Slim Devices Squeezebox2 Classic Integration Notes

Hide thumbs Also See for Squeezebox2 Classic:
1
2
3
4
5
6

Advertisement

Quick Links

Download this manual
Manufacturer:
Model Number(s):
Core Module Version:
Comments:
Document Revision Date:
O
S
VERVIEW AND
UPPORTED
The Squeezebox Classic is a network music player that connects to the network and provides local audio
outputs for digital music. The Squeezebox Classic supports digital music from both internet sources and
local media. When integrated with the current version of the g! software, the Squeezebox Classic is used
as an extension of the Internal Player and can stream from the same local music library as the Internal
Player. In addition, the Squeezebox Classic supports Pandora or Rhapsody Internet Radio via
Squeezenet.
IMPORTANT! This document covers the Squeezebox "Classic" model 2/3. Slim Devices (now
Logitech) has released multiple iterations of the Squeezebox, which can be identified by checking
the "Model:" number on the bottom of the device. If it says Logitech as opposed to Slim Devices,
it is a Squeezebox 2/3.
If you are working with a Squeezebox Touch, please see the Squeezebox Touch Integration Note.
This Integration Note does not apply to Logitech Media Server integration.
T
HE FOLLOWING PLAYBACK OPTIONS ARE SUPPORTED BY THE
•
Play and index digital music stored locally or on network storage.
•
Browse library by Artist, Album or Tracks and create/manage Playlists.
•
Supports .MP3, .FLAC, and .WAV files stored on the HC Hard Disk (if applicable) or
other networked storage device.
•
Stream Pandora and Rhapsody Internet Radio through Squeezenet
T
HE FOLLOWING PLAYBACK OPTIONS ARE
•
Audio file formats other than .MP3, .FLAC or .WAV
•
Squeezenet Features other than Pandora or Rhapsody
Note: The Now Playing screen will always display transport controls, but transport
controls are not necessarily supported on all services (Pandora etc).
Any feature not specifically noted as supported should be assumed to be unsupported.
ELAN Home Systems ● 1690 Corporate Circle ● Petaluma, CA 94954 USA
tech support: 800.622.3526 • main: 760.710.0990 • sales: 877.289.3526 • email: elan@elanhomesystems.com
©2013 ELAN Home Systems. All rights reserved. ELAN and g! are trademarks of ELAN Home Systems. All other trademarks are the property of their respective owners.
Slim Devices
Squeezebox2 / Squeezebox3 "Classic"
3.0.419 or later
Squeezebox2 Firmware 15 / SlimServer 5.4.0
SqueezeBox3 Firmware (Version 130, Core Module
4.0.1631/5.0.687/5.1.223 or newer for Rhapsody)
1/30/2013
F
EATURES
NOT
SUPPORTED BY THE
Integration Note
:
S
QUEEZEBOX
S
:
QUEEZEBOX

Advertisement

loading
Need help?

Need help?

Do you have a question about the Squeezebox2 Classic and is the answer not in the manual?

Questions and answers

Related Manuals for Slim Devices Squeezebox2 Classic

Summary of Contents for Slim Devices Squeezebox2 Classic

  • Page 1 IMPORTANT! This document covers the Squeezebox “Classic” model 2/3. Slim Devices (now Logitech) has released multiple iterations of the Squeezebox, which can be identified by checking the “Model:” number on the bottom of the device. If it says Logitech as opposed to Slim Devices, it is a Squeezebox 2/3.

  • Page 2: Installation Overview

    NSTALLATION VERVIEW 1. Install the Squeezebox at the desired location, and pull power and Cat5 as needed. 2. Connect the Squeezebox electrically to the home network and then configure the Squeezebox. See Squeezebox Configuration. 3. Integrate the Squeezebox into the g! system and test proper operation. This step is outlined in g! Configuration Details.
  • Page 3 Type in the desired name for the item. “<Auto Detect>”, etc. The system will auto detect this variable. Devices Variable Name Setting Comments <User Defined> (Default: Slim Devices Squeezebox2/3) MP3 Players Name Device Type Slim Devices Squeezebox2/3 <User Defined> (Not Required) Location <User Defined>...

  • Page 4: Important Notes

    QUEEZEBOX ONFIGURATION IMPORTANT NOTES: The Squeezebox is configured using its display based menu system and its remote control. ELAN strongly recommends using the hard-wired Ethernet connection to the Squeezebox instead of a wireless connection. Only configure one Squeezebox at a time. If you have multiple Squeezebox’s in an installation, disconnect power to all but one, then configure that one.
  • Page 5 ANDORA HAPSODY ONFIGURATION To setup Pandora or Rhapsody Internet Radio, you must first configure a Squeezebox account at http://mysqueezebox.com (formerly http://squeezenetwork.com) and associate the Pandora and/or Rhapsody service with the account. Rhapsody is a paid service, and may use existing credentials or requires the creation of a new account.
  • Page 6 ANDORA HAPSODY INTEGRATION VIA QUEEZENET OTES The following issues have been observed when integrating Pandora via Squeezenet: • Skipping multiple tracks on a Pandora station can result in inconsistent station access and playback • Adding music to a Pandora station then selecting “More Results…” does not function as expected however the behavior in g! is consistent with the behavior of the squeezebox standalone operation.
