Summary of Contents for Water Hero P-100
- Page 1 P-100 INSTALLATION AND OPERATION MANUAL...
- Page 3 Water Hero P-100 Thank you for purchasing the Water Hero P-100, which offers whole-building leak detection and water conservation monitoring. This box contains: Water Meter, Sensor Main Controller Cap & Unions Motorized Ball Valve Sensor Cable [~6 foot cord length]...
-
Page 4: Terms And Conditions
Warning Terms & Conditions Water Hero P-100 is plumbed into a water All Water Hero terms and conditions, supply line. Improper installation can cause privacy policies warranty leaks. Ensure installation is completed policies can be found on the Water by a licensed plumber and abides by the... - Page 5 Start- Up Guide P-100...
- Page 6 3. Connect blue Sensor Cable to jacks on round white Sensor Cap and Main Controller 4. Connect Valve Power Cord to Main Controller 5. Water Hero Main Controller will power up; a blinking green LED and solid yellow LED will illuminate Main Controller...
-
Page 7: Connect To Your Wifi Network
Connect to Your WiFi Network Option #1: Using an iPad or iPhone 1. Search the Apple App Store for “Water Hero Remote” and download 2. Open the app and tap the text that reads “New Customer? Tap here to create an account”... - Page 8 Connect to Your WiFi Network Option #1: Using an iPad or iPhone 4. You’ll be directed to the “My Devices” page; on the bottom right tap “+” 5. Follow Step 1 instructions, and tap “Next” at the bottom of the page, then continue through Step 4...
- Page 9 Connect to your WiFi Network Option #2: Using any smartphone or computer 1. Using your device (i.e. computer, laptop, or mobile device), open a web browser. Enter URL mywaterhero.net and select “Create an account” 2. Enter your e-mail address and desired password.
- Page 10 Access the Device Configuration Page 1. Turn the Main Controller to its side; ensure the yellow light* is lit solid and the green light is blinking *If Yellow light is not illuminated perform Network Reset, P. 23 of manual 2. Go to WiFi settings on your smartphone or computer;...
- Page 11 Access the Device Configuration Page 3. Once connected to “Water Hero Access Point” WiFi network, open an Internet browser (we recommend Chrome) and go to URL http://192.168.1.1 to access Water Hero’s “Device Configuration Page” http://192.168.1.1...
- Page 12 2. Enter your Wi-Fi network password (Case Sensitive) 3. Enter the e-mail address associated with your Water Hero Account Do NOT enter data in ”Manual Input” Section 4. Once all information is unless prompted by Water Hero staff entered, press “Add”...
- Page 13 *If green light not blinking, conduct Network Reset on P. 23 of manual 2. Open a browser and enter URL www.mywaterhero.net 3. Enter e-mail address associated with your Water Hero Account password and press login to view your device online...
- Page 14 Prepare for installation of Water Hero 1. The valve and meter of the Water Hero P-100 can be installed in a horizontal or vertical orientation 2. Motorized Ball Valve should be installed upstream from the meter 3. Water Hero P-100 MUST be installed downstream of fire suppression...
- Page 15 Prepare for installation of Water Hero INSIDE BUILDING STREET SIDE Main Controller Power P-100 Water Adapter Meter Motorized Ball Valve Main Water Supply Water Hero P-100 MUST be plumbed after (downstream of) fire suppression systems...
- Page 16 Features & Functionality P-100...
- Page 17 My Devices 1. Login to your account at mywaterhero.net and you will be presented the “My Devices” tab. This tab shows all Water Hero devices registered to the account. It also shows total water flow amount for each device listed and the ambient temperature at the meter sensor.
- Page 18 Dashboard Ambient air Gauge displays temperature real time Remote Valve Leak detection Operation mode Selector selector* Hourly water usage data *Home/away mode alerts and shut-offs can be adjusted under the Settings Tab...
- Page 19 Utilities “Timed Measurement” allows “Measure Flow” is a stopwatch user to find out how much feature that allows user to view water was used during a the amount of water that has specific period of time. Set the been used over a period when target date and times to get the feature is engaged.
- Page 20 Settings Notifications panel Temperature alerts panel Home and Away Mode allows user to select allow user to set low panels allow user to set method by which and high temperature limits after which alerts warnings and alerts warnings. Temperature and automatic shut-off are sent extremes could indicate are triggered...
- Page 21 Preferences The Large Preference panel Water and Temperature Unit boxes indicates e-mail, name and enable switching between imperial phone number for your account and metric units of measurement for volume and temperature newcustomer@example.com New Customer 000-000-0000...
-
Page 22: Troubleshooting
Troubleshooting P-100... - Page 23 Diagnostics Valve Network Reboot Open/Close Reset Water Hero Access Point Mode (green blinking ; yellow solid) Normal Operation (green blinking slowly) Sensor Cable Not Connected (red and blinking)
- Page 24 Troubleshooting Perform a network reset or modify e-mail account* Note: Only perform a network reset when Water Hero must be paired to a new WiFi network or associated with a new e-mail address, as repeated Network Resets can make your device unstable! 1.
- Page 25 If Water Hero was previously online and is now currently offline, conduct the following steps: 1. Check your WiFi signal near the Water Hero with a laptop or smart phone. If WiFi is down, reset your modem. 2. If WiFi is weak, consider purchasing and installing a range extender.
- Page 26 Situation 3: To Open or Close Valve from the device Main Controller If you can not access the Water Hero web interface or iOS app and need to open or close the valve from the device Main Controller, conduct the following: 1.
- Page 28 © 2018 Water Hero Inc.
