Summary of Contents for Assa Abloy TRAKA TOUCH L
- Page 1 TRAKA TOUCH L INSTALLATION GUIDE TD0068 03/08/18 VERSION 2.4 This Document is the subject of copyright and must not be copied or otherwise reproduced either in whole or in part without the express written permission of TRAKA.
-
Page 2: Version History
VERSION HISTORY Version Date Description of Changes Approved By 05/07/14 Initial version of document 07/07/14 Changed wording in Battery & Diagram Key 28/01/15 Updated the PCB type to the new iMX28 added new screenshots 12/05/15 Added information on extension systems and changed document layout. -
Page 3: Table Of Contents
CONTENTS Version History ..............................2 Contents ................................ 3 Introduction ............................. 5 Product Details ............................5 Electrical Rating ..........................5 Environmental Rating ........................5 Compliance Level ..........................5 2.3.1 USA and Canada .......................... 5 2.3.2 Europe ............................5 System & iFob Diagram ..........................6 System Diagram .......................... - Page 4 Maintenance ............................32 10.1 Switching off the system ......................... 32 10.2 Manually Opening the Door ......................33 10.3 Serial Number/Rating Plate Location ....................34 10.4 Replacing the Fuse in a Surge Protection Device ................. 35 10.5 Backup Battery ..........................36 10.5.1 Battery Location ........................
-
Page 5: Introduction
INTRODUCTION This User Guide has been prepared to assist with the installation of a Traka Touch L System and additional extensions. PRODUCT DETAILS ELECTRICAL RATING Power supply: Input: 100-240V AC, Output: 15V DC Battery backup: DC12v 7Ah Power consumption: 35W max ENVIRONMENTAL RATING Operating temp: Ambient, for indoor use only (-5°C to +40°C at 95% non-condensing relative humidity) -
Page 6: System & Ifob Diagram
SYSTEM & IFOB DIAGRAM SYSTEM DIAGRAM 3.1.1 DIAGRAM KEY Receptor Slot The Receptor Slot holds the iFob in place. Pod Cam Lock 2 master keys are supplied with your Traka system. The master key can be used for gaining access to the system electronics during servicing and maintenance. -
Page 7: Ifob (Intelligent Fob) & Key Bunch Diagram
IFOB (INTELLIGENT FOB) & KEY BUNCH DIAGRAM 3.2.1 IFOB KEY iFob The iFob is at the heart of any Traka Key Management system. It is a bullet shaped device made from nickel plated brass. It contains a microchip with a unique identification number allowing the Traka system to identify the key(s) attached. -
Page 8: Extension Systems Overview
EXTENSION SYSTEMS OVERVIEW If your system does not have extension cabinets you can skip this section. Additional ‘extension’ cabinets are installed alongside the main system. Up to three additional extensions can be added for a total of four systems. NOTE: Each extension cabinet will be clearly marked to indicate which order they should be located next to the main system. - Page 9 Primary CANbus – through-connection connects to the Traka Touch PCB (if it is in the main cabinet) or the previous cabinet (if it is in an extension system). Secondary CANbus - connects to the receptor strips in the local cabinet. Cabinet Door Solenoid and Switch - connects to the door lock mechanism in the local cabinet.
-
Page 10: Before You Start
BEFORE YOU START MOUNTING INFO & SAFETY TIPS Traka systems contain delicate electronic components which may be damaged if Electrostatic Discharge (ESD) control measures are not correctly adhered to. Traka systems must be securely fastened to a wall to eliminate the potential of the system being pulled over and causing damage or injury. -
Page 11: What You Should Have
WHAT YOU SHOULD HAVE Once you receive your Traka Touch system, please check you have the following… Traka Touch L cabinet Traka Touch L 4x M5 x 15mm 2x Master Ferrite Core & 1x Pod (Pod will not extension(s) (if... -
Page 12: Wall Preparation
‘systems width section' of the skirting board so it will sit flush to the wall. The chosen location for the main cabinet should be no further than 1 Meter from the mains spur. NOTE: All dimensions are in mm. Standard Traka Touch L System V2.4 03/08/18 TD0068 Page 12 of 38... - Page 13 Knockout Dimensions NOTE: The Traka Touch L system is very heavy (60+kg) and therefore needs a strong wall to fix to. Fixings are not included and so when selecting the appropriate fixings it is essential they are strong enough to retain the Traka System and not pull out from the wall.
-
Page 14: Installing The System
INSTALLING THE SYSTEM The Touch L system must be secured to the wall as described in this section to eliminate risk of injury or damage. It is required that the system be installed by two people. One person must be holding the system at all times, ensuring that it does not fall whilst the other prepares it for install. -
Page 15: Attaching The Pod To The Cabinet
ATTACHING THE POD TO THE CABINET When you receive your Traka Touch L system the Pod will not be attached to the cabinet. To attach the Pod the Control Panel must be removed. Refer to the Traka Document Template Style Guide for information on formatting requirements. - Page 16 Once all of the relevant cables have been disconnected, the Control Panel can be removed by disengaging the 2 spring hinges. Place the Control Panel to one side. This will be refitted at a later stage in the installation process. The Pod can now be attached to the side of the cabinet using the supplied M5 x 15 Cap Screws.
- Page 17 An earth cable connected to the fixing point on the door lock mechanism will be coiled up in the back of the cabinet. Route this cable through the cut-out and connect to the earth cable attached to the base of the Pod. V2.4 03/08/18 TD0068 Page 17 of 38...
-
Page 18: Routing Cables
ROUTING CABLES On top of the system are two knockouts. These are used to bring the Mains Cable and Network Cable (if applicable) out through the cabinet to the mains spur and network socket. Using a large flat headed screwdriver and a hammer, carefully knockout one or both of these holes depending on your requirements. - Page 19 Attach the supplied ferrite core to the network cable. Any cables to be connected between the cabinet and the Pod will be coiled up in the back of the cabinet. Before standing the cabinet against the wall, the following cables must be passed through the cut-out in the cabinet and into the Pod.
-
Page 20: Accessing The Fixing Holes
ACCESSING THE FIXING HOLES Using one of the supplied master keys, manually open the cabinet door by turning the key clockwise. Using a 4mm Allen Key or T-bar, unscrew the two M6 x 25mm socket screws to remove the cover panels. The 1U blank fascia and strengthener at the bottom of the system will become loose and can be put to one side. - Page 21 This will reveal three mounting points at the bottom of the system. Using a 10mm Nut Spinner/Ratchet, unscrew the two M6 nuts to remove the blank fascia and strengthener at the top of the system. NOTE: If the cabinet is part of a system with additional extensions there will be an interface PCB located on the back of the 1U strengthener with several cables connected to it.
-
Page 22: Fixing To The Wall
FIXING TO THE WALL NOTE: Traka Systems can be heavy. The Touch system must be secured to the wall, as described in this section, to eliminate risk of injury or damage. The system may also require two persons to lift it. Locate the desired position on the wall you wish the Touch system and any extension cabinets (if applicable) to go. - Page 23 NOTE: If you are extending an existing system, the Door Lock Cable will have originally been connected to the Control Pod. A Door Lock Extension Cable will have been supplied with your extension system to extend the original lock cable to enable it to be connected to the Interface PCB. Disconnect the existing lock cable at the joining bullet connectors, and connect the new lock extension cable.
-
Page 24: Re-Fitting The Control Panel
RE-FITTING THE CONTROL PANEL Refit the Control Panel as removed in the ‘Attaching the Pod to the Cabinet’ section by engaging the spring hinges in the corresponding slots on the Pod. Connect the following cables to the Control Panel as shown below. Earth Cable Power, Battery, Door and Reader cable (if applicable) Speaker, Network and USB cables (if applicable) - Page 25 V2.4 03/08/18 TD0068 Page 25 of 38 This Document is uncontrolled when printed unless over stamped “CONTROLLED DOCUMENT”...
-
Page 26: Connecting The Mains Power
CONNECTING THE MAINS POWER IMPORTANT: The installation of Traka products must be carried out in accordance with any local electrical installation codes/standards that may apply. NOTE: A readily accessible mains disconnection device must be incorporated in the building installation wiring and this device must enable double pole disconnection. NOTE: In the case of a battery being fitted there are two power sources present. - Page 27 Follow the process below to install the surge protection module. The cover on the surge protection module is secured with M4 Torx screws. Remove the screws using a T25 Torx driver and remove the cover. There will be an earth lead connected to the cover that can also be disconnected. NOTE: Ensure the module is not connected to the mains power outlet before removing the cover.
- Page 28 Pass the mains cable from the Traka Power Supply through the cable gland and connect the Live (L), Earth (E) and Neutral (N) wires to the terminal block as labelled, and then tighten the cable gland. Refit the cover. Connect the plug to the mains power outlet. V2.4 03/08/18 TD0068 Page 28 of 38...
- Page 29 V2.4 03/08/18 TD0068 Page 29 of 38 This Document is uncontrolled when printed unless over stamped “CONTROLLED DOCUMENT”...
-
Page 30: Switching On The System
SWITCHING ON THE SYSTEM The system will automatically boot up when the mains is connected. However, if you are powering the system from a backup battery alone, or the system has been switched off with the mains still connected, you can switch the system on following the steps below. -
Page 31: Product Disconnection
PRODUCT DISCONNECTION MAINS DISCONNECTION To completely disconnect the system from the mains follow the steps below: If the product is connected to a non-switched fused spur, remove the fuse from the spur. • • If the product is wired to a plug and connected to a power outlet, disconnect the plug from the power outlet. In the case of a battery being fitted there are two power sources to disconnect before any service or •... -
Page 32: Maintenance
10. MAINTENANCE This section will take you through certain processes that may be useful when servicing the system, or if an area is in need of general maintenance. If at any point you are unsure please contact Traka Technical Support for advice. 10.1 SWITCHING OFF THE SYSTEM Disconnecting the system directly from the mains could result in data loss and should only be done in an emergency. -
Page 33: Manually Opening The Door
10.2 MANUALLY OPENING THE DOOR Using one of the supplied master keys, manually open the cabinet door by turning the key clockwise. V2.4 03/08/18 TD0068 Page 33 of 38 This Document is uncontrolled when printed unless over stamped “CONTROLLED DOCUMENT”... -
Page 34: Serial Number/Rating Plate Location
10.3 SERIAL NUMBER/RATING PLATE LOCATION The Traka Touch Serial Number/Rating Plate can be found in the following location: Insert the Master key into the cam Lock on the Control Pod and turn the key 90° clockwise. The Control Panel will now lean forward at 90°. The Rating plate serial number can be found on the back of the Touch System pod. -
Page 35: Replacing The Fuse In A Surge Protection Device
10.4 REPLACING THE FUSE IN A SURGE PROTECTION DEVICE NOTE: This section only applies to systems installed in the USA and Canada. Each surge protection device is fitted with a ‘slow-blow’ 3A fuse. The fuse specification is: 3A 125V 6.3x32mm Slow Blow •... -
Page 36: Backup Battery
10.5 BACKUP BATTERY 10.5.1 BATTERY LOCATION Traka provide a backup battery already connected with every Touch System inside the UK. If for any reason you need to connect/disconnect the battery yourself please follow this section and then refer to the connection details below. Using one of the supplied master keys, manually open the cabinet door by turning the key clockwise. -
Page 37: Battery Connection Details
10.5.2 BATTERY CONNECTION DETAILS The battery inside the Traka Touch will already be connected to the battery cable when you receive your system, if however you need to replace a battery or the cable, please reconnect using information below. If you are unsure please contact Traka Technical Support using the details at the end of this document. -
Page 38: Technical Support
11. TECHNICAL SUPPORT If you need to contact Traka/distributor for technical support, please use the contact information below. UK Telephone: 0845 630 6300 International Telephone: +44 1234 711391 support@traka.com Email: Web: support.traka.com V2.4 03/08/18 TD0068 Page 38 of 38 This Document is uncontrolled when printed unless over stamped “CONTROLLED DOCUMENT”...
