Summary of Contents for HUBBELL LIGHTING Dual-Lite Trident TRF Series
- Page 1 ® Dual-Lite Trident TRF Battery Cabinet 10kVA (UL924 System) 10-30kVA (Alternate Runtimes) USER MANUAL 003-2608...
- Page 2 Dual-Lite. Dual-Lite reserves the right to modify the product described herein, in order to improve it, at any time and without notice. For technical assistance, contact Dual-Lite’s Technical Support Center at 1-800-848-6439. Technicians are available during normal working hours (EST). Hubbell Lighting, Inc 701 Millennium Blvd Greenville, SC 29607 Web site: www.dual-lite.com/...
- Page 3 Safety Warnings IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS This manual contains important instructions that you should follow during installation and maintenance of the battery cabinet. Please read all instructions before operating the equipment and save this manual for future reference. READ AND FOLLOW ALL SAFETY INSTRUCTIONS a.
- Page 4 DANGER This battery cabinet contains LETHAL VOLTAGES. All repairs and service should be performed by AUTHORIZED SERVICE PERSONNEL ONLY. There are NO USER SERVICEABLE PARTS inside the battery cabinet. WARNING This battery cabinet contains its own energy source (batteries). Hazardous voltage may be present even when the battery cabinet is not connected to a power source.
-
Page 5: Table Of Contents
CONTENTS Safety Warnings ......................... iii 1 Layout ............................. 1 1.1 Introduction ........................1 1.2 Layout ..........................1 1.3 Battery Life ........................2 2. Battery Cabinet Setup ......................3 2.1 Inspecting the Equipment ....................3 2.2 Floor Loading ........................3 2.3 Clearances ........................3 2.4 Unloading the Cabinet(s) .................... -
Page 6: Layout
1 Layout 1.1 Introduction The Extended Run Time Battery Cabinet is used in conjunction with the uninterruptible power supplies (UPS) to prevent loss of valuable electronic information and minimize equipment downtime. During brownouts, blackouts, and other power interruptions, batteries provide emergency power to safeguard operation. -
Page 7: Battery Life
1.3 Battery Life The batteries in your Dual-Lite UPS system were shipped from the factory fully charged. If you plan to place the batteries in storage for any period of time prior to installation and startup then the following precaution should be followed. Batteries placed in storage will age. -
Page 8: Battery Cabinet Setup
2. Battery Cabinet Setup This SECTION describes: Equipment inspection Floor loading and clearances Removing and replacing the cabinet panels Unloading the cabinet(s) 2.1 Inspecting the Equipment If any equipment has been damaged during shipment, keep the shipping and packing materials for the carrier or place of purchase and file a claim for shipping damage. -
Page 9: Unloading The Cabinet(S)
2.4 Unloading the Cabinet(s) The following tools are required for unloading the cabinet(s): Wrenches for 3/8” bolts Forklift CAUTION The battery cabinets are heavy (see Table 2). Unloading the cabinets requires at least two people to safely remove the cabinets from the pallet. To remove the battery cabinet from the ship pallet: 1. - Page 10 Remove and discard 3/8" bolt and washers (6) places Pull (2) shipping brackets away from cabinet. Remove and discard 3/8" lag bolts (6) places Remove and discard 3/8" bolt and washers (6) places Figure 3 - Shipping Bracket 6. Remove the front cover (see Figure 6) before inserting the lifting forks. 7.
-
Page 11: Placing The Cabinet
Figure 4 - Lifting Fork Area 11. Reinstall the front cover. 12. Roll the cabinet to the desired location. 13. Do not move the cabinet to another location by forklift as the cabinets are heavy may fall. Do not tip the cabinet more than 15 degrees from vertical. 2.5 Placing the Cabinet Once the cabinet has been rolled into position, remove the front panel to access the front leveling feet by pulling the panel outward at the bottom of the unit until it unsnaps and then lift... -
Page 12: Electrical Installation
3. Electrical Installation The Extended Run Time Battery Cabinet has the following power connections: TB1, 3 pole (positive, neutral, negative) terminal block and ground connection for battery power input. This goes to the UPS or to the next battery cabinet closer to the UPS. ... - Page 13 To replace the panel: Lower the shoulder screws at the top and bottom of the panel into the keyhole slots on the cabinet. Figure 6 - Removing the UPS Front Panel If the optional circuit breaker is included, switch it to the “OFF” position. Remove the inner front cover by removing the (10) ten screws mounting it to the enclosure.
- Page 14 16.34 [415.0mm] POWER CABLE ENTRY 4.40 [111.8mm] 5.25 [133.4mm] X 1.75 [44.5mm] 2.44 [61.9mm] (2) SWIVEL CASTERS (2) RIGID CASTERS (4) LEVELING FEET CONTROL CABLE ENTRY 1.75 [44.5mm] X 1.75 [44.5mm REAR Figure 7 - Bottom View of Cabinet BATTERY FUSES BATTERY CIRCUIT BREAKERS BATTERY BREAKER -B VERSIONS ONLY...
-
Page 15: Connecting To The Extended Battery Cabinet
3.2 Connecting to the Extended Battery Cabinet To be performed by authorized service personnel: Inspect battery trays for signs of damage. Verify that all terminal connections are sound. The red and black “powerpole” connectors will be connected, but the blue and white connectors on the wires joining the trays in the string should not be connected. - Page 16 Before working within the UPS cabinet, verify that the UPS has no power applied. Before touching the Extended Run Time Battery connector in the UPS, verify that all internal battery strings are disconnected (that is, verify that the blue and white “powerpole”...
-
Page 17: Circuit Breaker Interface
4. Circuit Breaker Interface NOTE: Disregard this section if tripping the battery cabinet breakers via REPO activation is not required. Figure 9 shows the location of the Battery Breaker Interface terminal block on the battery cabinet. NOTE: Wires to the Battery Breaker Interface terminal block TB4 must not enter the UPS or battery cabinet through the same port as the input/output or battery power wires. -
Page 18: Battery Removal, Installation, And Service
5. Battery Removal, Installation, and Service The batteries must only be serviced by authorized service personnel. Always wear eye protection and have eye wash near at hand. Never work on any connections that have not been disconnected from all other sources of voltage. Parallel connected battery cabinets require that all battery strings in all battery cabinets be disconnected before working within any particular cabinet. - Page 19 WARNING It is very important that only one tray at a time be extended from the cabinet. If more than one tray is extended, the cabinet can become unstable and topple over. After each tray is installed or serviced, it must be fully inserted and secured using the supplied threaded fasteners before attempting to install or service another tray.
-
Page 20: Maintenance
Maintaining proper ambient temperature usually requires installing the product in a temperature controlled space. Equipment rooms without cooling systems do not generally maintain the proper conditions for good battery life. See Hubbell Lighting’s website for warranty details: http://www.hubbelllighting.com/resources/warranty/ Page | 15... - Page 21 Figure 13 – Cabinet Schematic Page | 16...
- Page 22 Notes: Page | 17...
