EcoxGear ECOEXTREME Quick Manual

Waterproof Speaker Case (Model: GDI-AQCSE100 /101/102/103/104/105/106/107/108/109/110)

Specifications

Frequency Range: 160Hz-20,000Hz
Power Source: 3 x AA-size batteries
Dimensions: 7.3" (L) x 4.7" (W) x 2.6" (H)
Weight: 1.06lb
Temperature (Operating): 23°F to 104°F
Temperature (Storage): 14°F to 131°F
FCC Compliance Statement & Warning:
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. The device generates, uses & can radiate radio
frequency energy & if not installed & used in accordance with instructions may cause harmful interference to radio communications. There is no guarantee that interference will
not occur in a particular installation IF this device causes interferecne to radio or television recpetion try one of these measures: reorient or relocate the reciving antenna,
increase seperation between device & receiver, connect the device into an outlet on a circuit different from that to which the receiver is connected, consult a dealer or
expereinced radio / TV technician for assistance. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate the device and/or void the manufacturer's limited warranty.

Introduction

Thank you for your purchase of the EcoExtreme speaker case by ECOXGEAR.
The EcoExtreme is a waterproof and dirt proof case with a built-in amplified waterproof
speaker. The case will hold your MP3 player, cell phone, keys and anything you want to
safe safe from the elements.

Location of Controls

1) Power / Volume Knob: To optimize your speaker's sound set your audio device's
volume (iPod, cell phone, mp3 player etc) between the 70-80% levels. Rotate
the Eco Extreme's volume knob to the right to increase volume. To turn the Eco
Extreme 'off', turn the knob to the left until a 'click' is felt and the LED above the
volume knob turns 'off'.
2) Power LED: The LED above the volume knob illuminates 'on' when the batteries are
in use, even if you do not hear sound from the speaker. To optimize the lifespan of the
batteries turn the EcoExtreme off when not listening to music.

Installing Batteries

1) Open the EcoExtreme and remove the battery door. The battery door is located on
the inside of the EcoExtreme.
2) Insert (3) AA batteries in the battery compartment. Be sure the '+' and '-' of the
batteries are inserted in the same orientation per the picture below and markings on
the Eco Extreme. IMPORTANT: Use new, fully charged & commonly branded batteries.
Improper batteries may result in audio distortion or "hum" from the speaker
3) Replace the battery door.

Listening to your Music

1) Plug the EcoExtreme audio cable into the headset jack of your audio source
(MP3 player, iPod, iPhone or Smartphone)
2) Turn the volume on your audio source up to a normal listening level and choose
'play'. NOTE: The best sound is created by turning the volume up to about the
80 – 90% level. If the volume on your audio source is too low the volume level out of
the EcoExtreme may be too low. If the volume level on your audio source is at 100%,
the EcoExtreme volume may be distorted at high volume levels.
3) Turn the volume on the EcoExtreme to the desired listening level.
ECOEXTREME
Output Power: 3 Watt
Battery Life: 30 + hours with alkaline batteries
Floating payload (MP3 player, keys, documents etc) maximum: 8 ounces
IPX7 Waterproof Rating: water submersion not to exceed 3' depth for 30 minutes
This device has been tested & found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
