meyland-smith Discover User Manual

size 1 and size 2 users manual
Carry brace
Sling support
Introduction
The users manual contains information about how Meyland Discover is adjusted, how it is
maintained, safety precautions and technical data.
Meyland Discover is intended as a crawling aid for small children and is only suited for
indoor use.
In illustration 1 the different parts of the crawling aid is designated.
Getting ready for use
Meyland Discover is supplied fully assembled and
must therefore simply be adjusted to fi t the child
before use.
Adjustment
The height of the sling support is adjusted on
each side with the spring mountings placed on the
stanchions. It is recommended to always set the
height equally on each side. The height is adjusted
by drawing out the spring mounting and setting the
carry brace to the desired height. (see illustration
2)
Meyland Discover does not have brakes. All four
wheels are smooth rolling and revolving to give the
child as much freedom of movement as possible.
Spring mounting
Stanchion
Illustration 1
Illustration 2
Safety precautions
Warning:
Meyland Discover must never be used without an adult present and never in places where
there is a risk that the child can run over a dangerous edge (stairs or the like).
Warning:
Meyland Discover must never be used for sitting or standing on since it can easily roll away
under the child.
Limitations for use:
The maximum allowable weight of the users is 25 kg.
Meyland Discover should only be used on a plane, horisontal and stable surface.
Maintenance
All parts of Meyland Discover can be cleaned with hot water and soap.
It should should regularly be checked that bolts, screws and nuts are tightened and if
necessary re-tighten them.
Technical data
Total width
Total depth
Slingsupport width
Slingsupport depth
Height of slingsupport
Weight
Max load
The frame is made from powder coated steel pipes and the sling support is made from
imitated leather.
size 1 and size 2 users manual
Size 1 Size 2
52 cm 52 cm
31 cm 31 cm
28 cm 28 cm
18 cm 24 cm
10 - 21 cm 10 - 21 cm
4 kg 4 kg
25 kg 25 kg
