  • Page 1 MIDI-Pedalboard Manuale d’uso - User Manual - EN Bedienungsanleitung - Ver. 1.2...
  • Page 3: Table Of Contents

    1. Controlli e connettori del pannello posteriore ..................2 2. Normale funzionamento ........................3 3. Configurazione dello strumento (modalità Set) ...................4 4. Funzioni di configurazione ........................5 5. Midi Bulk Dump ...........................7 6. Caricamento del sistema operativo .......................8 7. Factory Setting ............................8 8. Schema di assemblaggio........................9...
  • Page 4: Controlli E Connettori Del Pannello Posteriore

    Midi [INPUT]. 4. [INPUT 2]: seconda presa Midi di ingresso alla quale collegare un generatore di dati Midi esterno. 5. [INPUT 1]: prima presa Midi di ingresso alla quale collegare un generatore di dati Midi esterno.
  • Page 5: Normale Funzionamento

    Ad ogni evento di nota generato dalla pedaliera o di controllo tramite i pedali di espressione in uscita dallo strumento il led verde effettua un singolo lampeggio. La porta [MIDI OUT] oltre ad inviare i dati Midi generati dallo strumento, ritrasmette anche quelli ricevuti dalle due porte [INPUT 1] e [INPUT 2] (funzione Soft-Thru).
  • Page 6: Configurazione Dello Strumento (Modalità Set)

    Per accedere alle funzioni di configurazione dello strumento premere il pulsane [SET], il led rosso si accende fisso. Per abbandonare la modalità Set e tornare al normale utilizzo della pedaliera Midi ripremere il pulsante [SET], il Led rosso si spegne.
  • Page 7: Funzioni Di Configurazione

    Quando la pedaliera è in modalità note (vedi par. “Impostazione della modalità di pedaliera”) questa funzione imposta il numero della nota Midi del primo pedale. Questa funzione pertanto ha lo scopo di regolare una trasposizione della pedaliera; si ricorda che negli organi intonati con il La3 a 440 Hz le pedaliere trasmettono il [Do1] come nota Midi numero 36, impostando il valore 37 si ottiene una trasposizione di +1 semitoni.
  • Page 8 7) Premere il [Do#3] NOTA In modalità note numeri superiori a 96 vengono limitati a tale valore. CANALE MIDI DEL PEDALE D’ESPRESSIONE [EXPR. 1] 1) Premere il pulsante [SET] 2) Premere il [Do#2] 3) Premere un pedale bianco da 0 a 15 (il [Do1] corrisponde allo 0) 4) Premere il [Do#3] CANALE MIDI DEL PEDALE D’ESPRESSIONE [EXPR.
  • Page 9: Midi Bulk Dump

    4) Premere il [Do#3] 5. MIDI BULK DUMP Il Midi Bulk Dump è un pacchetto di dati contenente la configurazione dello strumento ovvero lo stato delle funzioni precedentemente descritte. Salvare questo pacchetto di dati in un’unità esterna permette di crearsi e disporre di più configurazioni ripristinabili in qualsiasi momento. Tale funzione ha altresì lo scopo di crearsi un backup della configurazione della pedaliera qualora per motivi accidentali la memo- ria interna venga cancellata o rovinata.
  • Page 10: Caricamento Del Sistema Operativo

    Il sistema operativo dello strumento viene fornito tramite un file Midi (file .mid). Per caricare lo stesso nella pedaliera è necessario disporre di un lettore Midi la cui porta Midi Out è da collegare alla [INPUT 1] (no la [INPUT 2]) della pedaliera. Durante la ricezione dei dati il led verde lampeggia, al temine del caricamento viene eseguita una verifica dei dati passata la quale il Led verde si spegne e quello rosso lampeggia una volta.
  • Page 11: Schema Di Assemblaggio

    MIDI-Pedalboard 8. SCHEMA DI ASSEMBLAGGIO EXP R. 2 EXP R. 1 MID I INP UT 2 INP UT 1 M ID I- P e d a lb o POW ER a r d RISK OF TO REDUC ELECT RIC E THE RISK...
  • Page 12 Smaltimento dei rifiuti elettrici ed elettronici (applicabile nell’Unione Europea e negli altri paesi europei con servizio di raccolta differenziata) Ai sensi dell’art. 13 del Decreto legislativo 25 luglio 2005, n. 151 “Attuazione delle Direttive 2002/95/CE, 2002/96/CE e 2003/108/CE” II simbolo presente sul prodotto o sulla sua confezione indica che il prodotto non verrà trattato come rifiuto domestico.
  • Page 15 1. Controls and connections on the rear panel ..................14 2. Play mode ............................15 3. Instrument configuration (Set mode) ....................16 4. Configuration functions ........................17 5. Midi Bulk Dump ..........................19 6. Operating system updating .........................20 7. Factory Setting ............................20 8. Assembly scheme ..........................21...
  • Page 16: Controls And Connections On The Rear Panel

    1. [EXPR. 2]: for connecting the cable of the right expression pedal. 2. [EXPR. 1]: for connecting the cable of the left expression pedal. 3. [MIDI OUT]: Midi socket for the transmission of the Midi data generated by the pedalboard and received by the two [INPUT] Midi sockets.
  • Page 17: Play Mode

    Every time a note is played on the pedalboard or the expression pedals are in use, the green Led flashes one time. The [MIDI OUT] port, in addition to the MIDI data transmission, also transmits the Midi data received through [INPUT 1] and [INPUT 2] (Soft-Thru function) Midi sockets.
  • Page 18: Instrument Configuration (Set Mode)

    [F#1]: Midi transmission channel for the notes played on the pedalboard [G#1]: Midi velocity value of the notes played on the pedalboard [A#1]: Midi note or Program Change number of the first pedal -C1 (transposer function) [C#2]: Midi transmission channel for Control Change in connection with the expression pedal [EXPR.
  • Page 19: Configuration Functions

    This function allows the adjustment of a transposition of the pedalboard; (please note that with organ tuned with the A3 at 440Hz the keys will transmit C1 as Midi note 36, setting a value of 37 for obtaining a transposition of +1 semitone.
  • Page 20 7) Press [C#3] NOTE In Set mode numbers higher than 96 are limited to this value EXPRESSION PEDAL [EXPR. 1] MIDI CHANNEL 1) Press [SET] button 2) Press [C#2] 3) Press a white key from 0 to 15 ([C1] corresponds to 0) 4) Press [C#3] EXPRESSION PEDAL [EXPR.
  • Page 21: Midi Bulk Dump

    For receiving and storing in the internal memory a Midi Bulk Dump previously transmitted and recorded, connect the Midi Out of a Midi data player or a sequencer to Midi pedalboard’s [INPUT 1] or [INPUT 2]. Then press [SET] button and start playing the recorded Midi Bulk Dump on the external Midi device.
  • Page 22: Operating System Updating

    The operating system is supplied by Viscount as a Midi file (.mid file). For loading it into the Midi pedalboard, you have to use a Midi data player and to connect its Midi out to the pedalboard’s [INPUT 1] (not INPUT 2). When loading the green Led will flash, after reception the instrument will check data. If correct the green Led lights off and the red Led will flash one time.
  • Page 23: Assembly Scheme

    MIDI-Pedalboard 8. ASSEMBLY SCHEME EXP R. 2 EXP R. 1 MID I INP UT 2 INP UT 1 M ID I- P e d a lb o POW ER a r d RISK OF TO REDUC ELECT RIC E THE RISK...
  • Page 24 Disposal of old Electrical & Electronic Equipment (Applìcable throughout the European Union and other European countries with separate collection programs) Dir. 2002/95/CE, 2002/96/CE e 2003/108/CE This syrnbol, found on your product or on its packaging, indicates that this product should not be treated as household waste when you wish to dispose of it.
  • Page 27 INHALTSVERZEICHNIS 1. Bedienelemente und Aschlüsse auf der Rückseite ................26 2. Normaler Gebrauch ..........................27 3. Konfiguration des Instruments (Einstellmodus) .................28 4. Konfigurationsfunktionen ........................29 5. Midi Bulk Dump ..........................31 6. Laden des Betriebssystems .........................32 7. Werkeinstellungen ..........................32 8. Darstellung der Montage ........................33...
  • Page 28: Bedienelemente Und Aschlüsse Auf Der Rückseite

    1. [EXPR. 2]: Für den Anschluss des Klinkensteckers des rechten Fußschwellers. 2. [EXPR. 1]: Für den Anschluss des Klinkensteckers des linken Fußschwellers. 3. [MIDI OUT]: Midi-Buchse für die Übertragung der Midi-Daten, die vom Midi-Pedal selbst erzeugt werden, und derjenigen, die an den beiden Midi-Buchsen [INPUT] empfangen werden.
  • Page 29: Normaler Gebrauch

    Beim Einschalten des Geräts blinken die rote LED einmal und die grüne LED zweimal. Das bedeutet, dass das Instrument für den Gebrauch bereit ist. Jedes Mal, wenn mit dem Midi-Pedal eine Note gespielt wird oder die Fußschweller betätigt werden, blinkt die grüne LED einmal auf.
  • Page 30: Konfiguration Des Instruments (Einstellmodus)

    Drücken Sie zum Aufrufen der Funktionen für die Konfiguration des Instruments die Taste [SET]. Die rote LED leuchtet dann ständig. Drücken Sie die Taste [SET] erneut, wenn sie den Einstellmodus verlassen und zur normalen Funktionsweise des Midi-Pedals zurückkehren wollen. Die rote LED erlischt dann wieder.
  • Page 31: Konfigurationsfunktionen

    Diese Funktion dient also zur Einstellung einer Transposition des Midi-Pedals. Man beachte, dass das Pedal bei einer Orgel, bei der A3 auf 440 Hz gestimmt ist, das [C1] als Midi-Note Nr. 36 übertragen wird. Setzt man den Wert auf 37, erhält man eine Transposition um einen Halbton nach oben.
  • Page 32 7) Drücken Sie [C#3]. HINWEIS: Werte über 96 werden auf diesen Wert begrenzt MIDI-KANAL DES FUSSSCHWELLERS [EXPR. 1] 1) Drücken Sie die Taste [SET]. 2) Drücken Sie [C#2]. 3) Drücken Sie eine weiße Taste von 0 bis 15 ([C1] entspricht 0).
  • Page 33: Midi Bulk Dump

    ÜBERTRAGUNG Zum Übertragen der Konfiguration des Instruments über den Anschluss [MIDI OUT] (der an den Anschluss MIDI IN eines Midi-Aufnahmegeräts wie z.B. eines Sequenzers angeschlossen ist) müssen sie zuerst die Taste [SET] und dann [D3] drücken. Nach Abschluss der Datenübertragung erlischt die rote LED.
  • Page 34: Laden Des Betriebssystems

    Pedal wird ein Midi-Abspielgerät benötigt, dessen Anschluss Midi Out mit dem Anschluss [INPUT 1] (nicht [INPUT 2]) des Midi-Pedals zu verbinden ist. Während des Empfangs der Daten blinkt die grüne LED. Nach dem Laden werden die Daten geprüft. Ist das Ergebnis der Prüfung positiv, erlischt die grüne LED und die rote LED blinkt einmal.
  • Page 35: Darstellung Der Montage

    MIDI-Pedalboard 8. DARSTELLUNG DER MONTAGE EXP R. 2 EXP R. 1 MID I INP UT 2 INP UT 1 M ID I- P e d a lb o POW ER a r d RISK OF TO REDUC ELECT RIC E THE RISK...
  • Page 36 Entsorgung von alten Elektro- und Elektronikgeräten (gültig in der Europäischen Union und anderen europäischen Ländern mit separatem Sammelsystem) Dir. 2002/95/CE, 2002/96/CE e 2003/108/CE Dieses Symbol auf dem Produkt oder auf der Verpackung bedeutet, dass dieses Produkt nicht wie Hausmüll behandelt werden darf.
  • Page 37 Reset NOTES: *1: Midi data received by Input ports are redirected to the Midi Out port *2: a fixed velocity value can be setted in Set mode (see chapt. 4) *3: Program Change messages are transmitted in Program Change mode only (see chapt.
