inc. • Schiller Park, IL • 60176 • USA • www.hpcworld.com...
- Page 5 This is the Binding Indicator-the lock is binding with the strike plate. Press firmly on the door while operating. If binding is a frequent occurrence, the strike plate and/or door hinges need to be aligned with the lock. © 2010 • HPC, Inc. • Schiller Park, IL • 60176 • USA • www.hpcworld.com...
