CA6
Quick Reference Guide
■Home screen
Splice program
Heater program
Control panel
Display the Settings panel
Power source type
Change image view
Display/Non-display icons
Start the splicing process
■Settings panel
To display the Settings panel, tap the
Settings panel icon (
SD
Power Time
Home Screen icons
) on Home screen.
Heater panel
Heater
Start and cancel
heating cycle
Start the heating process
View splice data after splicing
Adjust the zoom of a fiber image
Adjust display brightness
Capture a fiber image
Settings panel icons
Display the menu screen.
Set up Splice Program.
Set up Heater Program.
Log
mode by entering passcode.
Adjust the volume.
Perform an arc test.
Using Keypad
Reset
Set
Power ON/OFF
in
to
Administrator
