Components
SunPipe Components
1 x 230 SunPipe Diamond Dome
1 x Integral ABS Flashing Plate with Extract Duct
1 x Code 4 lead skirt
1 x SunPipe Extension 610mm Length – Crimped End
1 x SunPipe 30° or 45° Adjustable Elbow
1 x SunPipe Standard 610mm Length - Plain End
1 x SunPipe 250mm Long Bell End Ceiling Extension
1 x SunPipe Ceiling Trim
1 x SunPipe Ceiling Bezel
1 x Silicone Sealant
1 x SunPipe Installation Pack
Sola-Vent Components
1 x Photovoltaic Flashing Plate c/w polycrystalline PV panel
1 x Code 4 lead skirt
1 x Extract Fan and Housing
1 x Length of Flexible Ducting
2 x Jubilee Clips
2 x 400mm Length of White PVC Duct
1 x Black connecting adaptor to suit White PVC Duct
1 x Sola-Vent Base Unit
2 x 12v Batteries
1 x Black transition to suit Sirroco Fascia
230 Sola-Vent System
2 x 35W Halogen Bulbs
2 x Shower Downlighters
1 x Sola-Vent Plywood Backing Plate
1 x Sola-Vent Ceiling Fascia c/w PIR
2 x 30Amp 240v Junction Box
1 x Sola-Vent Installation Pack
1 x Mains back up facility
Dec 2006
Advertisement
Summary of Contents for SOLaVent 230
- Page 1 230 Sola-Vent System Dec 2006 Components SunPipe Components 1 x 230 SunPipe Diamond Dome 1 x Integral ABS Flashing Plate with Extract Duct 1 x Code 4 lead skirt 1 x SunPipe Extension 610mm Length – Crimped End 1 x SunPipe 30° or 45° Adjustable Elbow...
- Page 2 Installation instructions: Monodraught Sola-vent (All mains wiring should be carried out by a qualified electrician.)
- Page 3 DO NOT Connect the internal batteries until the installation has been fully completed. Failure to do so may cause damage to the system. 1. Check to ensure that there is sufficient room for the ventilation ductwork and SunPipe lengths between the bathroom ceiling and the selected position of the roof flashing and that a suitable mains lighting circuit is available to the bathroom ceiling for the Halogen downlights, connected to the bathroom light switch and a mains plug socket is available in the loft / ceiling void for the...
- Page 4 Vent flashing and up to 9m away from the Base unit. (Additional extension cables are available from Monodraught tel 01494 897700) b. Fit the solar panel flashing plate as per the SunPipe standard flashing plate installation instructions. c. The cable should be passed through the roofing felt by making a small hole through it.
- Page 5 11.Insert the cast metal holders for the downlighter units into the ceiling fascia, ensure that the securing clips are securely located. Fit the bulbs and retaining clips as per the manufacturer’s instructions. 12.Connect the Miniature PIR using the three core cable provided.
- Page 6 16.Position the fan in place within the fan housing below the Sola-Vent flashing plate. Take note of the direction arrows on the side (Arrow should point towards roof) and check that the fan spins freely without any obstruction from the foam gasket.
- Page 7 21.Having checked that the electricity supply is disconnected, connect the mains wiring to the Downlighters from the switched mains lighting circuit using the two brown connector blocks supplied. Ensure that no bare wire is showing and insulate with electricians tape if necessary. (All mains wiring should be carried out by a qualified electrician.) 22.Having checked all wiring connections for safety reconnect the mains supply and test the mains lights using the bathroom light switch.
- Page 8 Maintenance instructions: Monodraught Sola-vent The Monodraught Sola-vent is designed to run with little or no maintenance for years of trouble-free service. The Sola-vent has a number of non-serviceable components in the ABS base unit and these may be replaced by a qualified electrician if necessary.
- Page 9 Troubleshooting: Monodraught Sola-vent All Sola-Vent systems are checked prior to despatch including the PIR sensors. There is unlikely to be any reason why the Sola-Vent system will not function correctly. Firstly disconnect the batteries from the system and unplug the PV connector. Ensure that all the LED’s are not flashing on the Solar Controller.
- Page 10 Wiring Diagram : Monodraught Sola-Vent...
