Musical Air Horn
BH1
BH2
INTENTION FOR USE
Thank you for purchasing this Musical Compressor Air Horn from Streetwize. This car accessory
kit is designed to be mounted inside your vehicle's bonnet and wired to your vehicle's 12V battery
and horn switch so that it replaces the sound & tone of your vehicle's factory fitted horn.
This product can be fitted to cars, vans, caravans and motorhomes.
This product should NOT be used for anything other than its intended purposes.
To get best use out of this product, please read all information in this document.
Important: Installation of this product requires sufficient knowledge and experience
of electrical wiring in automotives. If you do not possess this knowledge, we highly
recommend that you seek assistance from a competent professional.
Dixie
La Cucaracha
BH1/BH2
Advertisement
Table of Contents
Summary of Contents for Streetwize Dixie BH1
- Page 1 La Cucaracha INTENTION FOR USE Thank you for purchasing this Musical Compressor Air Horn from Streetwize. This car accessory kit is designed to be mounted inside your vehicle’s bonnet and wired to your vehicle’s 12V battery and horn switch so that it replaces the sound & tone of your vehicle’s factory fitted horn.
- Page 2 Product Elements • 5 x horn trumpets • Compressor • Plastic air tubing • Relay • Fixings and bolts • Coil Clips Mounting Instructions 1. Carefully remove all the components from its packaging. 2. Find a suitable location for installing the compressor in your vehicle’s bonnet.
- Page 3 Connecting The Air Horn To 12V Battery & Horn Switch Before outlining the electrical wiring instruction, first please be aware of the two types of horn switches. Connecting to the Vehicle’s Factory Horn Switch 1. There are two types of horn switches: one with a single terminal and the other twin terminal. 2.
- Page 4 4. Connect the relay terminals 30/86 to the positive terminal of your vehicle’s 12V battery. When doing so, we recommend you also connect a 20Amp fuse as shown in Figure 4. 5. Once installed, test the horn to ensure proper operation. 6.
- Page 5 Streetwize: Ashburton Road West, Trafford Park, Manchester, M17 1RY For Product Support: For Trade Enquiries: E: support@streetwizeaccessories.com E: sales@streetwizeaccessories.com T: +44 (0)161 447 8597 T: +44 (0)161 447 8580 www.streetwizeaccessories.com EU Registered Address: Ace Supply Co (Europe) Ltd, 25 Herbert Place, Dublin 2,...
