Summary of Contents for HannStar Display Hannspree Hanns.G Series

Page 1 www.hannspree.co.uk...
Page 2 Hannspree is a global consumer electronics manufacturer specialising in audio visual technology. We are part of the HannStar Display Corporation, one of the largest glass panel manufacturers in the world, consequently both the Hannspree and HannsG brands benefit from a rich heritage and world-class technological process in display technology.
Page 3: Table Of Contents
Contents ........................................... The Status Bar..................................................................................Quick Settings Panel Notifications....................................................................................Favourites Tray Action Bar....................................................................................... App Drawer ............................................. Settings ..............................................Wi-Fi ............................................Bluetooth Display..........................................................................................Storage ............................................... Battery Apps..........................................................................................Location ............................................. Security ........................................... Language & Input ........................From this pane you can change the default language of your device...........................................
Page 4: The Status Bar
The Home Screen Turn on your device by pressing the power button and unlock by placing your finger on the padlock and swiping either left or right. From there you will be presented with you home screen. You can have as many home screens as you want, which you simply swipe left/right to access.
Page 5: Quick Settings Panel
Quick Settings Panel Google introduced the “Quick Settings” panel which allows you to pull push and pull the status bar down in the middle side of the status bar to access a whole array of device features. Pull once for notifications, twice for quick settings. Notifications Pull down on the status bar’s in the to see all your notifications, which you can then enter each by clicking or dismiss by swiping to...
Page 6: Favourites Tray
Favourites Tray The Favourites Tray allows you to pin any app so no matter what home screen you are on, you can always access them. Action Bar At the bottom of your device is the “Action bar,” which like the status bar is persistent, and never goes away but maybe hidden in some full screen apps.
Page 7: App Drawer
App Drawer The app drawer. This is the centre icon on the app tray that opens up where all your apps are installed. From here you can open them, uninstall, or pin shortcuts to the home screen.
Page 8: Settings
Settings There are two ways to access settings, you can either open the app tray and tap the “Settings” shortcut or you can pull down the “Quick Settings” panel and choose “Settings” from the choices.
Page 9: Wi-Fi
Wi-Fi Wi-Fi networks can be searched for and connected to using this tab. Make sure you have the correct security settings. Turn on the WiFi. · Press the WiFi Icon on the top right corner of the screen · (status bar) or from "Settings" → "Wireless ＆ networks" →"WiFi".
Page 10: Display
Display Using the display accounts for the majority of battery use. Brightness and timeout period can be adjusted in this pane to get a bit more time out of your battery. Storage Similar to battery life storage space is a limited resource. The storage pane allows you to determine what is taking up space, and how much you can reclaim by removing applications and deleting files not needed...
Page 11: Security
Security There’s a great many ways to protect your device and data on Android. From this pane you can setup a lock screen password. Meaning any user wanting to unlock your device will need your Password or Passcode. Language & Input From this pane you can change the default language of your device.
Page 12: Arranging Shortcuts
Arranging shortcuts If you simply want to rearrange shortcuts so they’re in a certain order, then you can easily move them around. Simply choose the shortcut you want to move press and hold and see that the shortcut’s outline can be seen where it will be placed if you were to release it at that moment.
Page 13: Creating Folders
Creating Folders Folders are a great way to clean up similar types of shortcuts and place them in a group. When you tap on the group, it will expand open and you can pick the app you want to launch, kind of like having mini app drawers on your home screen.
Page 14: Folders In The Favourites Tray
Folders in the Favourites Tray Folders in the Favourites Tray works the same as any other folder only this folder will be persistent across all your home screens and always within reach of your thumb. To create a group in the favourites tray, follow the same procedure as previously outlined above, only drag your apps to the tray instead of the home screen.
Page 15: Your Play Store Apps
Your Play Store apps Tap the upper-left corner of the Play Store to access a slide-out menu. Here you’ll see applicable actions associated with your account – “Store home,” “My apps,” “Shop apps,” “My wishlist,” and “Redeem” – as well as the “settings.”...
Page 16: App Info
App info Tap on any app to open its “app info” screen. Here you are given some basic information on what version it is, how much storage it uses, cache data, defaults, and permissions Force stop/Uninstall updates/Disable In this first section, you force the app to stop, uninstall updates, and disable it altogether.
Page 17 If app maker pushes out an update, which does more harm than good or they make changes that you simply don’t like). You can uninstall that update or updates to revert to an earlier app version. Then you can simply “disable” apps the app will still be on your tablet but the shortcut will be removed from the app drawer.
Page 18: Clear Data/Cache
Clear data/cache Clearing app and cache data is a sure way to free up storage space but caveats abound. In many cases, clearing data can undo personalisa- tion’s and other simple things like sign-in information. So for example, if you clear the data from the Facebook app, you will have to sign back in the next time you launch the app.
Page 19: Troubleshooting
TROUBLESHOOTING APPLICATION Why does the application I installed not fit the tablet resolution? Click "Settings" → "Applications" → "The installed application is de signed for cell phone and it may not support full screen resolution. Why does the direction of the tablet rotation not match with the application (I.E.
Page 20: Display & Video
DISPLAY & VIDEO Why won't the screen on my tablet auto rotate? Please check upper middle quick settings of “Landscaoe”. If yes, please change it to “AUTO ROTATE” NOTE: Some apps are designed for mobile phone only, so the app may not support the auto rotate function.
Page 21: Touch Panel
TOUCH PANEL Why is the touch panel not responding (the display screen is working)? Press Reset button to check whether the Tablet can be booted into system or not. Enter Tablet main page, press Volume button to test whether the volume is working or not.
Page 22 How do I reset to factory settings? Click "Settings" → "backup & reset" → "Factory data reset" to clear all user settings and recover the system to the default status. WARNING: All installed applications and personal data will be erased (emails, contacts...etc.).
Page 23: Wireless
WIRELESS How do I set up wireless Wi-Fi connection? Turn on the W-iFi Press the Wi-Fi Icon on the top right corner of the screen (status bar) or from "Settings" → "Wireless & networks" →"WiFi". Find a WLAN Select a network from "Settings" →"Wireless & networks" →"WiFi" →"WiFi Settings".
Page 24: Storage
STORAGE How do I disconnect a Micro SD card from my tablet? It is recommended to remove the Micro SD card from "Settings" → "Storage" → "Unmount SD card". Why does the inserted Micro SD card not work or shows "Damaged SD card"...
Page 25: Power
How do I find the Software (UI) Version from the device? The Software (UI) version can be found in "Settings" → "About tablet". POWER How to check the Tablet if the Tablet cannot be turned - If the power is low, connect to the electric outlets. - Press and hold the POWER/ Force-off button for 8 seconds until the Hannspree logo appears.
Page 26 The battery on my device runs out very quickly, what can I do? When the product is not in use, be sure to turn off the device. Switch OFF WiFi / Bluetooth and close unused apps to save battery. If you have network applications running in the background (that are auto launched at boot, i.e.: checking the weather every 2 minutes) this will have an impact on the battery drain.
Page 27: Others
OTHERS Does the SN1AT76 support external recording device? (i.e. bluetooth headset) No, SN1AT76 do not support external recording device. (i.e. Bluetooth headset, USB microphone…etc.) Please use built-in microphone for recording. How do I type special characters on the virtual keyboard in device (i.e. à á â ã ä å)? On the virtual keyboard, simply tap and hold on a particular letter to bring up special characters for selection.
Page 28 WARRANTY...
Page 29 1 Warranty conditions The warranty for all Hannspree products is for 2 years from the date of purchase For 14 days following the purchase date the product can be returned to Ideal Shopping for a full refund Warranty will be honoured on receipt of a valid proof of purchase ie invoice Warranty will only cover genuine faults.
Page 30 4 Repairing your product Once the repair centre have received your product it will immediately be assessed. If there is any damage you will be notified at this point and may be charged for subsequent replacement of damaged parts The product will be repaired and then tested for 24 hours to ensure that it is fully working.
Page 31 Appendix 1 -Hannspree warranty conditions HANNSPREE LIMITED WARRANTY COVERAGE Hannspree Europe GmbH, (hereinafter referred to as "Hannspree") or its Authorised Agent, warrants that the products supplied are free from defective material and workmanship (other than those parts excluded below) during the warranty period. If a product proves to be defective in material or workmanship during the warranty period, Hannspree will, repair or replace the product with a similar product.
Page 32 Established in June 2003 and headquartered in Taipei, Taiwan, Hannspree is a leading manufacturer of Display solutions, spanning Australia, China, Europe, Hong Kong, Japan, New Zealand, Taiwan and The USA. The central manufacturing facilities are located in Taiwan and in China. European Headquarters are in Venlo, Netherlands and our Marketing organization is based in Germany.
