Summary of Contents for SmartAV MXwall LT V2 P20 Series
- Page 1 MXwall LT V2 4-Input and Up to 12-Output Video Wall Processor and Matrix Switch USER MANUAL Designed and Manufactured in the USA 1-800-284-2131 www.smartavi.com...
-
Page 2: Table Of Contents
OVERVIEW TECHNICAL SPECIFICATIONS_________________________________________________________________ WHAT’S IN THE BOX?________________________________________________________________________ FRONT AND BACK___________________________________________________________________________ HARDWARE INSTALLATION__________________________________________________________________ AVAILABLE CONFIGURATIONS_______________________________________________________________ FRONT PANEL CONTROL_____________________________________________________________________ SOFTWARE INSTALLATION___________________________________________________________________ 8-11 USING THE SOFTWARE______________________________________________________________________ 11-20 CONNECT TO THE NETWORK_______________________________________________________________ SYSTEM ERROR______________________________________________________________________________ USING THE TABLET__________________________________________________________________________ CONFIGURATION FOR 4U AND 2U UNITS____________________________________________________ TROUBLESHOOTING_________________________________________________________________________ TECHNICAL SUPPORT________________________________________________________________________ LIMITED WARRANTY STATEMENT____________________________________________________________ 4-Input and Up to 12-Output Video Wall Processor and Matrix Switch... -
Page 3: Technical Specifications
Technical Specifications MODEL P20 Series P40 Series Classic Size 2U, 3U, 6.5U, 11U, 20U 2.5U, 4U, 6.5U, 11U, 20U Input Interface Number 8/8, 16/24, 36/48, 76/88, 152/176 16/20, 32/40, 36/48, 76/88, 152/176 Output Interface Number 12/8, 18/12, 36/24, 72/60, 144/120 9/8, 18/12, 36/24, 72/60, 144/120 DVI / HDMI / DP / VGA / YPbPr / CVBS / DVI / HDMI / DP / VGA / YPbPr / CVBS /... -
Page 4: What's In The Box
What’s in the box? PART NO. Q-TY DESCRIPTION MXWALL-LT-V2 4-Input 12-Output Video Wall Processor and Matrix Switch CCPWR06 Power supply cord User Manual MXwall LT V2 FRONT MXwall LT V2 BACK 4-Input and Up to 12-Output Video Wall Processor and Matrix Switch... -
Page 5: Hardware Installation
HARDware INSTALLATION 1. Position MXwall LT V2 conveniently and keep it unplugged. 2. Connect displays to the MXwall LT V2 and power on the displays. 3. Connect any video source to the MXwall LT V2. 4. Optionally connect an RS-232 cable from a PC to the RS-232 port on the unit for additional control. 5. -
Page 6: Available Configurations
AVAILABLE CONFIGURATIONS It is easy to create different configurations or modes that are easy to navigate through with the MXwall LT V2. There are endless possibilities. Creating and switching between display modes is simple. The touchscreen front panel, on-screen-display, RS-232, and TCP/IP can be used to switch between modes at will. -
Page 7: Front Panel Control
Front panel control The MXwall LT V2 front panel displays the temperature of the unit in degrees Celsius in order for users to monitor and prevent overheating. Many settings can be changed from the Setup page of the touchscreen front panel by clicking the white bar next to the setting name. -
Page 8: Software Installation
SOFTWARE INSTALLATION 1. Run MXwall_lt_v2_installer_32bit.exe 2. A Setup window will pop open. Select where you would like to save the MXwall LT V2 software. It is recommended that the default installation path be used. Click ‘Next >’. 3. You will be asked to confirm the name of the Start Menu folder. Use the default name or choose a different name and then click ‘Next>‘... - Page 9 SOFTWARE INSTALLATION (continued) 4. You will be given the option to create a desktop shortcut. Then click ‘Next >’ 5. You will be given a prompt to confirm installation of the MXwall LT V2 software. Click ‘Install’ to continue with the installation. 4-Input and Up to 12-Output Video Wall Processor and Matrix Switch...
- Page 10 SOFTWARE INSTALLATION (continued) 6. When the installation is complete a window will appear stating whether the installation was successful or not. Click the ‘Finish’ button to exit or launch the MXwall LT V2 software. 7. The MXwall software needs to adjust some compatibility settings in order to function properly. Right click on the MX-Wall Desktop icon and select “Properties”.
-
Page 11: Using The Software
SOFTWARE INSTALLATION (continued) 8. See the section titled for guidance on specific configuration for each type Configuration for 4U and 2U Units of unit. USING the software Logging In 1. Run the MXwall LT V2 Software Manager. 2. Log in using the default Account Settings. Username: ‘admin’, password: ‘admin’, then click the ‘Login’... - Page 12 USING the software (continued) 2. To connect to the MXwall LT V2 unit over LAN, either manually enter the unit’s IP address in the IP Address bar, or select the magnifying glass search icon which will automatically detect the IP address.
- Page 13 USING the software (continued) To configure the connection settings from the software manager: 1. Click the ‘Connect’ icon in the top navigation bar. 2. Here, choose whether to connect by network or serial port connection, enter the relevant information, then click ‘Set up’. 3.
- Page 14 USING the software (continued) Setting IP Address Statically The IP address of the MXwall LT V2 unit can be set statically from the connection settings window as shown in figure below. Simply enter the desired IP address and then press ‘Modify IP’. Creating Inputs and Views The MXwall software manager represents output screens as a grid.
- Page 15 USING the software (continued) Input Source Pane The various input channels can be managed from the Input Source Management Pane. Each channel number corresponds to the input port number on the back of the MXwall unit. Changing Settings 1. To change video wall settings, click the settings icon in the navigation bar. 2.
- Page 16 USING the software (continued) Creating Layouts and Scenes 1. The MXwall LT V2 allows users to create customizable layouts and then play them as scenes. 2. After creating the desired layout, select ‘Autofill fields’ and then ‘Add’. This will create a layout. 3.
- Page 17 USING the software (continued) Users Permissions To change user permissions, select the ‘Users’ icon in the navigation bar. From this window, user permissions and passwords can be easily changed 4-Input and Up to 12-Output Video Wall Processor and Matrix Switch...
- Page 18 USING the software (continued) Creating Text Overlaps Using text overlaps, you can create customized messages or labels which can be displayed along with specified input source channels. To create a text overlap, right click the desired channel and click “Text Overlap.”...
- Page 19 USING the software (continued) Cropping Source Image To crop the source image for a specific channel, right click the channel’s icon and select “Source Crop”. In this example, Channel 1 has been selected. Here, you can change the start and end XY coordinates for the source image. When finished, click “Confirm”.
-
Page 20: Connect To The Network
USING the software (continued) Changing Channel Names To change the name of a given channel, double left-click the desired Input Source channel and enter the name of your choice. Connect to the network To connect your MXwall to the network, first connect an ethernet cable from your network access point to the RJ45 jack on the back of the MXwall. -
Page 21: System Error
many devices on your network, check your router for available IP addresses before assigning one to your device and then, from the router, consider applying a static lease to the MXwall’s IP address so that it does not change. Connect to the network (continued) VWC_V5.1.exe –... -
Page 22: Using The Tablet
USING the tablet INSTALLATION The MXwall LT V2 tablet software allows for greater flexibility and mobility while using the video wall. The tablet software functions with tablets running Android version 7 and above. Although the MXwall tablet software will work with tablets that use various screen resolutions, it is recommended that you use a 1080p capable tablet for the best user experience. -
Page 23: Configuration For 4U And 2U Units
Configuration for 4U and 2U Units If you have a 2U MXwall, set Machine Type to “2U 2Wins-2” and Single Display to “Max 2 Windows. If you have a 4U MXwall, set Machine Type to “4U 4Wins” and Single Display to “Max 4 Windows. 4-Input and Up to 12-Output Video Wall Processor and Matrix Switch... -
Page 24: Troubleshooting
Troubleshooting No Power • Make sure that the power adapter is securely connected to the power connector of the unit. • Check the output voltage of the power supply and make sure that the voltage value is around 12VDC. • Replace the power supply. No Video •... -
Page 25: Limited Warranty Statement
Limited warranty statement A. Extent of limited warranty SmartAVI, Inc. warrants to the end-user customers that the SmartAVI product specified above will be free from defects in materials and workmanship for the duration of 1 year, which duration begins on the date of purchase by the customer. Customer is responsible for maintaining proof of date of purchase. - Page 26 NOTICE The information contained in this document is subject to change without notice. SmartAVI makes no warranty of any kind with regard to this material, including but not limited to, implied warranties of merchantability and fitness for particular purpose. SmartAVI will not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance or use of this material.
