Summary of Contents for Accurate Technology Model 9

  • Page 2: Table Of Contents

    Table of Contents 1. Introduction The Projector Purchaser’s Record and Servicing 2. Installation & Setup Quick Setup Installation Consideration Hardware Setup Mounting 2-11 Power Connections 2-14 Source Connections 2-14 Serial Port Connections 2-15 Optical Alignment 2-16 Source Setup 2-24 2.10 Memory Setup 2-26 2.11...
  • Page 3 WARNINGS AND CONSIDERATIONS Before operating the projector for the first time, read all Warnings and Guidelines. Observe and follow all warnings and instructions marked on the projector. The exclamation point within the equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the projector.
  • Page 4 CAUTION: TO PREVENT ELECTRIC SHOCK. DO NOT USE THIS THREE-WIRE GROUNDING PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED. LINE VOLTAGE SELECTION WARNING: SEVERE DAMAGE MAY OCCUR TO THE PROJECTOR IF THE INCORRECT LINE VOLTAGE IS SELECTED.

  • Page 5: Introduction

    * Superior geometry control, contrast, astigmatism and color performance * Contrast Modulation * ASR and ASI to reduce the need for manual display adjustments * Image Shifter Module to help lengthen CRT life (standard on Model 9) * Optional ACON 11 automatic convergence feature Functional Description The projector accepts data/graphics and video input signals from a variety of sources for projection onto flat, curved, or rear projection screens.

  • Page 6: Purchaser's Record And Servicing

    Introduction serviced without accessing the projector's internal circuitry. Projector settings, usually different for different sources, are stored in memory for each individual source. These settings are retained until changed by the user, even if power is removed from the projector. Construction >...

  • Page 7: Installation & Setup

    Step 3 > Connect a Source Connect a source to the projector's built-in RGB input (slot 1) or, for the Model 9, the Image Shifter RGB input (slot 2). Ensure the source is on and properly connected. Step 4 >...

  • Page 8: Installation Consideration

    INSTALLATION & SETUP 2.2 Installation Considerations Careful consideration should be given as to how and where the projection system is installed. Although the projector offers high performance, the final display quality could be compromised if the projector is not installed properly. This subsection discusses the considerations you should make before proceeding with a final installation.
  • Page 9 INSTALLATION & SETUP Screen Type > Screen type is a very important factor when designing a projection system. Inexperienced users or installers should always consult their dealer when deciding on screen type. The following guidelines may be helpful to understand the differences between screen types.
  • Page 10 INSTALLATION & SETUP To summarize, curved screens are better suited for brightly lit rooms where the audience is situated within the viewing cone. Flat screens are best suited when a wide viewing angle is required and ambient room lighting (near the screen) is low. Note: Screen Gain is defined in Appendix A, Glossary.
  • Page 11 INSTALLATION & SETUP Throw Distance The throw distance (projector-to-screen distance) must be determined for every new installation. Throw distance, the distance between the projector's center lens and the center of the screen, is based on screen size. As screen size increases, the distance between the projector and the screen increases.
  • Page 12 INSTALLATION & SETUP To minimize the effects caused by unwanted light from door and aisle ways, carefully choose the position of your projector and screen. Figure 2-3 shows an installation where poor screen placement has allowed too much unwanted light to enter the screen. In figure 2-4 the screen and the projector are positioned so that unwanted light is minimized.

  • Page 13: Hardware Setup

    INSTALLATION & SETUP * For rear screen applications, less space is required if a mirror is used to fold the optical path. * Choose the right screen size for your application: - As screen size increases, magnification increases which reduces brightness. This reduces the contrast ratio, which affects legibility.
  • Page 14 INSTALLATION & SETUP Follow the steps below to convert the keypad to a remote keypad and change its protocol setting. Step 1 Unplug the projector then remove the front top cover to access the built- in keypad. To remove the cover, remove the four screws holding it to the projector, two on the right and two on the left.
  • Page 15 INSTALLATION & SETUP This jumper setting is important if the keypad is configured for remote operation. There are two keypad protocols: A and B. These protocols are available to allow two projectors in the same room to be independently controlled by separate remote keypads. The protocol setting of the keypad must match that set in the projector's Keypad Options menu ( UTIL 6 then 1...
  • Page 16 INSTALLATION & SETUP If the keypad is configured for IR remote operation, make sure the batteries are installed. If it is configured for built-in or wired remote operation, make sure its extension cable is properly connected to the projector. Perform the following keystroke sequences to change its operating settings: To toggle the keypad's protocol setting (A or B), press * BRITE TINT DETAIL then...

  • Page 17: Mounting

    INSTALLATION & SETUP 2.4 Mounting The projector should be mounted after the system design has been established and reverse scan setup (if required) is complete. Front Screen Installations > Floor Mount Mount the projector on a secured table or cart. Position the projector at the chosen room location with the projector pointing towards the center of the projection screen.
  • Page 18 INSTALLATION & SETUP Ceiling Mount Mounting the projector to the ceiling requires the use of a projector ceiling mount fixture. The fixture is shipped from the factory in kit form (with assembly instructions) for assembly and installation by the dealer/installer. For more information, contact your dealer or Accurate Imaging.
  • Page 19 INSTALLATION & SETUP Diffused Rear Screen Systems If the system includes a diffused rear screen, floor mount or ceiling mount the projector so that the image is directed to the center of the audience. Projection tilt should be less than 15 degrees. See Figure 2-13. In situations where the space behind the projector is limited, a mirror may be used to fold the optical path as illustrated in Figure 2-14.

  • Page 20: Power Connections

    INSTALLATION & SETUP 2.5 Power Connection To apply power to the projector, plug the AC line cord into the line input socket located at the front panel of the projector. Plug the three-prong end of the line cord in a grounded AC outlet.

  • Page 21: Serial Port Connections

    INSTALLATION & SETUP The two RGB interfaces provided allow connection of an RGB source having one of the following sync types: sync on green, composite sync, or separate H & V sync. To connect a source, connect the red, green, and blue outputs to the RED, GREEN, and BLUE inputs on the interface.

  • Page 22: Optical Alignment

    INSTALLATION & SETUP If using the projector with a signal switcher, connect an RS-232 serial communication cable between the switcher and the projector serial port labeled ''SWITCHER''. lf the projector is to be controlled by a computer or controller which has an RS-232 serial port, connect an RS-232 serial cable between the computer and the projector serial port labeled ''IN''.
  • Page 23 INSTALLATION & SETUP Step 2 > Case Removal Locate the four screws around the base perimeter of the back portion of the fiberglass case, and the four screws on the base perimeter of the front portion of the fiberglass case. Unscrew these screws, and then gently slide the front cone off, pulling away from the center, straight out.
  • Page 24 INSTALLATION & SETUP For the Model 8/ Model 9 the lenses are secured to the projector frame by a top plate and individual mounting plates as shown in Figures 2-21a and 2-22a. During optical alignment, adjust the top plate securing bolts using the ball nose screwdriver supplied with the projector.
  • Page 25 INSTALLATION & SETUP For the Model 8 and 9, each CRT is attached to its lens by socket head allen screws located at each lens mounting plate. For each lens, the upper left screws (when facing the lens) adjust the focus between the left and right sides of the picture, and the upper right screws adjust the focus between the top and bottom of the picture.
  • Page 26 INSTALLATION & SETUP Step 9 > Press to increase contrast to a normal viewing level. Step 10 > Pivot the projector and move it side to side as necessary to display a symmetrical crosshatch centered left-to-right on the screen. The pivot point should be at the tear wing nut of the green lens to avoid changing the throw distance.
  • Page 27 Step 24 > On the Model 9 locate the two adjustment bolts at the upper right comer of the green lens mounting plate (viewed from the front). Adjust the two bolts until the top and bottom areas of the picture are equally refocused.
  • Page 28 Step 28 > On the Model 9, locate the two adjustment bolts at the upper left corner of the red mounting plate (viewed from the front). Adjust the two bolts until the left and right areas of the picture are equally defocused. Use the same technique as that used for the previous adjustment (step 27).
  • Page 29 Step 31 > On the Model 9, locate the two adjustment bolts at the upper right corner of the blue lens mounting plate (viewed from the front). Adjust the two bolts until the top and bottom areas of the picture are equally defocused.

  • Page 30: Source Setup

    INSTALLATION & SETUP Note: on all models, it may be necessary to readjust the lens' rear wing nut to keep the center defocused. Step 33 > Rotate the blue lens using the rear wing nut until the picture is focused in the center.
  • Page 31 INSTALLATION & SETUP Step 2 > Press CONT then DOWN to adjust the contrast of the image to a suitable level. Step 3 > Press DOWN to adjust electrical focus for best overall sharpness. Step 4 > Press LEFT RIGHT to adjust skew until the vertical line through the center of the image is not tilted (perpendicular to the horizontal line).

  • Page 32: Memory Setup

    INSTALLATION & SETUP Step 10 > Adjust C linearity as follows: Press DOWN until the horizontal line through the center of the crosshatch is equally distant from the lines at the very top and bottom. Press LEFT RIGHT until the center of the crosshatch is equally distant from the vertical lines at the left and right edges.
  • Page 33 INSTALLATION & SETUP Note: Memory setup should be performed when the projector is in its final operating position. If the physical position of the projector changes, memory setup must be repeated. Here is a brief summary of the setup memory, ASR, and ASI discussions in Section 3. About Setup Memories...
  • Page 34 INSTALLATION & SETUP (e.g., a SVGA card). When a source switch is made, the projector may automatically select a Recall memory with matching scan frequencies or create the display settings based on the settings in other setup memories. (Refer to Appendix C for ASI/ASR logic diagrams.) Input Memory Setup >...
  • Page 35 INSTALLATION & SETUP Step 4 Make display adjustments as required. Adjustment changes will automatically be saved in the Recall memory. ASI Improvement > If the projector will be used with many sources, or new sources will be frequently added to the system, it is recommended that five or six setup memories be created expressly for the purpose of improving ASI accuracy.
  • Page 36 INSTALLATION & SETUP (You may notice that as new Recall memories are created, fewer display adjustments are required. This is because ASI is using other setup memories to create the initial settings of the new memories.) ASR Setup > This subsection provides two examples of how the ASR feature may be used and set up.
  • Page 37 INSTALLATION & SETUP Step 4 Press SOURCE 0 then 1 to make Input memory 01 the current setup memory then press UTIL 1 then 5 to display the Clear Setup dialog box. Move the cursor to ''Do It'' then press ENTER to clear the display and frequency settings of the input.

  • Page 38: Image Shifter Setup

    2.11 Image Shiner Setup This section provides setup and usage information about the Image Shifter Module (ISM) which can be installed in slot 2 of the projector (and which is standard on the Model 9). The Image Shifter> The Image Shifter Module (ISM) is an RGB input interface with an image shift feature to help extend the useful life of the projector's CRTS.
  • Page 39 INSTALLATION & SETUP the phosphor is spread out, thus reducing the noticeable effects of ''phosphor burn''. The ISM accepts RGB video signals from a variety of signal types: sync-on-green, composite (not composite video) and separate H & V. Inputs are by way of standard BNC type connections.
  • Page 40 INSTALLATION & SETUP Image Shift Synchronization Inputs & Outputs The ISM'S multi-display synchronization feature is provided for multi-display applications such as a stacked video display wall. This feature allows you to synchronize image shifting amongst multiple ISMS. When used, all display images move both horizontally and vertically at the exact same rate and in the same direction.
  • Page 41 INSTALLATION & SETUP ISM Setup > Set up the ISM as follows: Note: If a new source is connected after the ISM has been set up, setup may again be required for the new source. Step 1 Turn on the projector. With a source connected to the ISM, press SOURCE 0 then 2 select it.
  • Page 42 INSTALLATION & SETUP Step 3 You are now ready to adjust the controls, which shift the image about the raster. First switch the FAST/SLOW switch to the FAST position. Now slowly turn the H RANGE control clockwise. You should notice that the image is moving side to side within the raster.

  • Page 43: Acon Setup

    INSTALLATION & SETUP Slowly adjust the V CENT control to avoid blanking the image. When connecting the ISM, the image may initially appear dimmer than it does when the ISM is not used. Also, if the source being used is sync-on-green, the image may have a greenish appearance.
  • Page 44 INSTALLATION & SETUP Figure 2-29. ACON Installation Examples 2-38...

  • Page 45: Operation

    S e c t i o n 3 OPERATION 3.1 Overview This section explains how to operate the projector once it has been installed and is ready for use. If you have not yet set up the projector, refer to Section 2, Installation and Setup. Before using the projector for the first time, it is recommended that you read through this section of the manual.
  • Page 46 OPERATION Built-in Keypad When the keypad is configured for built-in use (factory default), it is connected to the projector by a 3-foot extension cable, located below the front top cover. This configuration is intended for initial setup of the projector and applications where it is desirable to keep the keypad with the projector.
  • Page 47 OPERATION Figure 3-2 shows the projector functions, which are accessible from the multi- use (full function) keypad. As you may notice from the figure, some keys provide direct access to specific functions (such as POWER to turn the projector on or off), and some keys provide indirect function access via menus.
  • Page 48 OPERATION Keypad Usage > The keypad is used the same way you would use a remote keypad supplied with a TV or VCR. There are only a few general key press rules to keep in mind: Key Press Rules 1) All key presses are in sequence; no functions require simultaneous key presses. POWER STBY are the only keys which require an extended hold-down for...
  • Page 49 OPERATION Slidebars When an adjustment is made, a slidebar is superimposed on the projection screen. The slidebar displays the adjustment setting on a percentage scale. To make an adjustment, use the arrow keys indicated by the sliders. Press EXIT to end an adjustment or, for a sliders accessed from a menu, press ENTER .
  • Page 50 OPERATION Message Boxes Message boxes display brief messages on the screen to indicate a status, condition, or error. Messages are overlayed on the displayed source image and in most cases remain on the screen for about five seconds. To remove a message box prior to the five second display period, press EXIT.
  • Page 51 OPERATION To view help describing a menu, press HELP while the menu is displayed. If multiple pages are available, press HELP to advance to the next page. Press RECALL to go back to the previous page. To end help, press EXIT.
  • Page 52 OPERATION Power-on > To turn on the projector, press POWER on the keypad. Hold POWER down for about one second. lf using an IR remote keypad, point the keypad at the projection screen or the front of the projector. During power-on, the projector proceeds through a series of internal diagnostic tests, which last approximately 9 seconds.
  • Page 53 OPERATION Volume The Volume function is used to adjust the audio output level. To adjust Volume, press VOL then UP DOWN until the desired audio level is attained. System Status Pages> The projector's current operating settings may be displayed by pressing while at presentation level.
  • Page 54 OPERATION 3.3 Source Selection The projector includes a built-in RGB input interface to accept a single input. With optional accessories such as a Multi-standard Decoder, and the use of one or more external switchers, the number of inputs can be significantly increased. Because of this large capability, three source selection methods are available: Input Selection, Direct Channel Selection, and Up/Down Channel Selection.
  • Page 55 OPERATION To select an input. Press SOURCE m n at presentation level. where; m = 0 (projector) or 1-9 (switcher 1, 2, ... 9) n = 1-9 (slot number) The projector switches to, and displays, the source connected to the input selected. The projector also uses the display settings previously set in memory for that input.
  • Page 56 OPERATION Direct Channel Selection> This method of source selection takes advantage of the Channel List feature explained in section 3.7, Utility Features. The Channel List allows you to assign a source to a 2-digit number, from 01 to 99. Once you have assigned channel numbers to your sources, and the projector is at presentation level, you can select a source by pressing the 2-digit channel number associated with it.
  • Page 57 OPERATION Notes: 1) if screen messages are turned off via the Preferences menu ( UTIL 5 then 2 the source message is not displayed. 2) During input selection or Recall memory selection (explained later), the message box displays numeric keypad entries as they occur.
  • Page 58 OPERATION for a high resolution computer output. When display adjustments are made, the new settings are automatically saved in one of the projector's setup memories. There are two types of setup memories: Input and Recall. Both memory types store the same parameters.

  • Page 59: Display Adjustments

    OPERATION To select or create a Recall memory: Press RECALL m n. where: m = the 1st digit of the Recall memory number n = the 2nd digit of the Recall memory number For example, to select Recall memory 01, press RECALL 0 then 1.
  • Page 60 OPERATION Convergence is used to align the red, green, and blue color components of the image. It is described in section 3.6, Convergence Registration. Most adjustment functions, when selected, display a slidebar overlayed on the source image. The sliders displays the current setting and indicates which arrow keys to use for making the adjustment.
  • Page 61 OPERATION To adjust detail, press DETAIL then DOWN until the sharpest display is attained. Detail level should be roughly proportional to input signal quality. Higher levels of detail improve good quality signals. Lower levels of detail reduce noise in poor quality signals.
  • Page 62 OPERATION PIC 2 Size The Size function is used to adjust the horizontal and vertical size of the display image. (This adjustment is also available through the Geometry menu.) To adjust size, select Size from the Picture menu. Two slidebars are displayed: a Horizontal Size sliders and a Vertical Size slidebar.
  • Page 63 OPERATION To toggle between fast and slow sync, select item 5 from the Picture menu. Item 5 indicates the current synchronization mode. PIC 6 Blanking (Top/Bottom/Left/Right) The Blanking selection item is used to hide or blank out unwanted information or noise at the top, bottom, left, or right of the display image.
  • Page 64 OPERATION To modify decoder operation, select Decoder Options from the Picture menu. From the Decoder Options menu, select item 1 to set the decoding method to use for the current source signal input to the decoder. Select item 2 to set the routing of the current source signal within the projector.
  • Page 65 OPERATION About the Accurate Sync Routing System The Accurate Sync Routing System allows various sync and video combinations to be made to the Input 01 or 02 on the VIM. You can connect Video signals with Separate sync (R-G-B-H/C-V), Composite sync (R-G-B- H/C) or Sync-on-Green (R-Gs-B). As well, the routing system allow Composite Video signals to be connected through the Green BNC and routed to the Decoder as long as the Recall (or input) memory assigned to the Composite Video source is set for routing as Composite Video.
  • Page 66 OPERATION 1) If the routing is set to either ''As Composite'' or ''As S-video'' setting ''Auto Clamp'' to ''On'' routes the sync to the DPB from the Decoder. This setting is required for S-video to operate properly. It also allows Composite Video to operate. Setting ''Auto Clamp'' to ''Off'' routes the sync to the DPB from the Sync-on-Green circuitry.
  • Page 67 OPERATION GEOM 3 SIDE PIN The Side Pincushion function adjusts pincushion of the sides of the display image. The two displays shown below demonstrate side pincushion adjustment. To adjust side pincushion, select Side Pin from the Geometry menu then press LEFT RIGHT until the sides of the image are as curved or as straight as desired.
  • Page 68 OPERATION To adjust H bow, select Bow from the Geometry menu then press LEFT RIGHT until the image appears as desired. To adjust V Bow, press DOWN until the center of the picture is as curved or as straight as desired. GEOM 7 C Linearity The C Linearity function corrects for gradual non-linearity between the top and bottom or...

  • Page 69: Convergence Registration

    OPERATION 3.6 Convergence Registration Convergence Registration is the process of aligning the red, green, and blue color components on the projection screen. The projector's convergence system provides accurate color registration in 45 discrete convergence zones configured in a 9 by 5 array on the projection screen.
  • Page 70 OPERATION The following options are available while performing any of the manual convergence routines: Convergence on Image When a convergence method is first selected, an internally generated crosshatch test pattern is displayed. Alternatively, you may override the use of the test pattern and have the external image displayed.
  • Page 71 OPERATION wish to go back to a previous zone, press *. Once all 45 zones have been converged an Exit dialog box is displayed, as shown below. lf you wish to exit prior to converging all 45 zones, EXIT will immediately display the Exit dialog box. Note: CONV My be used instead of...
  • Page 72 OPERATION To change the convergence color, press COLOR. Each press of the Color key changes the color as shown. To move to another control point, press ENTER. The caption above the box changes to ''MOVE''. Use the arrow keys to move to another zone for convergence. Press ENTER converge the zone.
  • Page 73 OPERATION Automatic Convergence - Full, Touchup, and Center Only Options 1, 2 and 3 in the ACON Auto-convergence Menu provide selection of three automatic convergence routines; ACON (full), ACON (touchup), and ACON (center only). lf the image has never been converged or is poorly converged, select option 1, ACON (full).
  • Page 74 OPERATION Error Messages If ACON encounters a problem, which it cannot resolve, processing halts and an error message is displayed. If you encounter an error message, refer to section 4.3, Troubleshooting for assistance. If you are unsure how to resolve the problem, contact your dealer.

  • Page 75: Utility Features

    OPERATION When Manual Learn Screen is selected, a screen is displayed. Use UP, DOWN, LEFT, and RIGHT to move the four black bars to the outside edges of the screen. Initially, the arrow keys control the top and left bars, as indicated by the bottom line of the text box. To move the right and bottom bars, press ENTER then use the arrow keys.
  • Page 76 OPERATION Item 4, Input Memories, displays a listing of the Input memories stored in the projector. Item 5, Preferences, lets you set various operational settings, which affect the behavior of the projector, according to your preferences. Item 6, Remote Control Options, allows you to modify the projector's communication settings for communication with external control devices such as remote keypads.
  • Page 77 OPERATION between ''the two closest'' setup memories. This feature is very useful when adding a new source to the system and/or when much adjustment is required. By using the ''ASI with Save'' feature, the projector can do most of the required adjustments for you. To perform an ''ASI with Save'', press from the Source Setup menu.
  • Page 78 OPERATION other setup memories stored in the projector. The new settings created by ASI are either a copy of the settings from another setup memory which has matching scan frequencies or an interpolation between ''the two closest'' setup memories. ASR is also performed when: - You switch to an input which has ASR set to On.
  • Page 79 OPERATION Example A system has six different sources as shown in Figure 3-7. Source ''A'' is a video camera. Source ''B'' is a VCR. Sources ''C'' through ''F'' are various computers. All sources are connected to a 3rd party (non-Accurate Imaging) signal switcher. The switcher is connected to projector slot 1.
  • Page 80 OPERATION operation is not performed. When the clear operation is complete, the Source Setup menu is returned. Note: Clearing a setup memory does not delete it from the system. If the projector's 80 memory spaces are used up, and you need to delete unused memories to make room for new memories, call your dealer for assistance.
  • Page 81 OPERATION Program a channel as follows: When the Channel List is first displayed, the cursor is positioned in the channel number column. While in the channel number column, press DOWN to highlight the channel you want. Alternatively, you can highlight the channel you want by entering the channel number on the keypad.
  • Page 82 OPERATION The Input Field The Input field contains the switcher and slot number of the input to be switched to when the channel is selected. If the input is a direct projector input, the input number is a 0 followed by the projector slot number. If the input is from a switcher, the input number is a number from 1 to 9 (switcher number) followed by the switcher slot number.
  • Page 83 OPERATION ASR feature is on or off for each memory. A check mark is displayed in the ASR column next to the memories, which may be chosen for use by ASI during an ASR. If two or more Input memories have identical scan frequencies, only the memory last adjusted will have a check mark.
  • Page 84 OPERATION messages will be displayed, such as slidebars, error and warning messages, the SOURCE RECALL PROJ MUTE messages, and the GEOM menus. For most applications, it is recommended that Screen Messages be left on. However, if during a presentation you want to make subtle display adjustments without drawing attention to your actions, Screen Messages should be set to Off.
  • Page 85 OPERATION Two selection items are displayed: Keypad Options and Communication Setup UTIL 6 1 Keypad Options Press from the Remote Control Options menu to display the Keypad Options menu Use the menu to select the keypad protocol type the projector will respond. IR sensor This setting determines how the projector responds to IR remote keypads aimed at the projector' s built-in IR sensor.

  • Page 86: Multiple-Projector Functions

    OPERATION Remote Jack This setting determines how the projector responds to devices connected to the REMOTE Jack on the projector's rear panel. This jack can accept input from a wired keypad or remote IR sensor. Four settings are available: A or B, A, B, and Off. lf set to A, the projector will only respond if the keypad using the REMOTE jack is set for protocol A operation.
  • Page 87 OPERATION UTIL 7 1 Set Clock Press from the Clock/Events menu to display the Set Clock menu. Use the menu to set the current time and date and their format. Time To edit the time stored in the real time clock/calendar, press from the Set Clock menu.
  • Page 88 OPERATION UTIL 7 2 Programmable Events Press from the Clock/Events menu to display the Programmable Events feature box. The Programmable Events feature box allows you to program a list of up to twelve events to occur at specified times and intervals. For example, you can program the projector so that at the same time each day, standby mode is turned off and Source 01 is displayed.
  • Page 89 OPERATION The Type Field The Type field shows the event to take place. With the cursor positioned on the Type field press ENTER to cycle through the available events. Press to clear the entire event line. Events are described in Table 3-1 below. The Interval Field The Interval field shows a date or interval at which the event is to take place.
  • Page 90 OPERATION The Start Field The Start field shows the start time of the event. With the cursor positioned on the Start field use the number keys to enter the start time. Use the notation previously defined by the Set Clock utility (12 hour or 24 hour). If using a 12 hour clock, press ENTER toggle between a.m.
  • Page 91 OPERATION To use this feature, a number of video sources must be fed to the projector or a connected switcher. Each source is assigned to a channel in the Channel List. The U/D status of each of these channels must be enabled in the list - see the Channel List entry in this section for details.

  • Page 92: Maintenance

    S e c t i o n 4 Maintenance 4.1 Warnings and Guidelines The Accurate projection system is CSA approved and is designed for safe and reliable operation. However, safe operation cannot simply be assured by design; installers, maintainers, and users must maintain a safe operating environment for the system. This section covers warnings and guidelines, which promote the safe usage of the projector.

  • Page 93: Cleaning

    MAINTENANCE Operate the projector at the voltage indicated on the line voltage indicator. Do not overload power outlets and extension cords as this can result in fire or shock hazards. The projector is equipped with a three wire plug having a third (grounding) pin. This is a safety feature.

  • Page 94: Troubleshooting

    MAINTENANCE Case Cleaning > Clean the case with a soft dampened cloth. Use a mild commercial cleaner. Do not use liquid or aerosol cleaners. ACON Cleaning > The lens on the ACON Locator Assembly is very tolerant to dust and should only be cleaned if ACON performance is affected.
  • Page 95 MAINTENANCE Symptom: The projector's green POWER LED is lit and all other LEDS are off yet no picture is displayed. Cause/Remedy:1) Contrast or brightness may be set too low. Press to activate the status screen. If there is no display, press then increase contrast ( CONT ) and brightness...
  • Page 96 MAINTENANCE Symptom: The display is jittery or unstable. Cause/Remedy: 1) The horizontal or vertical scan frequency of the input signal may be out of range. Check the specifications in Section 5 for scan frequency ranges. 2) Synchronization signals from the source may be inadequate. Correct the source problem.
  • Page 97 MAINTENANCE 3) The projection room walls and ceilings may be too reflective. Reflective ceilings, walls, and floors should be kept to a minimum. The best projection rooms are dark with matte finishing. 4) The projector may be too far from the screen. 5) The location of the audience with respect to the screen may not be adequate.
  • Page 98 MAINTENANCE Symptom: The display is not rectangular in shape. Cause/Remedy:1) The geometry settings may not be set correctly. Adjust the display geometry settings. (Press GEOM for the Geometry menu). Symptom: The display is ''noisy''. Cause/Remedy:1) The input may not be terminated. Make sure the input is terminated (75 ohms).
  • Page 99 MAINTENANCE * Has a Learn Screen been performed since the last projector configuration change? Learn Screen must be performed if: - The throw distance has changed since the last time Learn Screen was performed. - The ACON Locator Assembly mounting position has changed since the last time Learn Screen was performed.

  • Page 100: Specifications

    - Liquid coupling for optimized contrast ratio Resolution > 2500 x 2000 addressability - 1500 x 1200 ANSI pixels for Model 9, 1350 x 1100 for Model 8 Brightness > Usable brightness per industry standard: Model 8 = 235 ANSI lumens...

  • Page 101: Specifications

    SPECIFICATIONS Frequency Response > 120 MHz bandwidth (-3 dB) - Accommodates 3 nanosecond pixels and digital clock rates over 300 MHz DC Restoration > Keyed clamp, better than 1% Geometry Distortion > - Horizontal: 2.0% maximum Vertical: 1.0% maximum Deflection Circuits> - Smartlock circuitry for quick lock-in and ultra steady images Vertical Deflection...
  • Page 102 - Can be ceiling mounted on its optional ceiling mount or placed on a cantered cart for portable applications Weight > Model 9 Model 8 - 176 lbs / 80 kg - 143 lbs / 65 kg - 229 lbs / 104 kg (shipping weight)
  • Page 103 SPECIFICATIONS Regulatory Approvals > - FCC Class A, DHHS and HWC requirements, EN55022 Class B - CSA/UL/EN 60 950 - EU Directives 73/23/EEC, 89/336/EEC (CE marked) Further information > Proceed to the Accurate website for further technical diagrams and documentation.
  • Page 104 Physical Dimensions >...
  • Page 106 A p p e n d i x Glossary This appendix defines many of the terms used in this manual as they apply to the Accurate projection system. ACON (Automatic Convergence)> ACON is an optional automatic convergence feature available for Accurate series projectors.

  • Page 107: A Glossary

    GLOSSARY Bow > A horizontal curve in the center of the image, and/or a vertical curve across an image. Brightness > Brightness in projection usually describes the amount of light emitted from a surface such as a screen. Brightness is measured in lumens, foot-lumens, foot-candles, or lux. Candela or Candle >...
  • Page 108 An optional interface module which can lengthen CRT life while maintaining a bright picture by slowly shifting the image about the CRT faceplate. Image shifting occurs both horizontally and vertically. Shift range is totally controllable by the user. NOTE: Standard on the Model 9.
  • Page 109 GLOSSARY Input Memory > A setup memory which is associated with a particular projector or switcher input. Interface > A device that accepts an input signal for display by the projector. Interlace > A method used by video tape players and some computers to double the vertical resolution without increasing the horizontal line rate.
  • Page 110 GLOSSARY NTSC Video > A video output format of some video tape and disk players. There are two types of NTSC (National Television Standards Committee) video: NTSC 3.58 and NTSC 4.43. NTSC 3.58 is used primarily in North America and Japan. NTSC 4.43 is less commonly used. Optical Screen >...
  • Page 111 GLOSSARY RGB Video > The video output of most computers. It can be analog or digital. Analog RGB video has 3, 4, or 5 wires; one for red, one for green, one for blue, and none, one or two for sync. For three wire RGB, the green wire usually provides sync.
  • Page 112 GLOSSARY Vertical Frequency > The frequency at which images are generated. Vertical frequencies vary amongst sources. This term is also called vertical scan rate. Video > The signal that is used by display devices (such as projectors) to generate a picture. This term also refers to the output of video tape/disk players and computers.
  • Page 113 A p p e n d i x B...
  • Page 129 F-10...
  • Page 131 Index-1...
  • Page 132 Index-2...
