Troy-Bilt TBWC28 Fast Start Manual

1
A. Tighten star knobs
securing upper
and lower handles
together.
B
B. Push down
on the handle
adjustment lever
with your foot.
A
A
2
Pivot the handle
into operating
position. Be careful
not to crimp cables.
© 2017 12ABW32G
IMPORTANT: READ OPERATOR'S MANUAL AND ENGINE MANUAL THOROUGHLY
AND FOLLOW THE IMPORTANT SAFE OPERATION PRACTICES BEFORE OPERATING .
READ AND UNDERSTAND ALL INSTRUCTION, WARNING, AND DANGER LABELS.
PARA INSTRUCCIONES EN ESPAÑOL, REFIÉRASE AL MANUAL DEL OPERADOR.
Starter
Rope Handle
Handle
Adjustment
Lever
Note: Refer to your Operator's Manual
for instructions on attaching the grass collector.
Premium Drive Control

Blade Control

The handle height can be adjusted to one of two
positions. Push down on the handle adjustment
lever with your foot and place the handle into the
most comfortable operating position.
A. To convert to side discharge, lift the
mulch plug.
B. Slide two hooks of side discharge chute under
hinge pin on mulch plug assembly and position
hole in the chute over and onto the deck stud
located behind the discharge opening. Lower
mulch plug.
C. Secure the chute to the mowing deck by
Mulch Plug
threading wing knob included in the manual
bag onto the deck stud.
C
Deck
Stud
Need Help?
Call 1-888-TO-HELP-U
3
4
A
Mulch
Plug
B
778-13650
