PC LINE PCL-PCI10 Quick Start Manual

Gigabit PCI Network Interface Card
PCL-PCI10
Hardware Installation:
1. Turn off computer and remove its cover.
2. Insert the contact edge of the adapter card into the connector of any available PCI
Bus master expansion slot. Press the card firmly into the connector to PCI slot.
Please make sure the card's contacts are fully seated in the PCI slot.
3. Install the bracket screw that secures the card to the Computer chassis.
4. Replace the computer's cover.
5. Connect the Gigabit PCI Network Interface Card to the network with Ethernet
Cable.
6. Turn on the computer.
Driver Installation:
The step by step driver installation guide for Windows
found inside the driver CD. Window Vista™ does not require installation driver.
Standard & Specification:
* Data Transfer Rate: 10/100/100Mbps, supports 8K transmit FIFO and 64K receive
FIFO
* Compliant with IEEE 802.3 10Base-T
* Compliant with IEEE 802.3u 100Base-TX
* Compliant with IEEE 802.3ab 1000Base-T
* Protocol: IEEE 802.3x Full Duplex Flow Control
* Power Consumption: 3W
* Interface: PCI specification 2.2 compliant
* Connector: RJ-45 x1
* LED: 10/100 Activity, 1000 Activity
* Dimensions(app.): 119mm(length) x 45mm(width) x 16mm (hight)
* Net Weight(app.): 50g
* Operating Temperature: 0°C ~ 45°C
* Humidity: 5% ~ 95% (non-condensing)
* Storage Temperature: -20°C ~ 70°C
* Supported OS: Windows 98SE, Windows ME, Windows 2000,
Windows XP, Windows XP64bit, Windows Vista
* Regulations: FCC part 15 Class B, CE
GB
®
98SE/Me/2000/XP can be
