BELLAGIO 881.21.001.00 Assembly Instruction

CAUTION:
1. Please read these instructions carefully before assembly. count and organize all parts before you begin.
2. Assemble product on a clean and soft surface, such as a piece of carpet, so as to prevent the surface
paint of parts from scratching off.

ASSEMBLY:

1. Attach the legs to the table top using M8 headless screws, flat washer M8, spring washer M8 and nut
M8. Do not tighten at this stage.
2. First attach the long connecting to the table leg using M8 headless, flat washer M8 spring washer (S)
M8 and nut M8, then fix the long connecting rings to the legs together with the short connecting ring.
Do not tighten completely at this stage.
3. Put the assembled table on a flat surface and then put the knighthead, after that tighten all the screws
and nuts.
4. Put the bolt cap onto the nut..
5. Fix the adjustable foot pads under table legs to ensure the table is level.
PARTS&HARDWARE LIST
NO. DESCRIPTION
A TABLE TOP
B LEG
C Connecting
D Adjustable foot pads
E M8 headless screws
F Flat Washer M8
G Spring Washer M8
H Nut M8
I Bolt Cap
(Aluminum is soft metal, over tightening may strip thread or break parts)
ASSEMBLY INSTRUCTION
QTY
1
4
L 2
S 2
4
12
12
12
12
12
PLEASE DO NOT OVER TIGHTEN
