- Page 1 Maxi 3200 Coin box Operating instruction...
- Page 2 Important: For safe and proper use, read the instructions for use and further product-related documents carefully and keep it for later use! For errors, technical errors, printing errors and incompleteness, we assume no liability.
- Page 3 Holtkamp Electronics MAXI 3200 techn. stand 09.2017 4025_09.2017 V09.2019 S ü d s t r a ß e 4 0 / D- 4 9 0 8 4 O s n a b r ü c k info@holtkamp.de / www.holtkamp.de EU-Konformitätserklärung / European Union conformity explanation Für das nachfolgend bezeichnete Erzeugnis / For the following designated product...
-
Page 4: Table Of Contents
Holtkamp Electronics MAXI 3200 techn. stand 09.2017 4025_09.2017 V09.2019 Content 1 Legal information ..................................5 2 Warranty ....................................5 3 Safety notices ....................................5 4 Notes on cleaning and maintenance ............................5 Change battery .................................. 5 5 Spezific data ....................................6 6 General data .................................... -
Page 5: Legal Information
Holtkamp Electronics MAXI 3200 techn. stand 09.2017 4025_09.2017 V09.2019 Legal information Warranty All rights reserved. No part of this manual may not be reproduced or copied in any form without permission of Holtkamp Elektronik On the function of the device is granted for a period of 12 months. GmbH. The rights for contained software in control and memory The warranty is limited solely to technical defects of the unit, it blocks are exclusively from the manufacturer. The reading and can´t be accepted further claims. Further apply our general terms copying of the program content is strictly prohibited. and conditions, stand of June 2011, for products and services of The Holtkamp Elektronik GmbH is not liable to the purchaser of the electrical industry (ZVEI) - also see website: www.holtkamp. this product or third parties for damages, losses, costs or ex- penses caused by the buyer or any third party due to accident, Any liability extinguished by the manipulation of the device. misuse or unauthorized alterations, repairs or improvements. -
Page 6: Spezific Data
Holtkamp Electronics MAXI 3200 techn. stand 09.2017 4025_09.2017 V09.2019 Spezific data Write down the following data: Key number ( imprint on the key Number of identification from device ( see bookkeeping-statistic menu Commission (name customer) Trader (via which the device was purchased) General data Casing material Galvanised steel plate 1,5 mm Casing color Powder-coated white RAL 9016 Color design foil yellow orange Design foil from customer on request Dimensions h 255 mm x w 170 mm x d 135 mm Weight ca. 4,0 kg... -
Page 7: Illustration
Holtkamp Electronics MAXI 3200 techn. stand 09.2017 4025_09.2017 V09.2019 Illustration Illustration of device Housing-lower part Coin acceptor Coin slot Reject button for coins* Coin reject Coin box Removel of coins Lock Button for accounting-statistics menu Front plate LED-Display Design foin (standard) * (Special equipment) You can used the rejcet button for coins as door opener. -
Page 8: Illustration Of Electronic
Holtkamp Electronics MAXI 3200 techn. stand 09.2017 4025_09.2017 V09.2019 Illustration of electronic Circuit board MM-V99-1 230 V~ DIP switch for price settings Connection for coin barrier Connection for mechanical hour counter Connection for mechanical impulse counter Connection for free use Connection for account statistic menu button Elektrical connection Fuse circuit board Battery 3V CR 2032 DIP switch for time settings (see chapter 4) Conntection for short time button Remote start Connection for time stop Delete entrance Connection for coin acceptor... -
Page 9: Installation
● The device is cabled by means of threaded metric threads on the bottom or rear. ● With counters with 230V is necessary the connection of the protection-leader and with counters with 24V is required the ● The MAXI 3200 corresponds to the protection-type IP20 protection-ladder as function-earth. and can be used only in dry rooms/areas.. ● The floor must antistatic and conductive, that not statically ● The MAXI 3200 must be installed vertically and horizontally loads. - Page 10 Holtkamp Electronics MAXI 3200 techn. stand 09.2017 4025_09.2017 V09.2019 Connection 230V~ Connection 24V~ MAXI 3200 MAXI 3200 230V~ 24V~ Remote start Remote start Connection 230 V Remote start (potential free) Lead blinding to PE clamp! Connection lead - 10 -...
-
Page 11: Operating The First Time
Holtkamp Electronics MAXI 3200 techn. stand 09.2017 4025_09.2017 V09.2019 Operating the first time A manipulation is recognized deletes the MAXI the coins thrown If the MAXI is installed can through switches on the stream. The time-counter is now operational and can become program. Plea- in until then and breaks off the use. The manipulation was store se test the programming through a test-sprint. After this test, you in accounting statistic menu, as mistake. If a mistake happens, the MAXI blinks. Through call up the accounting statistic menu should delete the readings to get about a correct bill. The MAXI has protection a sabotage the were active if the contact of the you can finish the blink. -
Page 12: Programming
Holtkamp Electronics MAXI 3200 techn. stand 09.2017 4025_09.2017 V09.2019 Programming 10.1 Explanation the Programming The MAXI offers the possibility, to make the adjustments of the values over DIP switches (see illustration). DIP 1 DIP 2 DIP 3 DIP 4 DIP 5 Special- Pre-run Main time Run-out Price function time time 10.1.1 Special function (time meter - DIP 1 DIP 1: Switch 1 "ON"... -
Page 13: Adjustment Main Time (Dip 3)
Holtkamp Electronics MAXI 3200 techn. stand 09.2017 4025_09.2017 V09.2019 10.1.3 Adjustment main time (DIP 3) The main time is the operating time of the connected device, which can be bought with coins. It can be adjusted until maximal 225 minutes for each payment. Buying the main time more than ones is possible, and there happens an add up to maximal 25 main times. The adjustment of the main times is doing over the... -
Page 14: Bookkeeping-Statistic Menu
Holtkamp Electronics MAXI 3200 techn. stand 09.2017 4025_09.2017 V09.2019 Bookkeeping-statistic menu Open: Statistic 11.1 Inquiry schema - delete the statistics Impulse counter quantity of coins Operation hours counter full hours You came into the statistic menu, if you remove the coin removal and push the red button. That is on the upper left side in the coin- insert-box. Pushing this button, activated the following statistics. -
Page 15: Not Programmable Special Equipments
Holtkamp Electronics MAXI 3200 techn. stand 09.2017 4025_09.2017 V09.2019 Not programmable special equipments 12.2 Connection for time stop 12.1 Contactor 2 x 20 A The extra connection for time stop offers the possibility, to inter- The contactor offers the possibility, to increase the switching po- rupt the main time count-down with an external switch (e.g. flow wer of the MAXI. If you have ordered your MAXI with a contactor, sensor). If your MAXI has been ordered with an extra connection it will be installed on the SB frame inside on the rear wall of the for time stop, you will find on the SB frame, on the inside rear casing. -
Page 16: Short-Time Button
Holtkamp Electronics MAXI 3200 techn. stand 09.2017 4025_09.2017 V09.2019 12.6 Short-time button 12.7 Delete entrance The short-time button offers the possibility for example by using The delete-entrance offers the possibility bought time or rest the coin reset-button to open the washing machine door to turn time to delete with the potential free contact. You find this extra the connection appliance on for 30 seconds. After using this connection on the SB frame on the inside rear wall of the casing. short-time button the functions is not useable for 3 minutes. 12.8 Coin barrier The coin barrier offers the possibility to block the coins, e.g. if the... -
Page 17: Special Errors
Holtkamp Electronics MAXI 3200 techn. stand 09.2017 4025_09.2017 V09.2019 13.2 Special errors 4 points in the display of the MAXI 3200 are flashing and this In the below list you can see, what is behind the code. If you go to means, there is a special error. Under point 7 in the book- the bookkeeping-statistics menu the flashing is automatically off. keeping-statistics menu you can read out the error number. - Page 18 Holtkamp Electronics MAXI 3200 techn. stand 09.2017 4025_09.2017 V09.2019 - 18 -...
- Page 19 Holtkamp Electronics MAXI 3200 techn. stand 09.2017 4025_09.2017 V09.2019 Index Adjustment main time Safety notices Adjustment pre-begin time Short-time button Ádjustment price Special equipments, not programmable Adjustment run-out time Special errors Special function Specifications Spezific data Battery change Bookkeeping-statistic menu Time stop Change battery Cleaning Coin barrier Warranty Connection for time stop Contactor 2 x 20 A Current-dependent time stop...
- Page 20 For technical information during our business hours: Monday - Thursday 8.00 a.m. - 16.00 p.m. and Friday 8.00 a.m. - 13.00 p.m. choose: +49 541 97120-0 or visit our homepage: www.holtkamp.de Technical Stand 09.2019 / We reserve the right to technical changes in the production and technical developments. Südstraße 40, D-49084 Osnabrück Phone: +49 541 97120-0 info@holtkamp.de...
