- Page 1 CARBON MONOXIDE (CO) ALARM THE WORLD’S SMALLEST PLEASE READ THIS USER GUIDE CAREFULLY...
- Page 2 Yellow LED Fault Indicator CAVIUS Carbon Monoxide (CO) Alarm Part Code: 4002-006 Model: 4002-001 Recess Kit Part Code: 11010 Test/Hush PLEASE READ THE USER button GUIDE CAREFULLY BEFORE Sounder INSTALLATION AND RETAIN FOR FUTURE USE. For large text option and maintenance guide visit...
- Page 3 The best locations in your home to install the CO alarm: • Ideally, a CO alarm should be installed in every room containing a fuel-burning appliance. • Near bedrooms and living areas. • On each level of your home. • 1-3 meters away from all fuel burning appliances. • At eye level to allow optimum monitoring of the indicator lights.
- Page 4 Areas where NOT to install CO alarms: • In the immediate vicinity of a cooking appliance. • In an enclosed space e.g. in a cupboard. Placement: • Where it can be obstructed e.g. behind a curtain. The CO alarm is designed to be installed on the wall or a ceiling. • Directly above a sink. • Next to a door or window. • Next to an extractor fan. • Next to an air vent or other similar ventilation openings. • In an area where the temperature may drop below -10°C or exceed 40°C.
- Page 6 Installation of CO alarm: MARK UP USE THE SCREW HOLES ENCLOSED Info: The label on the product WITH A PEN SCREWS AND must not be removed due to PLUGS FOR INSTALLATION important information. Option 1 – Standard base 1. Use the mounting CLICK THE CO ALARM base ring to mark the FIRMLY INTO screw holes on the ceiling.
- Page 7 Option 2 – Recess Kit 2. Using your hole saw (44mm-48mm), cut a hole into the surface. Ensure there CAUTION: 1. Place the Cover Ring on the area where is no wiring or any electrical equipment behind you wish to install the CO alarm, trace around the surface you are drilling your hole into. the inside of the ring. INSERT RECESS KIT MOUNTING BASE INTO THE HOLE AND SECURE WITH SCREWS CLICK THE CO ALARM FIRMLY INTO HOLE SAW THE BASE TO ACTIVATE DRILL REQUIRED. 44mm - 48mm PLACE COVER RING AROUND THE RECESS KIT MOUNTING BASE...
- Page 8 Hush function: Normal mode: Hushing of the alarm is only possible when In normal mode, the POWER indicator under a level of 200ppm. If you cannot (Green LED) will flash every 60 seconds. hush the alarm, please refer to page 16 for Alarm mode: instructions. When a dangerous concentration of CO is When the alarm is under CO alarm warning, detected, the alarm will go into ‘Alarm Mode’. it can be silenced for 10 minutes by pressing It will be indicated by a series of repeated the hush button (which is the entire bottom of tones and the red LED will flash every 0.5 the alarm). seconds. If a battery fault occurs, the alarm can also be silenced for up to 8 hours by a short press on the HUSH button. This function can only be carried out once during a fault.
- Page 9 Test function: If the test passes, the alarm indication will be triggered for one sound sweep and the green After installation and at least once per quarter, LED will flash for 3 seconds. If the test fails, a test your alarm to make sure it is operating fault indication will be given (See page 17). correctly. After the test function is performed, the alarm When the bottom button is pressed the alarm will need to recover for 60 seconds before will sound, once the button is released, the another test can be conducted (to allow the alarm will conduct a self-test of the sensor sensor chamber to resettle). and battery for approximately 9 seconds. The alarm will also conduct a self-test every During this delay all three LEDs will flash 24 hours, which tests for a faulty sensor, drift in sequence. The result of the test will be or short circuit. indicated once the test is completed. TIP: It is safe to cover the sound output hole with your finger during the testing to minimize the sound level emitted.
- Page 10 What to do if the alarm sounds: Fault warnings: • Keep calm and open all doors and Battery fault: When the battery is low the windows. alarm will beep once every 60 seconds and the yellow LED will flash. • If the alarm continues to be activated, then evacuate the premises. Sensor fault: Sensor fault is indicated by two very short beeps every 60 seconds and the • Get medical help for anyone suffering the yellow LED will flash. Your CO alarm will not effects of carbon monoxide poisoning. respond to CO. • Call the appropriate emergency number. End of life: The end of sensor life is indicated by three short beeps every 60 seconds and the yellow LED will flash. Your CO alarm needs to be replaced.
-
Page 11: Maintenance
Maintenance: • When household cleaning supplies or similar contaminants are used, the area • Check if the alarm sounds and indicators should be ventilated. flash properly by pressing the TEST button at least once per quarter. • Please do not expose to rain or moisture, do not knock or drop the detector and • Your alarm should be cleaned once per opening or tampering with the alarm could quarter to remove dust and dirt. It can be cause malfunction. wiped with a damped cloth. Never use Other information: detergents or other solvents to clean the unit. • Never attempt to disassemble the unit or Do not paint the alarm. Note the local country clean inside. regulations regarding CO alarms. -
Page 12: Technical Information
TECHNICAL INFORMATION: VISUAL AND SOUND PATTERNS: Diameter: 40mm Height: 38mm Type of alarm: Type B apparatus with electro- chem ical CO sensor. Battery: Powered by a non-replaceable 3V CR123 Lithium battery with 10-year life (included). IMPORTANT: Do not try to replace the battery. Replace the product if the battery fails. Product Life: 10 years after manufacturing date. Complies to standards: EN50291-1:2018, EN50291-2:2010, EN50270, EN50271, EN60335, RoHs, REACH. Working condition: -10 to +40C, 30 to 95% non-condensing. Storage/Transport: -20 to +50C, 10 to 95% non-condensing. -
Page 13: Information About Carbon Monoxide
INFORMATION ABOUT CARBON MONOXIDE (CO) ALARM CARBON MONOXIDE: This CAVIUS carbon monoxide (CO) alarm is designed and tested to detect CO in General Carbon Monoxide Information: private homes, camping trailers, mobile Carbon monoxide (CO) is known as the ‘silent homes, caravans and boats. It will provide killer’ because it is odourless, tasteless and early warning of the presence of CO. - Page 14 Developed & Manufactured by: Warranty: CAVIUS provides a 10-year warranty against defect in faulty material and workmanship from the date of purchase, on all devices. Julsøvej 16 - DK8600 Silkeborg The warranty applies to reasonable and normal conditions of use cavius.com - info@cavius.com only. It does not include damage as a result of misuse, incorrect Manufactured in P .R.C. installation, accidental damage, neglect, unauthorised deconstruction or dismantling and any airborne or other contamination however this may have occurred. Distributor information: If this product has an acknowledged defect it must be returned to for New Zealand - CAVIUS Nano Ltd. the national CAVIUS distributor at the purchasers cost with the proof of purchase. 58a Poplar Lane, Papamoa 3187, NZ. If the product has become defective within the 10-year warranty, www.cavius.co.nz CAVIUS APS, Denmark will repair or replace the unit without charge and send back to the purchaser, via the national distributor at the for Australia - CAVIUS Australia distributors cost. 14/30 Octal Street, Yatala, QLD 4207, Australia. The guarantee excludes labour costs, freight costs, service costs and any incidental and consequential damages. Do not attempt to repair www.cavius.com.au or service this product as this will invalidate the warranty.
-
Page 15: Carbon Monoxide (Co) Alarm
CARBON MONOXIDE (CO) ALARM THE WORLD’S SMALLEST PLEASE READ THIS USER GUIDE CAREFULLY...
