LightSymphony LS30034FOB Quick Start Manual

Changing The Key Fuctions

The keyfob is manufactured in two pre-set versions, as shown below.
1 2
4
3
4-Zone
Model LS30034FOB
However, it is possible to convert between these versions by replacing the keys with
the spare button-caps provided. After replacing the button-caps, the new mode must be
programmed by pressing and holding either the two left-hand or right-hand keys
together until the LED lights, as shown below;
OFF ON
1 2
Press and
hold to set
2-zone mode
Environmental Information for Customers in the European Union
European Directive 2002/96/EC requires that the equipment bearing this symbol on the product and/or its
packaging must not be disposed of with unsorted municipal waste. The symbol indicates that this product
should be disposed of separately from regular household waste streams. It is your responsibility to dispose
of this and other electric and electronic equipment via designated collection facilities appointed by the
government or local authorities. Correct disposal and recycling will help prevent potential negative
consequences to the environment and human health. For more detailed information about the disposal of your old
equipment, please contact your local authorities, waste disposal service, or the shop where you purchased the product.
OFF ON
1 2
Master On/Off + 2 Zone
Model LS30032FOB
2
1
3 4
Press and
hold to set
4-zone mode

SPECIFICATIONS

Battery 1 x RC2032
Frequency 434.075MHz
Range 300 meters line-of-sight
Safety Rating Extra Low Voltage
Physical 33 x 60 x 10mm
Ambient Temp. 0°C to +40°C

INTRODUCTION

The Light Symphony keyfob remote control provides simple
remote control over your garden lighting.
This manual provides a basic guide to its functions and assumes
your lighting is now installed and fully working. For more
detailed information on the setting up of the system please refer to
the instructions provided with Light Symphony's other products.
Before using the keyfob please fit a CR2032 battery. The battery
is inserted by removing the 3 screws on the back of the unit and
sliding it into the holder '+' side up.
Please read the section about "System Codes" to reduce the risk
of interference with neighbouring systems.
KeyFob
ISSUE 1.3
COPYRIGHT © PM INTERNATIONAL LTD 2012
