Summary of Contents for YF ET-9EN
- Page 1 Microcomputer Fructose Dispenser ET-9EN、 ET-9EA Technical Manual We won TAIWAN PACKAGING STAR (TP STAR) GOOD DESIGN PRODUCT TAIWAN EXCELLENCE 2001 CE MARKING CERTIFIED MINISTRY OF ECONOMIC AFFAIRS INNOVATIVE RESEARCH AWARD Made by Y-FANG SEALING MACHINE LTD.
- Page 2 340W...
- Page 3 II. Operation Instructions: 1. Fill the fructose reservoir before you power on the machine. If the fructose level becomes too low during operation the machine will emit 5 beeps and the indicator light will begin to flash. Please refill with fructose immediately to avoid malfunction.
- Page 4 IV. Function setting instruction table: (It is recommended that setup be performed by a technician) Long press the “Setting” key (5 seconds) to enter internal function settings. After setting has been completed, press the “Setting” and “Save” keys to end the task and exit.
- Page 5 Attachment 1 Component Detailed Drawings Connecting collar Washer Plug Spring Fructose output nozzle Please clean the fructose output nozzle every week...
- Page 6 Attachment 2: Internal structure and disassembly 1. Loosen the nut by using socket wrench #35 2. Loosen the screws on the base to complete the task...
- Page 7 Incorrect (X) Correct (O) Figure A...
- Page 8 3. Selector terminal plug on IC board loose 4. IC board crash Press “Setting” key for 5 seconds to Flow rate shows serious error enter P1 total flow rate and re-calibrate Washing the ET-9EN/ET-9EA Fructose syrup Dispenser with hot water is strictly prohibited...
- Page 9 Technical Note 18 ET-9EN / 9EAFructose Dispenser IC board [44 pins] Wiring Diagram ET-9EN Fructose Dispenser IC board [updated 2007.6] Wiring Diagram Filter capacitors Temperature sensor cord Switch Buzzer Liquid level cord Transformer Counter electric eye Plug for external SENSOR...
- Page 10 ET-9EN/ET-9EA Maintenance Fructose syrup dispenser cleaning procedures 1. Press the “Continue” key to drive out residual fructose. 2. Use absorbent paper or a dry cloth to remove any remaining fructose. 3. Pour in 60°C warm water and use sponge to wash and wipe, and then loosen output end to remove it.
- Page 11 Product Microcomputer Telephone Address Description Fructose Dispenser Model Number ET-9EN/ET-9EA Warranty Conditions: 1. This machine is warranted for one year Company Finished Product Certification Seal: from the date of shipment from the factory. During this period maintenance and parts replacement will be made free of charge.
