SMS L7010PNLSTAND1 Manual

Stand system for professional monitor

Advertisement

Quick Links

Stand system for professional monitor
Stativsystem für professionelle Bildschirme
L7010PNLSTAND1
Installation and Adjustment manual/Montage- und Einstellungsanleitung
M000050-L7010PNLSTAND1

Advertisement

loading
Need help?

Need help?

Do you have a question about the L7010PNLSTAND1 and is the answer not in the manual?

Questions and answers

Summary of Contents for SMS L7010PNLSTAND1

  • Page 1 Stand system for professional monitor Stativsystem für professionelle Bildschirme L7010PNLSTAND1 Installation and Adjustment manual/Montage- und Einstellungsanleitung M000050-L7010PNLSTAND1...
  • Page 2: Speci Cations

    - Be careful with the ngers while touching the pillars due to risk of injury. A correct mounting is extremely important and this is not the responsibility of SMS Smart Media Solutions. - Faulty mounting may result in injury to persons or damage to equipment. SMS will not be responsible in any way if the product has been mounted incorrectly.
  • Page 3 L7010PNLSTAND1 How to read this manual/Verwendung dieser Bedienungsanleitung Symbols: 1. Important symbol denotes measures/information that it is important to follow. 2. Triangle symbol denotes a situation that requires caution. 3. Prohibitory symbol denotes measures that must not take. 4. Mandatory symbol denotes measures that you must take.
  • Page 4 SMS. The name of the supplier and the date of the purchase must be clearly legible on the receipt. The owner is to pay the cost of returning the product to SMS, while SMS is to pay the cost of returning the product subsequently to the owner.
  • Page 5 L7010PNLSTAND1 Instruction for use/Gebrauchsanleitung Children may use the product only under supervision of an adult. Kinder dürfen dieses Produkt nur unter Aufsicht eines Erwachsenen benutzen. Not for children Nicht für Kinder geeignet Transport When moving the stand always touch Unlock the Caution when passing the hooked monitor due to risk of injury.
  • Page 6 L7010PNLSTAND1 Product Dimensions/Produktabmessungen 1521 1013 Applicable Monitor Dimensions/Abmessungen für geeigneten Bildschirm: SHARP PN-L702B 1648 1702...
  • Page 7 L7010PNLSTAND1 Delivery Content/Lieferumfang...
  • Page 8 L7010PNLSTAND1 List of parts/Liste der Einzelteile M8x20 M8x20 M8x35 M6x12 M8x40 Locking Pin/Verriegelungsstift Wheel Pin/Radbolzen M6x30 M6x16 Plastic Knob/Kunststo noppen M8x20...
  • Page 9 L7010PNLSTAND1 Loose/Lockern! with the 17mm spanner. stand, A, with 8 screws, G1. Leave the Push the wheels, F1, on to the wheel pins. screws a bit loose. Montieren Sie die vier Radbolzen, F2, mit dem 17-mm- Befestigen Sie die beiden Säulen, B, mit Schlüssel am Bodenstativ.
  • Page 10 L7010PNLSTAND1 *Loosen/Lösen Tighten/ Anziehen! Move the shelf down to the track covers and Loosen the four screws, D2. Two at the top and tighten the four screws, J3. two at the bottom. Bewegen Sie die Konsole nach unten bis zu den Lösen Sie die vier Schrauben, D2.
  • Page 11 L7010PNLSTAND1 Slide/Schieben! Tighten/ Anziehen! Secure/ Fest anziehen! Tighten/ Anziehen! Slide the two stop plates,C2, on the screws, G2, Tighten the eight screws, G1, fastening the and tighten all eight screws when the plates are in place. Schieben Sie die beiden Anschlagplättchen, Ziehen Sie die acht Schrauben, G1, die die Säulen...
  • Page 12 L7010PNLSTAND1 “CLICK/ KLICK!” Attach two track covers, H1, with four plastic Mount the two display bars, E, on the monitor knobs, H3, above the shelf. with four screws, E1. Bringen Sie zwei Schienenabdeckungen, H1, Montieren Sie die beiden Bildschirmschienen, E, mit vier Schrauben, E1, am Bildschirm.
  • Page 13 L7010PNLSTAND1 Cut/Sägen! Cut the plastic cover, H4, in two 135mm long pieces, two 185mm long pieces and two 345mm long pieces. Sägen Sie die Kunststo abdeckung, H4, in zwei 135 mm lange, zwei 185 mm lange und zwei 345 mm lange Stücke.
  • Page 14 L7010PNLSTAND1 “CLICK/ Insert KLICK” Cable/ Kabel einführen! Attach Cover/ Abdeckung befestigen! Place the cables in one of the tracks of the pillars. Attach the two long track covers, H2, with plastic knobs, H3. Let the cables pass in to the track on the top of the cover and out in the bottom.
  • Page 15 L7010PNLSTAND1 Disclaimer: We reserve the right to change the design and technical data without any prior notice. Haftungsausschluss: Der Hersteller behält sich das Recht auf Änderungen der Konstruktion und der technischen Daten ohne vorherige Ankündigung vor.
