Night Owl
Hand Crafted Tube Guitar Amplifier
Important Information:
1.
Please read all of the information contained in this document.
2.
HUM - Some hum or amplified noise is normal. As the volume is increased
some amplified noise may be noticeable and will be more apparent in a small
quiet room. Additionally, tubes have inherent noise as do resistors. However,
excessive hum (noise) can be caused by electronic devices located near the amp
or on the same circuit such as neon signs, fridges, fluorescent lights, computers,
light dimmers, aquarium pumps, etc. Hum can vary with different outlets,
rooms or buildings.
3.
Do not operate this amp without a speaker load.
4.
This amp is equipped with a 1 Amp Slo-Blo fuse. (I know the controls panel
says 2A Slo-Blo but it's a mistake on the panel and will be corrected in
subsequent builds.) If a problem develops with the amp, the fuse will open and
the amp will not operate until it is replaced. After replacing the fuse, if the amp
does not operate or continues to blow the fuse, the amp needs service.
5.
This amp is fixed bias. If the output tubes are replaced the amp will have to be
re-biased for the new tubes. The bias range resistor will need to be replaced to
set proper bias for the new tubes. This work should be done by a qualified
technician.
15W Combo
VVT Amps
520 University Dr.
Waldorf, MD 20602
240-222-3830
www.vvtamps.com
Advertisement
Table of Contents
Related Manuals for VVT AMPS Night Owl
Summary of Contents for VVT AMPS Night Owl
- Page 1 Night Owl 15W Combo Hand Crafted Tube Guitar Amplifier VVT Amps 520 University Dr. Waldorf, MD 20602 240-222-3830 www.vvtamps.com Important Information: Please read all of the information contained in this document. HUM - Some hum or amplified noise is normal. As the volume is increased some amplified noise may be noticeable and will be more apparent in a small quiet room.
- Page 2 CAUTION RISK OF ELECTRIC SHOCK WARNING: This guitar amplifier contains lethal HIGH VOLTAGE. To avoid risk of INJURY or DEATH from electric shock, do not open the enclosure or remove the back cover from the amplifier. Refer all service work to qualified personnel. WARNING: This amplifier contains Vacuum Tubes.
- Page 3 If you replace your tubes they should be replaced with the same type as originally installed. VVT Amps only guarantees tubes originally installed/delivered with the amplifier. 4. The tolex fabric covering the cabinet should be cleaned periodically with a soft damp cloth.
- Page 4 If the fuse blows again the amp need service. Also, check your input and speaker output cables. VVT Amps wants you to be happy with your amp so, if there are certain tonal characteristics that you desire, we will assist you in those endeavors and make every effort to help you get your mojo.
- Page 5 DAYS from the date of purchase. If a tube fails within the 60 day period, VVT Amps will replace the tube at no charge. The speaker is guaranteed for ONE YEAR. The Cabinet is guaranteed against structural defects for ONE YEAR.
- Page 6 Specifications: Model Name Night Owl – Guitar Amplifier Product Number 909911221984 (Combo) Model Number 11221984-0011 (Combo) Series Night Owl Type All Tube Amp Audio Outpu t 15 Watts into 8 ohms Output Impedance 8 ohms Speakers 1-10 Eminence 1058K (Alnico) or Celestion Ten 30 (Ceramic)
