Summary of Contents for General Photonics FPS-002
- Page 1 FPS-002 Fiber Phase Shifter Instruction Note Version 1.1 May 9, 2018 General Photonics Corp. Ph: (909) 590-5473 14351 Pipeline Ave. Fax: (909) 902-5536 Chino, CA 91710 USA www.generalphotonics.com Document #: GP-IN-FPS-002-11 Page 1 of 9...
-
Page 2: Table Of Contents
Table of Contents: SAFETY NOTES........................ 3 Section 1. Specifications: ....................4 Section 2. Overview......................5 Section 3. Operation Instructions:................... 7 Getting started....................7 Operation ......................7 Section 4. Technical Support ................... 9 Document #: GP-IN-FPS-002-11 Page 2 of 9... -
Page 3: Safety Notes
SAFETY NOTES 1. The drive voltage for the FPS-002 can be up to 150V. Be careful when using high voltages. Never touch the cable or connector when electrical power is on. Make sure that the power is turned off when connecting or disconnecting cables. -
Page 4: Section 1. Specifications
Notes: Unless otherwise stated, specifications in this table are for devices without connectors at 23±5°C. 1. From edge of enclosure at input port to edge of enclosure at output port, not including boots or pigtails. Total fiber length including pigtails will be provided in test data for each FPS-002. Document #: GP-IN-FPS-002-11... -
Page 5: Section 2. Overview
Section 2. Overview The FPS-002 is a high speed, long range phase shifter with a range of up to 65π and an operating frequency range of 0 to 20 kHz. It was designed to have a low Vπ both at resonance and off-resonance, so that it can be driven with a standard function generator to achieve phase shifts of a few π, or with a high voltage driver for larger phase shifts. - Page 6 Larger package Figure 2 Mechanical dimensions of FPS-002 Two versions of the FPS-002 package are available. The package size used is chosen for compatibility with the bend radius requirements of the fiber used. Figure 2 shows the mechanical dimensions of the FPS-002 packages, including the size and locations of mounting holes.
-
Page 7: Section 3. Operation Instructions
FPS-002 electrical cable. Make sure that the polarity is correct. Ground the case ground pin (pin 4). Connect input and output fibers to FPS-002. It is important to clean the fiber connectors using industry standard procedures before connecting them. Make sure that the light source is turned off during connector cleaning. - Page 8 70.00 60.00 50.00 40.00 30.00 20.00 10.00 0.00 Frequency (kHz) Input Voltage (Vpp) (c) PM fiber on large frame tested at 1550nm (d) PM fiber on large frame tested at 1550nm Figure 3 Typical performance data. Document #: GP-IN-FPS-002-11 Page 8 of 9...
-
Page 9: Section 4. Technical Support
General Photonics is committed to high quality standards and customer satisfaction. For any questions regarding the quality and the use of the FPS-002, or future suggestions, please contact General Photonics Corporation at (909)-590-5473 (telephone) or (909)- 902-5536 (fax), or by e-mail at support@generalphotonics.com.
