F2B, VMF-2,
VM-2
Manual Version 2.11
B
E
URST
LECTRONICS INC
A
LBUQUERQUE, NM 87109
(505) 898-1455
VOICE
(505) 890-8926
TECH SUPPORT
(505) 898-0159
FAX
www.burstelectronics.com
Hardware, software and manual copyright by Burst Electronics. All rights reserved. No part
of this publication may be reproduced or distributed in any form or by any means without the
written permission of Burst Electronics.
Video Mixers and Faders
USA
Made in USA
Advertisement
Summary of Contents for Burst Electronics F2B
- Page 1 TECH SUPPORT (505) 898-0159 www.burstelectronics.com Hardware, software and manual copyright by Burst Electronics. All rights reserved. No part of this publication may be reproduced or distributed in any form or by any means without the written permission of Burst Electronics.
- Page 3 Black unit, a 2 channel A to B Mixer, and a 2 channel A to B Mixer/Fader. Model F2B Fade to Black The F2B Fade to Black module is a single input device. The video input fades to black (7.5 IRE) through the action of a fader bar.
- Page 4 Interconnect the VMF-2 Head End unit with the Remote Control Unit (RCU) using the RJ11 cable attached to the RCU. Burst Electronics supplies a 3’ (1 meter) cable. This cable may be lengthened to a maximum of 25’ (8 meters).
- Page 5 Power is supplied by a 12 Vdc 500 mA wall module (included). Any 12 Vdc source may be used (camera battery pack or equivalent). The center pin for the power supply is negative. VMF-2 Operation The VMF-2 will fade from A to B, B to A, or A to Black.
- Page 6 bar. The range is from about 0.15 seconds to 5 seconds. Select the speed you desire by adjusting the position of the fader bar. Upon hitting the TAKE pushbutton (or activating a GPI), the action (be it A to B, B to A, or A to Black) will occur at your preset speed.
-
Page 7: Specifications (All Models)
7.5 IRE Setup (0 IRE for PAL) DC Powered 11 to 14 Vdc Power 120 VAC 60 Hz, 12 Vdc 500 mA UL Listed Wall Module (included, center negative) Model F2B Bandwidth: 10 MHz @ 0.5 dB Differential Gain: 0.1% Differential Phase: 0.1°... - Page 8 Video Mixers & Faders...
