- Page 1 Installation manual Mobeye MS100E Measure, Control and Alarm module SW version 7.n...
- Page 3 • Do not let it fall from height. • Do not use in an environment where any inflammable gases, vapours or dust are present or could be present. • Repair of the device may only be carried out by people, trained for Mobeye ® repair.
-
Page 5: Table Of Contents
Table of Content Introduction To get ready in seven steps Place the SIM Card Connect a sensor Connect the power supply Connect the back-up battery Program the phone numbers Check the settings Alarm message confirmation Controlling the outputs Sensors and devices Configuration method Program mode How to program by SMS... -
Page 6: Introduction
The Mobeye MS100E has following features: • In case one of the inputs is activated by a sensor, the Mobeye MS100E sends an alarm SMS text message and calls the phone numbers as programmed. The SMS message contains the text ‘Mobeye alarm 1’... -
Page 7: To Get Ready In Seven Steps
5.10). 2.3 CONNECT THE POWER SUPPLY The Mobeye MS100E is designed to run on an external power supply (9-32VDC). The module will always be in connection with the GSM network. This gives following features: possibility to receive power failure messages (using a back-up battery) and the possibility to perform remote actions, such as arm/disarm, switch the outputs, ask status reports and to program it via SMS-commands. -
Page 8: Connect The Back-Up Battery
After inserting the SIM card and connecting the power, the Mobeye MS100E will perform a self test taking 1 minute. During the test, the light is red. If the light is flashing red, a problem with the SIM card is detected. A reason could be no SIM card was placed, or the PIN code security of the SIM card was not disabled. -
Page 9: Check The Settings
In this way you also check the correct working of the SIM card. Upon sending the command, the Mobeye MS100E returns an SMS text message to the originator of the request. SMS command list settings:... -
Page 10: Sensors And Devices
3. SENSORS AND DEVICES Several external sensors can be connected to the two inputs. The Mobeye MS100E can also switch external devices connected to it via the outputs after receiving an SMS command (or phone call). The Mobeye MS100E has a 9-32V power input for connection to an external power source. -
Page 11: Configuration Method
4.1 PROGRAM MODE As soon as the unit is powered and finished the start-up, the Mobeye MS100E in program mode and ready to receive SMS commands. -
Page 12: Configuration Possibilities
Up to five telephone numbers can be programmed in to the Mobeye MS100E. In the event of an alarm the Mobeye MS100E first sends an SMS text message to all numbers, next they are called. It is possible to confirm the call, after which the other numbers will not be called anymore. -
Page 13: Identification Text
It is possible to add a standard identification text (NAME) to all messages sent out by the Mobeye MS100E. The alarm messages are a combination of the name and the alarm text. A user defined identification has a length of maximum 20 characters. The default identification text is ‘Mobeye’. -
Page 14: Authorisations And Remote Control
O2OFF 5.15 UNAUTHORISED SWITCHING OF OUTPUTS Although the Mobeye MS100E is designed to only switch the outputs by an incoming SMS (or call, see chapter 6) from an authorized phone, there is also an option to let them be switched by any incoming call/SMS, without being authorised. To disable the need for authorised numbers, the 'authorization' option can be set to OFF. -
Page 15: Action Rules
6. ACTION RULES The alarm message and behaviour of the outputs of the Mobeye MS100E are programmed by action-reaction patterns. These so-called Action Rules are pre- programmed, according to the needs of many applications. However, it is possible to change these action rules (for advanced users only!). -
Page 16: Programming Action Rules
• Do not forget the space between CODE and the TRIGGER. • The Mobeye MS100E will play a short melody to indicate a successful configuration. In case of a wrong command, a long beep will sound. 6.4 TIME-BASED ACTION RULES It is possible to let the action be daily performed at a certain time. -
Page 17: List Of Programmed Action Rules
6.5 LIST OF PROGRAMMED ACTION RULES A list of programmed action rules, the Action Rules List (ARL), can be requested by sending following SMS to the unit. Example: Request programmed action rules: 1111 ARLREPORT? CODE ARLREPORT? 6.6 DELETE ACTION RULES An action rule can be deleted by an SMS by the command below incl. -
Page 18: Complete List Of Settings
Authorise telephone TELA1: ...TELA50: Tel. number number of ADDTELA: Delete authorised DELA:1..DELA:50 number Authorised remote AUTH: ON, OFF control Identification text NAME: 20 characters Mobeye Alarm text power TEXT2: 20 characters Power failure failure Alarm text power TEXT3: 20 characters Power... - Page 19 Setting Menu/ Options Factory command default restored restored Alarm text input 1 TEXT4: 20 characters Alarm 1 Alarm text input 2 TEXT5: 20 characters Alarm 2 Input 1 Text restored input 1 TEXT6: 20 characters restored 2 Input 2 Text restored input 2 TEXT7: 20 characters restored Program method via SMS (in program mode):...
-
Page 20: Reports And Lists
The originator of the request receives GSM signal strength as list. Warning In the event of a weak signal, the Mobeye MS100E can still be used, but there is a risk that messages cannot be sent or will be received with a delay. In case of no signal, it is... -
Page 22: Issue Solving And Technical Data
• Temperature range: -10°C until +55°C • Dimensions: 161 x 90 x 35 mm (LxWxH) • Back-up battery: Lithium-Ion, Mobeye article number AC-RBP1 • Power: 50 mA, short peaks of max. 2 A For support on technical problems regarding Mobeye MS100E please contact info@mobeye.eu. - Page 23 Declaration of Conformity Herewith we, Mobeye, declare that the product Mobeye XM2 telemetry module And the derived products MS100, MS200, MS300, Call-Key are in compliance with the essential requirements of the following European standards / EU Directives: Directive 73/23/EEC (low voltage directive)
