Love SCD-PS Series Quick Start Manual

Model
SCD-PS
1
This instruction will be helpful in the installation, electronic specification, function specification and troubleshooting of the SCD-PS.
This is an OPEN TYPE SCD-PS series. The SCD-PS series should be kept in an enclosure away from airborne dust, high humidity,
electric shock risk and vibration. Also, it is equipped with protective methods such as some special tools or keys to open the enclosure,
so as to avoid the hazard to users and the damage to the SCD-PS series.
Never connect the AC main circuit power supply to any of the output terminals, as it will damage the SCD-PS series. Check all the
wiring prior to power up. To avoid any electromagnetic noise, make sure the SCD-PS series is properly grounded
2

2.1 Model Explanation

Thank you for choosing Love Control's SCD series. The Model SCD-PS is a power module and provides 24VDC and 1A current for output
power. It is only used for Love SCD series. The Model SCD-PS is separated from the PLC MPU for better space utilization and easier
installation.
SCD-PS

Nameplate Explanation

Model
Input Power Supply Spec.
Output M odule Spec.
Barcode and Serial Number

2.2 Product Profile and Outline

SCD-PS
5
2
1
36.5
3
3
Model
Item
Power Input
Output Power
Ripple & Noise
MODEL : SCD-PS
INPUT : 100~240VAC 50/60Hz
OUTPUT : 24Vdc 1.0A
SCD-PST6360001
13.3 60
Unit: mm

Function/Electrical Specification

POWER OUTPUT MODULE

Warning

Introduction

Serial Number
SCD-PS T 6 36 0001
1 Power LED
2 Output/input terminal (fixed terminal)
3 DIN rail clip
4 DIN rail track (35mm)
4
5 I/O terminal label
6 Nameplate
6
3
SCD-PS
100~240 VAC (-15%~+10%), 50 / 60 Hz
24VDC (±3%), output current: 1A max.
Under 100mV Typical at full load
p-p
.
Production number
Production weeks
Production year (2006)
Production factory
Production model
