Suman eArche PV System Installation Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

eArche PV System

Installation Manual

Table of Contents

Need help?

Do you have a question about the eArche PV System and is the answer not in the manual?

Questions and answers

Summary of Contents for Suman eArche PV System

Page 1 PV System Installation Manual...
Page 2: Table Of Contents
Contents Purpose of this guide Features & Benefits Notices General safety Handling safety Installation safety Fire safety Production Identification Mechanical Installation Grounding Electrical installation Disclaimer of liability Products Data...
Page 3: Purpose Of This Guide
• This guide contains information regarding the installation and safe handling of Sunman (Zhenjiang) Company Limited eArche PV system. Sunman (Zhenjiang) Company Limited referred to as “SUNMAN”. • Installers must read and understand this guide prior to installation. For any questions, please contact SUNMAN’s Customer Service Department “or our local representatives”...
Page 4: Features & Benefits
Features & Benefits • Flexible layouts • eArche PV system can be installed at any shape roofs, which has integrated appearance with buildings. • Maximization installation quantity of eArche at any kinds roof. • Quick installation • Ultra-thin and light to save inatallation labor by a large margin. ©...
Page 5: Notices
Notices This manual contains important installation instructions for the core hardware components required for eArche PV System PV arrays. Copyright and Trademark Information Copyright © 2019 by Sunman (Zhenjiang) Company Limited. All rights reserved. eArche and the SUNMAN logo are trademarks of Sunman (Zhenjiang) Company Limited. Warranty Warnings “WARRANTY VOID IF NON-SUNMAN-CERTIFIED HARDWARE IS ATTACHED TO eArche PV System.”...
Page 6: General Safety
General safety • eArche that fall under this application class may be used in system operation at more than 50V DC or 240W, where general contact access is anticipated. eArche are qualified for safety under IEC 61730-2 and within this application class are considered to meet the requirements for Safety Class II. •...
Page 7: Installation Safety
• Do not attempt to disassemble eArche, and do not remove any attached nameplates or components from eArche. • Do not apply paint or adhesive to eArche’ top surface. • To avoid damage to the front cover and backsheet, do not scratch, “dent” or hit the front cover and backsheet.
Page 8: Fire Safety
• Under normal conditions, a photovoltaic eArche is likely to experience conditions that produce more current and/or voltage than reported at standard test conditions. Accordingly, the values of Isc and Voc marked on this eArche should be multiplied by a factor of 1.25 when determining component voltage ratings, conductor current ratings, fuse sizes, and size of controls connected to the PV output.
Page 9 • For detailed information on the best installation angle, refer to standard solar photovoltaic installation guides or consult a reputable solar installer or systems integrator. • eArche should not be shaded at any time. If a eArche is shaded or even partially shaded, it will fail to perform at ideal conditions and result in lower power output.
Page 10 Confirmation of Measure the size of Preparation of material of color steel color steel roofing bonding material Install chemical Clean the color steel Installation bonding material roofing a. Confirmation of material of color steel • SMD Series to be bonded with PE((Use of the brand: BECKER, VALSPAR, NIPPON, AKZO NOBEL) coating of zinc aluminum plate(Galvalume.
Page 11 following table. SMDxxxM-4X12DW, SMDxxxM-6X12DW, SMDxxxM-6X12UW, SMDxxxM-4X12UW, eArche SMDxxxM-6X10DW, SMDxxxM-4X09DW SMDxxxM-6X10UW SMDxxxM-4X09UW 665mm 995mm Layout of SMD Series • Layout (For Series: SMDxxxM-6X12DW, SMDxxxM-6X12UW, SMDxxxM-6X10DW, SMDxxxM-6X10UW) • Layout (For Series: SMDxxxM-4X12DW, SMDxxxM-4X12UW, SMDxxxM-4X09DW, SMDxxxM-4X09UW) © 2019 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2019A page9 / 18...
Page 12 ▶Note: • Please contact the local distributors if you are not sure whether your color steel roofing is suit for SMD Series or you have any question about this installation method. • Please contact the local distributors if you want to remove SMD Series from your color steel roofing. Quick-bonding Installation ▶For SMA Series SMAxxxM-6X12DW, SMAxxxM-6X10DW, SMAxxxM-4X12DW, SMAxxxM-4X09DW...
Page 13 • Layout(For SMA Series: SMAxxxM-6X12DW, SMAxxxM-6X10DW, SMAxxxM-4X12DW, SMAxxxM-4X09DW, SMAxxxM-6X12UW, SMAxxxM-6X10UW, SMAxxxM-4X12UW, SMAxxxM-4X09UW ) Specifications (mm) (mm) SMAxxxM-6X12DW SMAxxxM-6X10DW © 2019 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2019A page11 / 18...
Page 14: Grounding
SMAxxxM-4X12DW SMAxxxM-4X09DW SMAxxxM-6X12UW SMAxxxM-6X10UW SMAxxxM-4X12UW SMAxxxM-4X09UW Grounding • For grounding and bonding requirements, please refer to regional and national safety and electricity standards. If grounding is required, use a recommended connector type for the grounding wire. • For grounding, this guide refers to module frame grounding. If grounding is required, make sure module frames (metal exposed to touch) are always grounded.
Page 15 For SMA Series Grounding layouts © 2019 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice. www.sunman-energy.com version 2019A page13 / 18...
Page 16 ▶Note: • Pan head tapping screws with cross recessed: ISO 7049-ST 4.2X9.5-F-H GB/T 845-85 – ST Equal 4.2X9.5-F-H • Star washer: DIN 6797-J 4.3 GB/T 861.1-1987 4 Equal • Pan head tapping screws with cross recessed , should be made of Connection terminal and Star washer stainless steel •...
Page 17: Electrical Installation
penetrating the anodized coating of the aluminum frame (see the pictures below). Recommended Pan head tapping screws with cross recessed torque is 1 N•m. Electrical installation • Any hardware used must be compatible with the mounting structure material to avoid galvanic corrosion.
Page 18: Disclaimer Of Liability
recommends periodic inspections of the installation system to maintain optimal eArche’ performance. • The DC current generated by photovoltaic systems can be converted into AC and fed into a public Grid. As local utilities’ policies on connecting renewable energy systems to the Grids vary from region to region.
Page 19: Products Data
Products Data Max.series Series Products Dimensions Weight Fuse Rating quantity SMD355M-6X12DW 39.5 8.99 48.1 9.51 1979mm X 1019mm X 5.6mm 6.5kg SMD350M-6X12DW 39.2 8.93 47.9 9.46 1979mm X 1019mm X 5.6mm 6.5kg SMD345M-6X12DW 38.9 8.87 47.7 9.41 1979mm X 1019mm X 5.6mm 6.5kg SMDxxxM-6X12DW SMD340M-6X12DW...
Page 20 SMA340M-6X12DW 38.6 8.81 47.5 9.36 1955mm X 995mm X 35mm 8.9kg SMA335M-6X12DW 38.3 8.75 47.3 9.31 1955mm X 995mm X 35mm 8.9kg SMA330M-6X12DW 38.0 8.69 47.1 9.22 1955mm X 995mm X 35mm 8.9kg SMA325M-6X12DW 37.7 8.63 46.9 9.13 1955mm X 995mm X 35mm 8.9kg SMA295M-6X10DW 32.8...
