Page 1 P40 1.0 Notices No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, mechanical photocopying, recording or otherwise, without the prior written permission of the manufacturer. The information within this manual is subject to change without notice. The manufacturer shall not be held liable for technical or editorial errors or omissions contained in herein;...
Page 2: Important Safety Information
Important Safety Information Safety Instructions Your system is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that the safety instructions marked on the product and in the documentation are followed.
Page 3: Care During Use
Do not put rechargeable batteries or products powered by non-removable rechargeable batteries in the garbage. Contact the Samsung Helpline for information on how to dispose of batteries that you cannot use or recharge any longer. Follow all local regulations when disposing of old batteries.
Page 4: Laser Safety
Laser Safety All systems equipped with CD or DVD drives comply with the appropriate safety standards, including IEC 825. The laser devices in these components are classified as “Class 1 Laser Products” under a US Department of Health and Human Services (DHHS) Radiation Performance Standard.
Page 5: Regulatory Compliance Statements
Regulatory Compliance Statements Wireless Guidance Low power, Radio LAN type devices (radio frequency (RF) wireless communication devices), operating in the 2.4 GHz Band, may be present (embedded) in your notebook system. The following section is a general overview of considerations while operating a wireless device.
Page 6 In environments where the risk of interference to other devices or services is harmful or perceived as harmful, the option to use a wireless device may be restricted or eliminated. Airports, Hospitals, and Oxygen or flammable gas laden atmospheres are limited examples where use of wireless devices may be restricted or eliminated.
Page 7: United States Of America
United States of America Unintentional Emitter per FCC Part 15 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 8: Fcc Part
The FCC has set a general guideline of 20 cm (8 inches) separation between the device and the body, for use of a wireless device near the body (this does not include extremities). This device should be used more than 20 cm (8 inches) from the body when wireless devices are on.
Page 9 If the terminal equipment causes harm to the telephone network, the Telephone Company will notify you in advance that temporary discontinuance of service may be required. But if advance notice is not practical, the telephone company will notify the customer as soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe it is necessary.
Page 10 Canada Unintentional Emitter per ICES-003 This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the radio interference regulations of Industry Canada. Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limitesapplicables aux appareils numériques de Classe B prescrites dans le règlement sur le brouillage radioélectrique édicté...
Page 11 Telecommunications per DOC notice (for products fitted with an IC-compliant modem) The Industry Canada label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operation, and safety requirements. The Department does not guarantee the equipment will operate to the users’...
Page 12: European Union
European Union The following information is only applicable to systems labeled with the CE mark European Directives This Information Technology Equipment has been tested and found to comply with the following European directives: • EMC Directive 89/336/EEC with amending directives 92/31/EEC & 93/68/ EEC as per –...
Page 13 European States qualified under wireless approvals: Austria, Belgium, Denmark, Finland, France (with frequency Germany, Greece, Ireland, Italy, Luxembourg, The restrictions), Netherlands, Portugal, Spain, Sweden and the United Kingdom. Accept EU Iceland, Liechtenstein, Norway and Switzerland European States with restrictions on use: In France, the frequency range is restricted to 2446.5-2483.5 MHz for devices above 10 mW transmitting power such as wireless LAN.
Page 14: Using Your Documentation
Using Your Documentation Congratulations on your purchase of a notebook computer with the Windows® XP operating system. Whether you are new to using a portable computer or are an experienced user, this user’s manual can help you get the most from your computer. Manual Documentation Conventions Information Icons Three icons and their associated messages appear in this manual.
Page 15: Touchpad Conventions
CD-ROM Device Naming Convention In many installation programs you will have to get a program from the CD-ROM device. The program installation sequence assumes that the CD is drive d:\, however this is not always the case. The name of the CD-ROM drive is the letter following the letter assigned to your last HDD.
Page 16: Getting Started
Getting Started Introducing Your Computer Front View LCD Panel Status Indicators (p16) Touchpad (p11) Touchpad Button Status Indicators (p16) Fingerprint sensor is optional. For more information on using the fingerprint sensor, refer to the manual supplied with the device. LCD Button Microphone Hot Keys (p14) Power Button...
Page 17: Right View
Right View Headphone You can install various other multi-bay devices in the multi-bay of the system. Refer to (p 27). Left View Infrared Port Security Lock Port LAN Port (p41) 4 Users Manual Microphone USB Port Jack Jack (2.0) Modem Port USB Port Fan Vent (p40)
Page 18: Back View
Bottom View Multi-Bay Latch Compartment Speaker Battery (p87) Removing or disassembling the hard disk drive will void your warranty. To replace the hard disk drive, please contact your nearest Samsung Service Centre. Parallel Port Serial Port USB Port Monitor Port (2.0)
Page 19: Turning The Computer On And Off
Turning the Computer On and Off To turn on the computer 1. Insert the battery and connect the AC adapter according to the Installation Guide. 2. Slide the LCD latch to the right and open the LCD panel. 3. Press the power button. To turn off the computer 1.
Page 20 If the computer is not turned off properly due to a system error, press <Ctrl>+<Alt>+<Delete>. When [Windows Task Manager] dialog box appears, click Shut Down > Turn Off to turn off the computer. Your unsaved work may be lost/damaged. If <Ctrl>+<Alt>+<Delete> keys do not operate either, press the power button for more than 4 seconds to turn off the computer.
Page 21: Using The Keyboard
Using the Keyboard Your computer has an 89-key keyboard. By pressing designated key combinations, you can have access to all the key functions of a full-sized keyboard. Function Although the layout of the keys on your computer’s keyboard is different from that on a desktop computer’s keyboard, the keyboard feels like a full-sized keyboard when you use it.
Page 22: Using The Numeric Keypad
The keys on the keyboard can be grouped into the following categories: • Full-sized Alphanumeric typewriter keys are arranged like a standard typewriter keyboard and are used for text entry. The Windows keys on either side of the spacebar open Windows menus and perform other special functions. •...
Page 23: Using Special Function Keys
Using Special Function Keys The function key activates special functions when it is pressed in combination with another keys. <Fn> Key Key Name Combinations <Esc/ > Rest <F2/ > Gauge <F4/ > LCD/CRT <F5/Backlit> Backlight <F6/Mute> Mute <F9/ > Touchpad <F10/ >...
Page 24: Using The Touchpad
Using the Touchpad In Windows, you always see a small graphical image on the screen that indicates the location where you can take the next action. This image is called a pointer, and is usually displayed in arrow shape ( Touchpad The touchpad on your computer allows you to move the pointer on the LCD screen, just like a mouse that is used with a desktop computer.
Page 25 You can perform various actions with your touchpad as described below. Action Move Click Double-Click Right-Click Drag 12 Users Manual Function Process Move the pointer Place your finger on the touchpad and slide your finger to a destination. Select an object, open a menu, or Place the pointer over an object, execute a button then press left touchpad button...
Page 26 Action Function Scroll Display upper/lower/left/right part of the content within a window (Applicable to certain programs only) Please use the touchpad only with your finger. Using sharp devices may damage the touchpad. Operating the touchpad or touchpad button while starting your system may increase the time required for starting Windows.
Page 27: Hot Keys
Hot Keys Name Internet Butto E-Mail Button User 1 Button WLAN/Bluetooth or User 2 Button About the Wireless LAN Button Turning the wireless LAN on or off takes about 5 seconds. Pressing this button will not work for approx. 5 seconds after the last time the button was pushed. 14 Users Manual Function Launches Internet Explorer.
Page 28 Changing the Hot Key Setting You can change the program that will be launched when you press a hot key. As default, Windows Calculator is configured to launch when you press the User 1 button. You can set the program by completing the following procedure. 1.
Page 29: Reading The Status Indicators
Reading the Status Indicators Shows the operating status of the computer. Num Lock Caps Lock Scroll Lock Battery Power Hard disk drive 16 Users Manual Turns on when the numeric keypad is activated. Turns on when all alphabet characters you type will be in upper case. Turns on when it is set to scroll the screen up and down while the cursor position does not change in some applications.
Page 30: Adjusting Lcd Brightness
Maintaining your LCD brightness settings after turning the system off and on 1. Turn the system on. When the Samsung Logo appears, press the <F2> key to enter Setup. 2. In the Boot menu, change the Brightness Control Mode option to User Control.
Page 31: Adjusting The Volume
Adjusting the Volume To adjust using keyboard Press <Fn>+< level is displayed on the upper part of the screen for a few seconds. To adjust using volume adjustment program Click the Volume icon( level. For advanced volume control options, double-click the Volume icon( the volume level in the volume control program.
Page 32: Introducing Windows
Introducing Windows Understanding the Desktop The desktop is the working area on the computer. It consists of the large workspace and a taskbar at the bottom. Shortcut Icons Start Menu Start Button Start Button Taskbar Recycle Bin Language Bar Taskbar System Tray with Clock Opens the Start menu.
Page 33: Understanding The Start Menu
Understanding the Start Menu The Start menu includes everything that is required to start Windows. From the Start menu it is possible to run a program, open a file, assign system users with Control Panel, receive support by clicking Help and Support, and search desired items from the computer or Internet by clicking Search.
Page 34: Understanding A Window
Understanding a Window A window is the basic component in working with the computer. The My Computer window, which is a window for the computer's hard drive, will be used as an example here to show the basic composition of a window. Click Start >...
Page 35: Help And Support Center
Help and Support Center Help and Support Center provides references and troubleshooting information regarding computer use. Click Start > Help and Support. Windows XP Tour You can tour elementary functions provided by Windows XP. Click Start > Tour Windows XP. Or click Start >...
Page 36: Using The Computer
Using the Computer Using the CD Drive You have one of following drives installed in your computer. DVD-ROM drive CD-RW/DVD-ROM Combo drive DVD Super Multi Drive 1. Press the eject button on right side of the CD drive. 2. When the tray slides out, place a CD onto the tray with the label facing up, and push the CD down until it clicks.
Page 37 To clean a CD or DVD title Clean the disc with a soft clean cloth by wiping from the center outwards. To play a DVD You have to install the DVD software provided on a separate CD to view a DVD title.
Page 38: To Play A Video Cd
To play a video CD If a video CD does not run automatically, follow these steps. 1. Insert a video CD into the CD drive. 2. When the CD drive window appears, double-click the MPEGAV folder. 3. Double-click the .dat file. 4.
Page 39 4. In My Computer window, select files and folders to copy, then drag and drop them onto the CD drive window. 5. Click Write these files to CD in the CD drive window. 6. When the CD Writing Wizard appears, enter the CD label, and click Next. The data begins copying.
Page 40 Using the Multi-Bay Multi-Bay provides space for CD drive installations. You can replace the CD drive with various other types of drives. The procedures to replace the drive installed in the Multi-Bay with other drives are described below. Before Replacing the Multi-Bay Replace the Multi-Bay only after turning the computer off.
Page 41: Using Memory Card Slot
Using Memory Card Slot You can use a Memory Stick (or Memory Stick Pro) and a SD (Secure Digital) card using the memory card slot. You can use the Memory Stick and the SD card as removable disks and can use them to transfer data between your computer and any digital equipment such as a digital camera..
Page 42: To Remove A Memory Card
1. Insert the memory card into the memory card slot. 2. Click Start > My Computer. The inserted memory card is displayed. Memory Stick 3. You can write data to the memory card. If the memory card is not formatted yet, format the memory card before use.
Page 43: To Format A Memory Card
To format a memory card You can use a memory card after the format operation. The procedures to format a memory card are described below. Since format operation deletes all data in the memory card, please make sure that there is no important data in the memory card before formatting. To protect the data in the memory card Set the write protection tab of the Memory Stick or SD memory card to the Lock position.
Page 44: Using The Pcmcia Card Slot
Using the PCMCIA Card Slot Various different functions can be added by inserting PCMCIA cards into the system. This system supports 16/32 bit, type I or II PCMCIA card types. The PCMCIA card slot does not support a ZV card or a PCMCIA III card. To insert a PCMCIA card 1.
Page 45: Using Easybox
Use EasyBox program to make use of Windows' complicated function easily and conveniently. Learn about EasyBox Double-click the EasyBox( (Or select Start > All Programs > Samsung > EasyBox > EasyBox.) • System: System management features are available, including disk defragmenter, removing unnecessary files/folders, computer scheduling and system recovery.
Page 46: Configuring Firewall
The Windows Firewall prevents unauthorized users from gaining access to your system via the network or the Internet. 1. Click Start > All Programs > Samsung > EasyBox > EasyBox. 2. Click Security from the top menu bar. 3. Select Windows Firewall Settings from the Security menu on the left.
Page 47: Using Samsung Smart Screen
If you select OK, the program is automatically launched when you start your computer. 2. Samsung Smart Screen appears. When you run the program for the first time, water drop image is displayed.
Page 48: Using Samsung Theme
Using Samsung Theme Samsung Theme is a program that enables a user to easily switch a theme (desktop, logon screen and sound effect). Double-click the Samsung Theme ( (Or select Start > All Programs > Samsung > Samsung Theme > Samsung Theme.)
Page 49: Using Samsung Update Plus
Update Plus, your computer has to be connected to the Internet. To Update Samsung Software and Drivers 1. Select Start > All Programs > Samsung > Samsung Update Plus > Samsung Update Plus. If this is the first time you are running the program, a window will appear asking you if you agree to the agreement in the window.
Page 50 Here you will be able to find the latest available updates. To change the automatic update settings, click the Configuration button in Figure 2 and change the settings. Samsung Update Plus does not provide updates for additionally installed software and device drivers. Using the Computer 37...
Page 51: Using Samsung Command Center
Using Samsung Command Center Samsung Command Center is a program that enables the easy management of software provided for a Samsung computer. You can view brief descriptions of some programs and you can launch the programs directly. Samsung Command Center is always hidden automatically and it appears when you place the mouse cursor in the right-most position.
Page 52 • Samsung Update Plus Area : When there is new software or a new driver, the Samsung Update Plus notification window appears. If you click on the notification window, Samsung update Plus is launched and an update is performed with a percentage number indicating the progress status.
Page 53: Connecting To The Internet
Connecting to the Internet Connecting with a Modem Before Start: • Prepare a telephone line that is not digital. • Contact an internet service provider (ISP) for instructions on how to connect to and disconnect from the Internet. 1. Connect a telephone line to the computer’s modem port. 2.
Page 54 Connecting Through a Wired LAN 1. Connect a LAN cable to the computer’s LAN port. 2. Click Start > Control Panel. 3. Click Network and Internet Connections in the [Control Panel] window. 4. Click Network Connections in the [Network and Internet Connections] window. 5.
Page 55 6. On the General tab, select “Internet Protocol(TCP/IP)” and click Properties. 7. To use DHCP: On the General tab, select “Obtain an IP address automatically” and “Obtain DNS server address automatically”. Click OK. To use a static IP: On the General tab, select “Use the following IP address” and fill in the IP address, Subnet mask, Default gateway, Preferred DNS server, and Alternative DNS server fields.
Page 56: Using Samsung Network Manager
1. Connect LAN cable to the computer's LAN port. 2. Double-click Samsung Network Manager icon on the desktop. Or click Start > All Programs > Samsung Network Manager > Samsung Network Manager. 3. When you are using DHCP, available IP's are displayed in the status dialog box.
Page 57 To change network places You can change network places as below. 1. Connect LAN cable to the computer's LAN port, and double-click Samsung Network Manager icon on the desktop. If you used static IP in previous place, previous static IP is displayed in the status dialog box.
Page 58: To Share An Internet Connection
Internet Connection Share service, and the client, which is a computer that will use the Internet Connection Share service. To configure the server 1. Connect the network (LAN) cable and double-click the Samsung Network Manager icon on the Desktop. 2. Click Click here to setup Internet Connection Share.
Page 59 3. The computers are represented by an icon. Click the server computer. 4. In the server, select a device that is directly connected to the Internet. If you select Use Firewall, you can use the Windows Firewall.If you are using an external modem, select the network card connected to the external modem.
Page 60 To configure the client 1. Connect the network (LAN) cable and double-click the Samsung Network Manager icon on the Desktop. 2. Click Click here to setup Internet Connection Share. 3. The computers are represented by icons. Click the client computer.
Page 61 Connecting Through a Wireless LAN (Option) A wireless network (Wireless LAN) environment is a network environment that enables communication between multiple computers at home or a small-size office through wireless LAN devices. Using the wireless network connections between the systems, you can use normal network functions such as sharing of files, folders and printers.
Page 62: Connecting To An Access Point (Ap)
2) Computer-to-computer (ad hoc) This is also called a peer-to-peer network. In computer-to-computer wireless networks, you can wirelessly connect 2 or more computers that have wireless LAN modules. For details, see “Connecting to computer- to-computer networks (peer-to-peer or ad hoc)” on page 51. Connecting to an Access Point (AP) This section describes how to connect to an AP.
Page 63 2. Select an AP (E.g. Test) to connect to and click Connect. If there is a configured network key for the AP to connect to, the Enter Network Key window appears. Enter the Network Key in the window and then click the Connect button. When a network key is not defined for a selected AP, click on Link to display the warning message box.
Page 64 Connecting to computer-to-computer networks ad hoc) In computer-to-computer wireless networks, you can wirelessly connect 2 or more computers that have wireless LAN modules. Using this method, a computer that is not connected to the Internet can share the Internet by accessing another computer connected to the Internet.
Page 65 Click Change the order of Preferred Networks. 3. On the Wireless Network tab, click Advanced. 4. Clear 'Automatically connect to non-default network' check box, if it is selected. Select 'Computer-to-computer (ad hoc) networks only', and click Close. 5. In the Wireless Networks tab, click Add. 52 Users Manual...
Page 66 6. Enter the network name (e.g. samsung), and unselect 'The key is provided for me automatically'. Enter the encryption key in the Network key field, and click OK. To prevent a network connection from an unauthorized user, it would be better to configure a network key (encryption key).
Page 67 7. Check that the configured network name (e.g. samsung) is in the ’Preferred networks’ item, and click OK. Now your wireless network setup has been completed. Step 2. Connecting to the configured computer 1. Right-click on the Wireless Network Connection ( select View Available Wireless Networks.
Page 68 2. Select the wireless network name (e.g. samsung) specified in ”Connecting to computer-to-computer networks (peer-to-peer or ad hoc)” on page 51, and click Connect. 3. Enter a cryptographic key in the network key box and click Connect. If the network key is not configured in ”Connecting to computer-to-computer networks (peer-to-peer or ad hoc)”...
Page 69 Checking the connection status Move the mouse pointer over the Wireless Network Connection ( ) icon on the taskbar, and the connection status is displayed. 56 Users Manual...
Page 70: Wireless Network Setup Using The Wireless Lan Setup Program
Wireless Network Setup Using the Wireless LAN Setup Program You can use a wireless LAN by using a wireless LAN configuration program (PROSet) provided separately. To use wireless network connection, complete the following procedures. • Step1. Install the wireless LAN configuration program (PROSet). •...
Page 71 To connect to an Access Point: To connect to an access point or existing computer-to-computer (Ad Hoc) network, refer to the following procedures. (To create a new computer-to-computer network, refer to the following "To create computer-to-computer (Ad Hoc) network" section.) 1.
Page 72 Network name (SSID) is a name that a wireless adapter uses for identifying connection. Enter the name of computer-to-computer network to create (e.g., samsung) or the name of access point to connect. The network name identifies cases. (capital and lowercase) For the name of access point, check the settings of the access point, or ask your wireless network administrator.
Page 73 3. Configure password setting to be used for computer-to-computer network connection in the Security Settings window. To connect to an access point, enter the network authentication, data encryption (WEP), encryption level, key index, and wireless security password configured in the access point. It is recommended to configure data encryption for security purposes when creating a computer-to-computer network connection profile.
Page 74: Using Network Services
Using Network Services While the computer is connected to the network, you can use network services to share files, folders, and printers. Network services are provided for the computers that are connected to the network through wired or wireless network connections. For details, see “Connecting Through a Wired LAN”...
Page 75 Step 1. Configuring Sharing 1. Right-click the target file or folder to share in My Computer, and select Sharing and Security. 2. Click 'IF you understand the security risks but want to share files without running the wizard, click here'. It has the same security effect as that of the 'Network Setup Wizard'.
Page 76: Sharing Printers
Step 2. Using Shared Files or Folders This section describes how to access shared files or folders if your computer is a member of the same workgroup. 1. Double-Click My Network Places of desktop under Other Places. 2. Click 'View workgroup computers', and click the desired computer to access the shared file.
Page 77 Step 1. Configuring Printer Sharing 1. From the computer connected to the printer, click Start > Printers and Faxes. 2. Right-click the printer you want to share, and click Sharing. 3. Select 'Share this printer', enter a share name for the shared printer, and click OK. 4.
Page 78 5. Select 'Browse for a printer', and click Next. 6. Select the workgroup or computer, select the desired printer, and click Next. If you cannot find the desired printer, try again after a while. 7. Read the warning about a shared printer, and click Yes to install the shared printer. 8.
Page 79 Using Bluetooth Devices (Optional) You can transfer files between Bluetooth devices, use the Internet, and construct a Personal Area Network. In addition, you can use a wireless keyboard, wireless mouse, and a wireless printer that have the Bluetooth function. You can only use the Bluetooth communication function between devices (computers, mobile phones, PDAs, printers, etc.) which support Bluetooth.
Page 80 • Using a wireless printer You can use a wireless printer if the printer supports Bluetooth HCRP (Hardcopy Cable Replacement Profile). For more detailed procedures on using a wireless printer, refer to “Install a Bluetooth printer” of the Bluetooth On-line help. •...
Page 81: Infrared Communication
Infrared Communication Your computer may have infrared port. Using the infrared port, you can transfer data to computer, printer, camera and other devices through infrared communication. Restrictions in Use For infrared communication, the devices should have infrared communication capability, and should be located within 1 m of each other. In addition, there should be no obstacle between the infrared ports of the target devices.
Page 82 If you cannot use infrared communication 1. Check BIOS setup. a. Start the computer, and press <F2> to enter System Setup. b. Select I/O Device Configuration in the Advanced menu, and press <Enter>. c. Select Infrared Port, and set the item to Enabled by pressing <F5> or <F6>.
Page 83: Customizing Your Computer
Customizing Your Computer Using System Setup The System Setup (BIOS) program enables you to configure your computer hardware and set security and power-savings options. The settings you choose are stored in battery-maintained CMOS memory that saves the information even when the computer’s power is turned off.
Page 84: Starting System Setup
Starting System Setup To start System Setup, turn on your computer and then press <F2> and hold until the System Setup screen appears. Table 2. System Setup Menus Menu Function Main Changes the basic system. Advanced Configures advanced features on your computer. Security Enables security features, including passwords.
Page 85: Changing Booting Priority
Changing Booting Priority You can select the booting priority among the devices such as the hard drive, CD-ROM drive, etc. The following example describes how to configure the hard drive as the first booting device when the CD-ROM drive is configured as the first booting device by default.
Page 86: Configuring The Password
Do not lose or forget your password. If you have forgotten your password, contact the Samsung service center. 1. Select the Security menu in the System Setup. To enter System Setup, see “Starting System Setup” on page 71.
Page 87: Deactivating The Password
Activating the Booting Password Before activating the booting password, the supervisor password must have been configured. Set the Password on boot option to [Enabled]. From now on, system booting will not proceed without the password. Deactivating the Password 1. On the password to delete, press <Enter>. (e.g. supervisor password) 2.
Page 88: Configuring Resolution And Color Depth
Configuring Resolution and Color Depth Screen resolution is the number of pixels displayed on the screen. High resolution makes the overall screen area large, although individual items appear small. Color quality is determined by the number of bits used to represent a pixel on the screen. High color quality displays more number of colours on your screen.
Page 89 For XGA models, configuring the screen resolution to 1024x768, and the colour quality to Highest (32 bit) is recommended. For SXGA+ models, configuring the screen resolution to 1400x1050, and the colour quality to Highest (32 bit) is recommended. 76 Users Manual...
Page 90 Using External Display Devices(ATI Chipset model, (p 75)) Using external display devices such as monitors, projectors, TVs, etc allows you to view screen images alternatively or simultaneously on each device. Additionally, you can extend the screen onto two display devices to use a larger workspace. Using external display devices is especially useful when you are giving a presentation or watching a movie through your TV.
Page 91 2. Click the Settings tab > Advanced 3. Click the Display tab. 4. Select YPbPr On/Off. YPbPr On/Off YPbPr 5. Click Apply. 6. Click YPbPr. 7. Select the appropriate TV type in the YPbPr Properties window and Click Apply. 2. Press the <Fn>+<F4/ connected, the display option changes in LCD >...
Page 92: Using Dual View To View Extended Screen
Using Dual View to View Extended Screen You can expand the screen into two display devices and work conveniently in separate workspaces. In Dual View mode, you can select the screen resolution and colour quality for each display device, as if there were two separate graphics cards. 1.
Page 93 secondary display device is indicated as '2'. Now you can view the screen through two monitors. When you use Dual View, configuring the LCD as the 'Primary' monitor is recommended. If the screen of the secondary display device is displayed at 640x480 pixels, with 256 colours, change the settings to the desired screen resolution and colour quality in the [Display Properties] dialog box.
Page 94 Using External Display Devices(Intel Chipset mode, (p 75)) Using external display devices such as monitor or projector, you can view the screen images alternatively or simultaneously. You can extend the screen into two display devices to use larger workspace. Using external display devices would be especially useful when you are giving presentations or watching a video file.
Page 95 To switch display devices using shortcut key You can switch display devices easily by pressing <Fn>+<F4/ > shortcut key. Provided that multiple external display devices are connected, the display order is LCD > CRT > TV > LCD+CRT > LCD+TV > LCD whenever the <Fn>+<F4 / >...
Page 96: System Management
System Management Using Power Management Options Your computer includes Power Management options that can help the battery charge last longer and extend the life of the battery. Power-management options will slow down or shut off system components when the components are not being used. Power management may slow down system performance.
Page 97 84 Users Manual By default, the power scheme is configured to SAMSUNG mode. SAMSUNG mode extends the battery life and optimizes the Intel Speedstep function. Since the CPU power consumption is automatically...
Page 98 If You Reinstall Windows: You should re-establish hibernate in power options by opening Options Properties window and click on the Hibernate tab then click “Enable Hibernation”. Frequent Interruptions: If you experience frequent interruptions, you might also consider putting your computer into automatic hibernation after a specified number of minutes using the power management options.
Page 99 Advanced Power Management Schemes This section discusses the advanced power management schemes. There are two buttons that you can use to manually conserve power. To enter the power management window complete the following: 1. Click Start > Control Panel > Performance and Maintenance. 2.
Page 100: Using The Battery
Using the Battery Please refer to the following instructions when running the computer on battery power without connecting the AC power. Please read the instructions on the battery before use. Please refer to the system operation environment (p131) of this manual and operate and store the battery at room temperature.
Page 101: Monitoring The Battery Charge
Monitoring the Battery Charge You can view the battery charge status by completing the following procedures. To use the shortcut key to view Press the <Fn>+<F2/ source and the current remaining battery charge are displayed at the top left of the screen.
Page 102: Using The Battery Manager
Using the Battery Manager program, you can change the configuration of the LCD brightness, the sleep timer and system devices, and can extend the battery usage time to maximum. Click on Start > All Programs > Samsung > Samsung Battery Manager > Samsung Battery Manager. You can only change the detailed configuration in Custom Mode.
Page 103 • Custom Mode : In this mode, a user can configure a detailed configuration to save the battery usage time. A user can adjust the LCD brightness, select the time before the system sleeps, select the screen color quality and select the graphics mode.
Page 104: Battery Calibration
Battery Calibration Calibrating your battery once a month is one of the recommended methods of increasing your computer’s battery life. To calibrate the battery complete the following steps: Calibration Notes: You should start the battery calibration process with a fully charged battery, battery status LED is green.
Page 105: Removing The Memory Module
Upgrading Memory This computer has one or more 128 MB or 256 MB memory module(s). Two memory module sockets are provided so that you can replace memory or install an additional memory module. Removing the memory module Before removing/replacing the memory module, turn the system off completely.
Page 106: Adding A Memory Module
Adding a memory module 1. Align the new memory module connectors accordingly and slide it into the slot at ° a 30 angle. Ensure the notch on the memory module corresponds with the notch on the socket. 2. Push the memory module in until the module clicks into place. If the memory module is not fixed completely, gently push the memory down while pressing the memory module tabs outward.
Page 107: Using The Security Lock Port
Using the Security Lock Port The security lock is a device used to physically 'fix' the system when using it in a public place. The locking device needs to be purchased separately. The shape and methods of use may differ depending on the manufacturer. Please refer to the manual provided with the security lock for proper use.
Page 108: Tips For Using Your Computer
Tips for Using Your Computer The following information helps you avoid potential problems as you use your computer: Do not try to disassemble your computer. Opening the system chassis voids your warranty. Only an authorised manufacturer service center can replace or add any parts inside the chassis.
Page 109: Travelling With Your Computer
• To reduce the risk of ignition cause by small metallic object, such as paper clip or staples, moving around opening above keyboard, please lock the panel side with main enclosure during transportation. • The Docking Station Device is not transportable device. Travelling with Your Computer Air Travel If you are travelling by air, follow these tips:...
Page 110: Storing The Computer For Long Periods
Some liquids damage the polarized LCD screen. If your screen is damaged, contact your authorized manufacturer’s service center for a replacement. Storing the Computer for Long Periods If you will not be using the computer for a long period of time (a month or more), you should discharge the battery completely then remove the battery from the computer.
Page 111: Troubleshooting
Recovery CD to reinstall OS and System Software CD to reinstall the corrupt device drivers. System Recovery Precaution: Before you start restoring your windows operating system insure you backup all data on your hard drive. Samsung is NOT responsible for any data loss. 98 Users Manual...
Page 112: Questions And Answers
Questions and Answers This section provides information on possible problems, solutions and other references for system use. Windows Related Q1 The system does not shutdown properly. When the system does not shutdown normally, press and hold the Power button until the system manually shuts off. If the Power-Saving Mode is configured into the Power button, press and hold for more than 4 seconds to shut the system off.
Page 113: Display Related
Display Related Q1 The LCD screen is too dark or too bright Adjust the LCD screen brightness. Use the <Fn>+< Q2 The screen saver disturbs screen viewing during Media Player or video file operation. Unselect Tools > Options > Player > Allow screen saver during playback in the Media Player.
Page 114 Q7 A DVD or an MPEG file is only played on the LCD (ATI chipset model) When both the LCD and the CRT are being used simultaneously, video plays on one of them by default. Right-click over the Desktop and select Properties. In the [Display Properties] window, click the Settings tab >...
Page 115 original resolution is not restored when disconnecting the external display device, complete the following procedures. Press <Fn>+<F4 / Otherwise, click the Ati icon on the taskbar, and change the screen resolution to the correct setting. Q12 Pressing a function key in DOS mode does not display the OSD (status display icon) on the screen.
Page 116: Modem Related
Modem Related Q1 I cannot hear the modem sound. Check that the telephone line is properly connected to the modem. Check that the modem driver is installed properly. Click Start > Control Panel > Performance and Maintenance > System. Select Hardware tab > Device Manager > Modems in the System Properties window, and check if there is a yellow exclamation mark on the installed modem icon.
Page 117 In the Modem tab of the Modem Properties window, clear the 'Wait for dial tone before dialing' check box. When the configuration is completed, click OK. Q3 How do I use my modem when dialing from overseas? Check that the modem is correctly configured according to the current country. Because the values for communication may differ according to the country, you may not be able to connect via the modem due to an incorrect modem configuration.
Page 118: Wired Lan Related
Wired LAN Related Q1 <Wake On LAN> function <Wake On LAN> is a function that activates the system in rest mode when a signal (such as ping or magic packet commands) arrives from network (wired LAN). To use <Wake On LAN> function: Select My Network Places >...
Page 119: Wireless Lan Related
Wireless LAN Related Refer to ”Connecting Through a Wireless LAN (Option)” (p48) for the basic uses of a wireless LAN. Q1 The Wireless LAN device is operating properly, but I cannot connect to the Internet or to another computer. This is due to an incorrect configuration, or a configuration error. Check the following check lists: If you are using a computer-to-computer (Ad Hoc) network connection, check that the name of the configured network (SSID) is correct.
Page 120 Q3 I cannot share an Internet connection. It may require some time to synchronize the computers to share an Internet connection after the Internet connection sharing configuration is completed. If you cannot share Internet connection even after a longer period, restart the computer.
Page 121 - Verify whether the AP's firmware is the most recent version. (Contact the AP manufacturer or the place where you purchased the AP for details of the AP firmware.) Verify whether the AP has been properly connected to the network. Verify whether the network is operating normally by connecting the wired network cable, which has been connected to the AP, to your computer.
Page 122 disable the [View Available Wireless Networks] window supported by WZC service. Exit the wireless LAN related program then check whether the window is enabled. Initialize the device driver. Click Start > Control Panel > Performance and Maintenance > System > Hardware tab >...
Page 123 - A fixed IP is recommended for a small-size network. Q7 When using a computer-to-computer (Ad Hoc) network, sometimes I cannot search the access point. It may happen occasionally when you are using a computer-to-computer (Ad Hoc) network connection. Even if you cannot find some access points, the computer-to-computer (Ad Hoc) network is operating properly.
Page 124 This may be caused by selecting the ’Use IEEE 802.1x network authentication’ option when IEEE 802.1x authentication is not available. Check the properties of the AP in the wireless network settings. If the ’Use IEEE 802.1x authentication in this network’ option is selected, deselect the option on the Authentication tab.
Page 125 Click on "Use Microsoft Client" in the Tools menu of the PROSet program to manage a wireless network in Windows. To manage a wireless network in the PROSet program, click on "Use Inter PROSet/Wireless" in the Tools menu of the PROSet program. 112 Users Manual...
Page 126: Games And Programs Related
Games and Programs Related Q1 3D game is not executed, or some functions are not working. Change the graphic setting of the game to '2D' or 'Software Renderer', then execute the program again. Q2 I launched a game right after installing it, and the game is not executed. This problem may occur when the game is not compatible with Windows XP.
Page 127 Q5 <Fn+F4/ While displaying video of VCD or MPEG, or the display setting is Dual View, you cannot toggle display devices. Also the installation of NetWare Client 32 program disables the function of <Fn+F4/ Q6 While playing a game, pressing the <Fn>+<F4 / the screen is not properly displayed.
Page 128 Click the PowerPlay Settings button, and set the Plug-In, High Battery and Low Battery sliders to ‘Optimal Performance’ and then click Apply. (Intel chipset models) This may happen when using the DFGT function. Right-click over the Desktop and select Graphics Option > Graphics Properties >...
Page 129: Security Center
Security Center Q1 To change the popup window display settings when connected to the Internet. In the Windows XP SP2 environment, you can decide whether to display a popup window when connected to the Internet, for user convenience and security. To display most of the popup windows when connected to the Internet: Click on Internet Options in Start >...
Page 130 Q3 When you see a Windows Security Alert icon ( of the task bar. With the Security Center feature added, Windows XP SP2 checks the Firewall, the automatic updates configuration and installation of virus-checking programs to display a Windows Security Alert icon on the right part of the task bar when it judges that the computer is vulnerable to attacks from the Internet.
Page 131 If Windows does not recognize the existence of an anti-virus program even when it has been installed, your computer could be vulnerable to attacks from the Internet. You should install an anti-virus program that your computer is able to identify. Check the following programs which Windows can detect and select one from the list.
Page 132 HD TV Related Q1 On a component TV, the Full Screen DOS Mode screen does not display. A component TV does not support the Full Screen DOS Mode screen due to an output power problem of the TV. Please use DOS mode in a window when using a component TV.
Page 133 This happens when the TV does not support the component TV mode configured in the video driver. 1. Click Display Properties > Settings > Advanced > Display tab > YPbPr button. 2. Select the relevant modes (480i, 480p, 540p, 720p,1080i,16:9) and click the Apply button.
Page 134: Restoring The System
Restoring the System This description is only for models running Window XP. The System Restore function allows you to restore your computer to an earlier copy (called restore point), and restores the settings if a problem occurs.The System Restore function is provided by Windows XP to enable the resolution of various problems without reinstalling Windows XP completely.
Page 135: Returning Your Computer To An Earlier Restore Point
2. Select "Create a restore point", and click Next. Since changes made after the Recovery Point may not be maintained, please back-up all necessary files to another location before performing system recovery. 3. In the Restore point description box, type a name to identify the restore point, and than click Create.
Page 136 2. Select "Restore my computer to an earlier time", and then click Next. 3. Select the desired restore date from the calendar restoration and select the desired restore point from the list, and then click Next. The date of the restore point is displayed in bold font. 4.
Page 137: Undoing The Last Restoration
5. After the restoration is complete, Windows restarts. In the [System Restore completed] dialog, click OK.Your computer has been restored to the selected restore point. Undoing the last restoration The procedures to undo a restoration are described below. 1. Click Start > All Programs > Accessories > System Tools > System Restore. 2.
Page 138: Reinstalling Software
Reinstalling Software If you have reinstalled the Windows operating system, or the system and program do not operate properly, you can re-install the driver and program using the system software CD. This computer is optimized for Microsoft Windows XP, therefore driver other than the ones included in the System Software CD are not provided.
Page 139: Installing Drivers And Programs
Installing drivers and programs 1. Click Standard Installation in the main window of the System Software CD. (Standard Installation is recommended) 2. The system is scanned to display the drivers and programs that need to be installed. 3. Click OK. The drivers and programs are automatically installed as factory defaults.
Page 140: Reinstalling Windows Xp
Reinstalling Window may delete the data on the hard disk drive such as files, programs, etc. In order to minimize damage from data loss, please remember to always back up data. Samsung Electronics is not liable in the case of data loss, please consult your warranty statement for clarification.
Page 141 • Standard installation: You can change the settings for partitioning, the installation folder, etc. during the Windows installation. However, reinstalling Windows may delete the data on the hard disk drive such as files, programs, etc. In order to minimize damage from data loss, please remember to always back up data.
Page 142 8. When a window that requires your name and organization pops up, enter your name and the organization and click Next. In the Windows XP Professional edition, an additional window that requires the computer name and the administrator password appears. Enter the computer name and the administrator password and click Next.
Page 143 If You Cannot Run Windows If you cannot run Windows, you have to boot the system with the system recovery CD, and reinstall Windows. If you boot the system from the system recovery CD, you can install Windows only with the user installation option. You cannot install with the standard installation option.
Page 144: System Specification
Specifications System Specification The system specifications will be described below. The system specifications may differ depending on the derived models. With an Intel Graphics Chipset Item Specification Intel Pentium M 1.6GHz~ / Dothan (FSB533) / Celeron M Cache memory 2MB (Dothan) / Celeron 1MB Main memory 256/512/1024 MB DDR2 SDRM, 2 DDR2 socket Main Chipset...
Page 145 The system specifications are subject to change without notice. For detailed system specifications, refer to the product catalog. *) Using the AC adapter (60W) in other models may cause a system malfunction. Please use only an AC adapter specified in the system specification. With an ATI Graphics Chipset Item Specification...
Page 146: Product Specification
Wireless LAN Specification (Optional) Intel(R) PRO/Wireless 2200BG Network Connection Product Specification Item Physical Dimensions Specifications operation temperature and humidity Power Specification Power Saving Mode Receiving Mode Transmission Mode Power Network Compatibility Specifications Operating System Media Access Protocol Security * This piece of equipment supports the Wi-Fi wireless LAN security standard, WPA (Wi-Fi Protected Access) and CCX (Cisco Compatible eXtensions).
Page 147: Channel Allocation
PROSet may be required depending on the network settings. For driver update, visit www.samsung.com and for information on the PROSet installation, refer to ”Wireless Network Setup Using the Wireless LAN Setup Program” (p57). For more information, ask your network administrator.
Page 148 Radio Specifications RF Band Support Channels Device Standard Output Power Transmission Method Transmission Rate (Mbps) * Antenna Type * The transmission rate may differ from the actual transmission rate. ** 11a mode is supported only when the device is connected with an IEEE802.11a device (e.g. IEEE802.11a compatible Access Point).
Page 149 Abbreviations A ..Amperes AC ..Alternating current ACPI ..Advanced Configuration and Power management Interface APM ..Advanced Power Management ATA.
Page 150 ISA ..Industry Standard Architecture KB ..Kilobytes kg ..Kilograms LAN..Local-area network lb..
Page 151 Glossary AC adapter The AC (or alternating current) adapter regulates current coming into your computer from the wall outlet. The current at the wall outlet is alternating current and needs to be changed by the adapter to DC (direct current) before your computer can use it for power.
Page 152 CardBus CardBus technology enables the computer to use 32-bit PC Cards. Hardware in the computer and the Windows operating system provide support for the 32-bit cards. The voltage of 32-bit cards (3.3 volts) is lower than that of 16-bit cards (5 volts).
Page 153 Hard drive Also called fixed disk. A hard drive is connected to the computer and can be installed or removed. Data written to a hard drive remains until it is overwritten or corrupted. The 2.5-inch hard drive in your computer was designed for use in a notebook computer.
Page 154 PC Card PC Card stands for personal computer card. The Personal Computer Memory Card International Association (PCMCIA) defines the standards used to develop all PC Cards. PC Card types include: modems, Ethernet adapters, SCSI adapters, ATA cards, and memory cards. PC slot The PC slot is the hardware slot in the computer where the PC Card is placed.
Page 155 Shadow RAM A write-protected area of RAM that contains a copy of the BIOS. As the computer boots, the BIOS is copied from its permanent location in ROM to RAM. The BIOS can be executed much faster in RAM than in ROM. The BIOS remains in shadow RAM until you turn off the computer.
Page 156: Getting Started
SAMSUNG P40 BA68-02850A10 050110 Chapter 1 Chapter 1 Getting Started This chapter provides basic information for using this computer. System overview and methods for general use are provided.
Page 157: Introducing The Computer
Introducing The Computer Front View LCD Panel Status Indicators (P. 1-12) Keyboard (P. 1-9) Touchpad (P. 1-7) Touchpad Button Status Indicators The Fingerprint Identification System is optional. See also the appropriate user's guide to find more information. Manual LCD Latch Microphone (P.
Page 158 Right View Headphone Jack You can install various other multi-bay devices in the multi-bay of the system. For procedures to replace the multi-bay device, refer to Chapter 3. Using Multi-Bay. Left View Infrared Communication Port (P. 4-28) Security Lock Port (P.
Page 159: Rear View
Rear View 1394 Port (6 Pin) Bottom View Speaker Removing or disassembling the hard disk drive will void your warranty. To replace the hard disk drive, please contact your nearest Samsung Service Centre. Manual Serial Port Parallel Port Monitor connector TV Output Port USB 2.0 Port...
Page 160 Turning the Computer On and Off Turning On 1. Insert the battery and connect the power according to the supplied Installation Guide. 2. Lift up the LCD panel and open it to a comfortable angle. 3. Press and then release the power button to turn the system on. Turning Off 1.
Page 161: Changing Users
Creating and Changing User Accounts Multiple users can be registered in a single system so that each user may use their own customized working environment. Procedures to register and change user accounts are provided below. ■ Registering a new user 1.
Page 162 Touchpad Movement of the pointer (arrow) on the screen will correspond to movement made with a finger on the touchpad. Touchpad buttons the two buttons below the touchpad provide identical functions to buttons of a mouse. Locking the touchpad You can lock the touchpad and use only the keyboard and mouse. To lock the touchpad function, press the <Fn>+<F9>...
Page 163: Using The Touchpad Scroll Function
■ Drag (Move / Select) Drag and drop a part to the required place. ■ Using the Touchpad Scroll Function The touchpad has a scroll function, which can be used like the wheel dial of a wheel mouse. Move up and down along the right edge of the touch pad (scrolling up and down) or left and right along the bottom edge of the touch pad (scrolling left and right) to scroll the screen.
Page 164: Special Function Keys
Using the Keyboard Function Keys <Fn> Key ■ Special Function Keys: Key Com- binations Name Puts the computer into power saving mode. To use the com- Power Saving puter again, press the power button. Mode Gauge You can check the power supply, the battery charge, the wireless LAN, and the volume status.
Page 165 1-10 Manual Function Gauge You can check the power supply, the battery charge, the wireless LAN, and the volume status. Power Supply Status When operating on AC power Remaining Battery Charge Level Wireless LAN Status Wireless LAN Enabled Volume Status Sound On Screen Adjustment Key Moves up and down pages, or moves the cursor to the start or end of a line.
Page 166 Hot Keys : Runs Internet Explorer. Internet key E-mail key : Runs the Internet e-mail client program (Example: Outlook Express). User Button (User 1) : You can launch a frequently used program by press- ing the button. By default, Windows Calculator is configured to be launched when you press this button.
Page 167: Status Indicators
Status Indicators Shows the operating status of the computer. Icon Num Lock Caps Lock Scroll Lock Charger Power Hard disk drive 1-12 Manual Name Description Turns on when the numeric keypad is activated. Turns on when all alphabet characters you type will be Turns on when it is set to scroll the screen up and down while the cursor position does not change in some applications.
Page 168 Maintaining your LCD brightness settings after turning the system off and on 1. Turn the system on. When the Samsung Logo appears, press the <F2> key to enter Setup. 2. In the Boot menu, change the Brightness Control Mode option to User Control.
Page 169 Adjusting the Volume ■ To adjust using keyboard Press <Fn>+< The changed volume level is displayed on the upper part of the screen for a few seconds ■ Using the Volume Control Program On the taskbar, click the Volume ( For advanced volume control options, double-click the Volume ( adjust the settings in the [Master Volume] dialog.
Page 170: Proper Seating Posture During Computer Use
Proper Seating Posture During Computer Use The proper seating posture during computer use is provided here. Maintaining proper posture during computer use enhances performance and prevents physical bodily harm. If necessary, use a footrest to raise the level of your knees and ease the pressure on the thighs.
Page 171 1-16 Manual...
Page 172 Chapter 2 Chapter 2 Introducing Windows This chapter provides basic information on using the computer’s main operating system Windows.
Page 173: Windows Xp Basics
SAMSUNG P10 Windows XP Basics Windows is the computer’s main operating system, which needs to be familiarized with in order for efficiently computer use. Windows XP Tour A tour of the elementary functions provided by Windows XP. Click Start > Tour Windows XP.
Page 174 Understanding the Desktop The Desktop is the working area on the computer. It consists of the large workspace, which is more or less the entire the screen and a Taskbar at the bottom. Desktop Icons You can directly launch a program. Start Menu Start Button Start Button...
Page 175 Understanding the Start Menu The Start Menu includes everything that is required to start Windows. From the Start Menu it is possible to run a program, open a file, assign system users with the Control Panel, receive support by clicking Help and Support, and search desired items from computer or Internet by clicking Search.
Page 176 Understanding a Window A window is the basic component in working with the computer. The My Computer window, which is a window for the computer’s hard drive, will be used as an exam- ple here to show the basic composition of a window. Click Start >...
Page 177 Help and Support Center Help and Support Center provides references and troubleshooting information regarding computer use. Click Start > Help and Support. Displays Help Index Related help information appears when a search keyword is entered. Help Topics Troubleshooting Information Manual Connect to Support Center.
Page 178: Document Operations
Document Operations To create documents, WordPad or NotePad, which is included in Windows, or a separate specialized word processor program can be used, such as MS Word. Instructions for creating documents using WordPad is provided here. ■ Creating a New Document 1.
Page 179: Opening A Document
■ Opening a Document 1. Click Start > All programs > Accessories > WordPad. 2. Select File From the Menu, and click Open. 3. Click on the Look in field and specify the folder in which the file is saved. 4.
Page 180: Using The Computer
Chapter 3 Chapter 3 Using The Computer This chapter investigates various different functions of the computer and provides information on using the related application programs for them.
Page 181: Using The Cd-Rom Drive
Using the CD-ROM Drive This computer has one of the following CD drives. - DVD-ROM Drive - CD-RW/DVD-ROM Combo Drive - DVD-Super Multi Drive To Run a CD 1. Press the eject button on right side of the CD drive. 2.
Page 182: Using The Windows Media Player
Using the Windows Media Player The Windows Media Player enables the user to configure and play video and audio files from the computer or the Internet. Click Start > Windows Media Player. Or click Start > All Programs > Accessories > Entertainment > Windows Media Player.
Page 183: To Play An Audio Cd
To Play an Audio CD 1. Insert an audio CD into the CD drive, and a list of all available players is displayed automatically. 2. Select Windows Media Player, and click OK to play the audio CD. To Play a Video CD 1.
Page 184: To Write Data In Cd
To Write Data in CD If your computer has CD-RW functionality, you can copy data to a blank CD or cre- ate an audio CD. An additional CD writing program is supplied in an additional CD. 1. Insert a blank CD into the CD-RW drive. 2.
Page 185 5. When the CD Write Wizard appears, enter the CD label, and click Next. The data will begin copying. 6. When copying is completed, a ‘completed’ message will appear and the CD-ROM drive will open automatically. For more information on copying CDs Click Start >...
Page 186 Using the Multi-Bay Multi-Bay provides space for CD drive installations. You can replace the CD drive with various other types of drives.The procedures to replace the drive installed in the Multi-Bay with other drives are described below. 주의 Before Replacing the Multi-Bay Replace the Multi-Bay only after turning the computer off.
Page 187 Using Memory Card Slot You can use a Memory Stick (or Memory Stick Pro) and a SD (Secure Digital) card using the memory card slot. You can use the Memory Stick and the SD card as removable disks and can use them to trans- fer data between your computer and any digital equipment such as a digital camera.
Page 188 2. Click Start > My Computer. The inserted memory card is displayed. 3. You can write data to the memory card. If the memory card is not formatted yet, format the memory card before use. Since the memory card may be easily mislaid when moving your computer, keep the memory card separately.
Page 189: Working With Pcmcia Cards
Working with PCMCIA Cards Various different functions can be added by inserting PCMCIA cards into the system. This system supports 16/32 bit, type I or II PCMCIA card types. 1. Insert a card into the PCMCIA card slot on the side of the system. 2.
Page 190: Using Easybox
Learn about EasyBox Double-click the EasyBox( ) icon on the desktop. (Or select Start > All Programs > Samsung > EasyBox > EasyBox.) ▶ System : System management features are available, including disk defrag- menter, removing unnecessary files/folders, computer scheduling and system recovery.
Page 191 The Windows Firewall prevents unauthorized users from gaining access to your system via the network or the Internet. 1. Click Start > All Programs > Samsung > EasyBox > EasyBox. 2. Click Security from the top menu bar. 3. Select Windows Firewall Settings from the Security menu on the left.
Page 192 1. Click Start > All Programs > Samsung > Samsung Smart Screen. When you launch Samsung Smart Screen for the first time, a dialog box asking whether to register the program as a start program or not appears. If you select OK, the program is automatically launched when you start your computer.
Page 193 Using Samsung Theme Samsung Theme is a program that enables a user to easily switch a theme (desktop, logon screen and sound effect). Double-click the Samsung Theme ( (Or select Start > All Programs > Samsung > Samsung Theme >...
Page 194 Using Samsung Update Plus Samsung Update Plus is software that examines and updates Samsung software and drivers installed on your Samsung computer to the latest version. To use Samsung Update Plus, your computer has to be connected to the Internet. ■...
Page 195 Click the balloon help icon in the notification area. Here you will be able to find the latest available updates. To change the automatic update settings, click the Custom button in Figure 2 and change the settings. : Samsung Update Plus does not provide updates for additionally installed software and device drivers. 3-16 Manual...
Page 196: Using Samsung Command Center
Using Samsung Command Center Samsung Command Center is a program that enables the easy man- agement of software provided for a Samsung computer. You can view brief descriptions of some programs and you can launch the programs directly. Samsung Command Center is always hidden automatically and it appears when you place the mouse cursor in the right-most position.
Page 197 S/W List Area : ▶ AV Station Area ▶ Samsung Update Plus Area : When there is new software or a new 3-18 Manual Shows software included in the S/W group. You can add a file that can be launched directly from the Desktop or Explorer by dragging and dropping it.
Page 198: Connecting To The Internet
Chapter 4 Chapter 4 Connecting to the Internet This chapter provides instructions on connecting to the Internet.
Page 199 Connecting to the Internet The following options show many ways to connect to the Internet. An appropriate option should be selected depending on the user’s work- ing environment and the user’s system specifications. Option 1 Connecting using a modem and a telephone line. Option 2 Connecting using a High-speed communication Option 3 Connecting using a wired LAN Option 4 Connecting using a wireless LAN...
Page 200: Connecting To The Internet Using A Modem
Connecting to the Internet Using a Modem 1. Connect the telephone line to the modem port. Do not use a digital telephone line. 2. To connect the modem to the Internet, and use e-mail, you have to apply to an Internet Service Provider (ISP) for an Internet service.
Page 201: Configuring The Network Environment Settings For Wired Lan Connections
Configuring the Network Environment Settings for Wired LAN Connections A wired LAN environment is an environment where you can connect to the Internet using the company’s LAN or with a broadband modem. 1. Connect the network (LAN) cable to the LAN port of the system. 2.
Page 202 7. In the “This connection uses the following items” field, select Internet Protocol (TCP/IP), and click Properties. In the above screen, necessary network components can be added by clicking the Install button. 8. Enter the system’s IP and DNS server addresses on the General tab of the [Internet Protocol (TCP/IP) Properties] window.
Page 203 1. Connect LAN cable to the computer’s LAN port. 2. Double-click Samsung Network Manager icon on the desktop. Or click Start > All Programs > Samsung Network Manager > Samsung Network Manager. 3. When you are using DHCP, available IP’s are displayed in the status dialog box.
Page 204 To change network places You can change network places as below. 1. Connect LAN cable to the computer’s LAN port, and double-click Samsung Network Manager icon on the desktop. If you used static IP in previous place, previous static IP is displayed in the status dialog box.
Page 205 Internet Connection Share service. ▶ To configure the server, 1. Connect the network (LAN) cable and double-click the Samsung Network Manager icon on the Desktop. 2. Click Click here to setup Internet Connection Share.
Page 206 8. The current location is represented as a server. The server configu- ration is complete. ▶ To configure the client, 1. Connect the network (LAN) cable and double-click the Samsung Network Manager icon on the Desktop. 2. Click Click here to setup Internet Connection Share.
Page 207: Using Both Dhcp And Static Ip Simultaneously
Using Both DHCP and Static IP Simultaneously When you are alternatively using networks with either DHCP or static IP address- ing, you can use alternative settings that enable simultaneous configurations of DHCP and static IP to use both of the network connections without reconfiguring. 1.
Page 208: Configuring The Network Environment Settings For Wireless Lan Network
Configuring the Network Environment Settings for Wireless LAN Network A wireless network (Wireless LAN) environment is a network environment that enables communication between multiple computers at home or a small-size office through wireless LAN devices. When a computer-to-computer network has been constructed, a computer that is not connected to the Internet can share the Internet by accessing another computer connected to the Internet.
Page 209: Connecting To An Access Point
Connecting to an Access Point This section describes how to connect to an AP. You can use the network when you are connected to an AP. 1. Right-click on the Wireless Network Connection ( and select View Available Wireless Networks. 2.
Page 210 Connecting to computer-to-computer networks (peer-to-peer or ad hoc) In computer-to-computer wireless networks, you can wirelessly connect 2 or more computers that have wireless LAN modules. Using this method, a computer that is not connected to the Internet can share the Internet by accessing another computer connected to the Internet.
Page 211 Select ‘Computer-to-computer (ad hoc) networks only’, and click Close. 5. In the Wireless Networks tab, click Add. 6. Enter the network name (e.g. samsung), and unselect ‘The key is provided for me automatically’. Enter the encryption key in the Network key field, and click OK.
Page 212 7. Check that the configured network name (e.g. samsung) is in the ‘Preferred networks item’, and click OK. Now your wireless network setup has been completed. 4-15 Chapter 4. Connecting to the Internet...
Page 213 1. Right-click on the Wireless Network Connection ( and select View Available Wireless Networks. 2. Select the wireless network name (e.g. samsung) specified in “Connecting to computer-to-computer networks (peer-to-peer or ad hoc)”, and click Connect. 3. Enter a cryptographic key in the network key box and click Connect.
Page 214 Wireless Network Setup Using the Wireless LAN Setup Program. You can use a wireless LAN by using a wireless LAN configuration program (PROSet) provided separately. To use wireless network connection, complete the following procedures. Step1. Install the wireless LAN configuration program (PROSet). ▶...
Page 215 In Available Networks, click on Refresh. 2. Select the name of desired access point or computer-to-computer network to connect from the searched available networks list, and click Configure. 3. Enter Profile Name and click Next. 4. In the Search Security Settings window, the wireless network security search message will appear.
Page 216 Network name (SSID) is a name that a wireless adapter uses for identifying connection. Enter the name of computer-to-computer network to create (e.g., samsung) or the name of access point to connect. The network name identifies cases. (capital and lowercase) For the name of access point, check the settings of the access point, or ask your wireless network administrator.
Page 217 Using Network Services While the computer is connected to the network, you can use network services to share files, folders, and printers. Sharing files or folders This section describes how to share files and folders between computers connected to the network. To share files, complete the following procedures: Step 1.
Page 218 ■ Step 1. Configuring Sharing 1. Right-click the target file or folder to share in My Computer, and select Sharing and Security. 2. Click ‘IF you understand the security risks but want to share files without running the wizard, click here’. It has the same security effect as that of the ‘Network Setup Wizard’.
Page 219 ■ Step 2. Using Shared Files or Folders This section describes how to access shared files or folders if your computer is a member of the same workgroup. 1. Click Start > My Computer. Under Other Places, click My Network Places in your computer.
Page 220 Sharing Printers This section describes how to share a printer between computers connected to a net- work. To share a printer, complete the following procedures: Step 1. Configure printer sharing in the computer connected to the printer. ▶ ▶ Step 2. Add and use the shared printer in other computers on the network. ■...
Page 221 4. In the Printers and Faxes window, you will find the printer icon has been changed to another icon on a hand. ■ Step 2. Adding and Using a Shared Printer 1. From a different computer that wants to use the shared printer, click Start > Printers and Faxes.
Page 222 7. Read the warning about a shared printer, and click Yes to install the shared printer. 8. Select Yes for ‘Do you want to use this printer as a default printer?’, and click Next. 9. Click Finish. 10. When the printer sharing configuration has been completed, the shared printer appears in the Printers and Faxes window.
Page 223: Using Bluetooth Devices
Using Bluetooth Devices You can transfer files between Bluetooth devices, use the Internet, and construct a Personal Area Network. In addition, you can use a wireless keyboard, wireless mouse, and a wireless printer that have the Bluetooth function. ■ The following functions are provided by the Bluetooth software.
Page 224 ▶ Using a Personal Area Network You can exchange files between computers by connecting to the shared folder of another computer via a Personal Area Network. For more detailed procedures on using the Personal Area Network, refer to “Join a personal area network” , “Provide a name for your computer on a personal area network”and “Bluetooth person- al area networking overview”of the Bluetooth On-line help.
Page 225 Infrared Communication Your computer may have infrared port. Using the infrared port, you can transfer data to computer, printer, camera and other devices through infrared communication. ■ To establish infrared connection The procedures to communicate with another computer through infrared port are described below.
Page 226 If you cannot use infrared communication 1. Check BIOS setup. a. Start the computer, and press <F2> to enter System Setup. b. Select I/O Device Configuration in the Advanced menu, and press <Enter>. c. Select Infrared Port, and set the item to Enabled by press- ing <F5>...
Page 227 4-30 Manual...
Page 228: System Management
Chapter 5 Chapter 5 System Management This chapter provides information on efficient computer management.
Page 229: Managing Power
Power Options > Power Schemes tab. Then specify time in each item and click OK. By default, the power scheme is configured to SAMSUNG mode. SAMSUNG mode extends the battery life and optimizes the Intel Speedstep function. Since the CPU power consumption is automatically optimized to conserve power when the computer is operating on battery power, an application may be executed slower than when it is operating on AC power.
Page 230: Using The Power Button
Using the Power button You can configure the function of the power button. Click Start > Control Panel > Performance and Maintenance > Power Options and select the Advanced tab. When the Power button is configured to put the system into Power-Saving Mode, man- ually shutting down the computer requires the Power button to be pressed and held for more than 4 seconds.
Page 231 Using the Battery Please refer to the following instructions when running the computer on battery power without connecting the AC power. This computer uses smart rechargeable Lithium-Ion (Li-Ion) battery. Ejecting and Attaching Battery 1. Shutdown system and close LCD. 2. Put the computer upside down. 3.
Page 232: Monitoring The Battery Charge
Monitoring the Battery Charge You can view the battery charge status by completing the following procedures. ■ Using the shortcut key to view Press the <fn> + < > key combination on the keyboard and then the current power source and the current remaining battery charge are displayed at the top left of the screen.
Page 233: Increasing Battery Life
Using the Battery Manager program, you can change the configuration of the LCD brightness, the sleep timer and system devices, and can extend the battery usage time to maximum. Click on Start > All Programs > Samsung > Samsung Battery Manager > Samsung Battery Manager You can only change the detailed configura- tion in Custom Mode.
Page 234 Controlling the LCD Brightness If you restart the system after changing the LCD Brightness in Custom Mode, the LCD brightness is changed to its default value. To keep the brightness value configured in Custom Mode, configure the [Brightness Control Mode] item to 'User Control' in the [Boot] menu of the System Setup.
Page 235: Upgrading Memory
Upgrading Memory This computer has one or more 128 MB or 256 MB memory module(s). Two memory module sockets are provided so that you can replace mem- ory or install an additional memory module. 1. Using a screwdriver, open the memory-module compartment cover on the bottom of the system.
Page 236 3. Align the new memory module connectors accordingly and slide it into the slot at a 30˚ angle. 4. Push the memory module in until the module clicks into place. If the memory module is not fixed completely, push the module while pressing the memory mod- ule tabs outward.
Page 237: Using The Security Lock
Using the Security Lock The security lock is a device used to physically ‘fix’ the system when using it in a pub- lic place. The locking device needs to be purchased separately. The shape and meth- ods of use may differ depending on the manufacturer. Please refer to the manual provided with the security lock for proper use.
Page 238: Traveling With The Computer
Traveling with the Computer When traveling, keep the system and the AC adapter disconnected. Otherwise, it may affect the functions of the system. Make sure that the system is not pressed by a book or heavy objects. The LCD may get damaged. When traveling by plane, use a bag designed for notebook PCs and hand-carry the computer.
Page 239 5-12 Manual...
Page 240: Customizing Your Computer
Chapter 6 Chapter 6 Customizing your computer This chapter provides information how to use the system setup, customizinig screen settings.
Page 241: To Enter System Setup
Using System Setup System Setup is a utility that enables the computer environment to be changed to suit the user. System Setup is used when changing the system password, booting priority, or when adding new devices. Please use extra care when configuring System Setup, as it may cause serious system error.
Page 242: System Setup Menus
System Setup Menus Menu Items Description Main Configures the basic system environment Advanced Configures OS and major chipset options of the system Security Configures system security options Boot Configures booting options Exit Exits System Setup For more information on System Setup menus or options, please refer to Help on the right side of the screen.
Page 243 By configuring a supervisor password, you can restrict system access to autho- rized users only. Do not lose or forget your password. If you have forgotten your password, contact the Samsung service center. 1. Select the Security menu in the System Setup. (To enter into System Setup, see Page 6-2.) 2.
Page 244 ■ Setting the User Password You can configure user passwords so that other users can use the system. Before configuring a user password, a supervisor password must have been con- figured. Users can start the system with their user password, but cannot enter into the System Setup.
Page 245 Changing Booting Priority You can select the booting priority among the devices such as the hard drive, CD-ROM drive, etc. The following example describes how to con- figure the hard drive as the first booting device when the CD-ROM drive is configured as the first booting device by default.
Page 246 Configuring Resolution and Color Depth Screen resolution is the number of pixels displayed on the screen. High resolution makes the overall screen area large, although individual items appear small. Color quality is determined by the number of bits used to represent a pixel on the screen.
Page 247: Using External Display Devices
Using External Display Devices (ATI Chipset model, refer to P.6-7) Using external display devices such as a monitor, projector, TV, etc allows you to view screen images alternatively or simultaneously on each device. Additionally, you can extend the screen onto two display devices to use a larger workspace.Using external display devices is especially useful when you are giving a presentation or watching a movie through your TV.
Page 248 2. Press the <Fn> + < > key. Provided that an external display device is con- nected, the display option changes in LCD > CRT > LCD+CRT order whenever the key is pressed. Provided that multiple external display devices are connected, the display order is LCD>CRT>TV>LCD+CRT>LCD+TV>LCD whenever the <Fn>+<...
Page 249 4. When you have completed this, click OK on the left of the Troubleshoot button. The primary display device (the LCD) is indicated as ‘1’, and the secondary dis- play device is indicated as ‘2’. Now you can use each of the two display devices as independent display devices.<Enter>...
Page 250 Using External Display Devices (Intel Chipset model, refer to P.6-7) Using external display devices such as monitor or projector, you can view the screen images alternatively or simultaneously. You can extend the screen into two display devices to use larger workspace. Using external display devices would be especially useful when you are giving presentations or watching a video file.
Page 251 Monitor Notebook Intel(R) Dual Display Clone Extended Desktop 6-12 Manual Displays on an external device such as monitor or a projector. You can only view the screen on the TV. Displays on the notebook LCD only. Displays the same screen on the notebook LCD, and an external device such as monitor or projector.
Page 252: Checking For Viruses
Checking for Viruses The Norton AntiVirus software is provided as the virus inspection program. When you first run Norton AntiVirus, the Norton AntiVirus Configuration window pops up. If you complete the configuration and your computer connect to network, you can download and install the latest updates via the network. When the live update is done, virus scanning starts automatically.
Page 253 6-14 Manual...
Page 254: Recovering The Computer
Chapter 7 Chapter 7 Recovering the Computer This chapter provides recovery procedures using the System Recovery CD when the computer is not operating properly.
Page 255 Restoring the System The System Restore function allows you to restore your computer to an earli- er copy (called restore point), and restores the settings if a problem occurs. The System Restore function is provided by Windows XP to enable the reso- lution of various problems without reinstalling Windows XP completely.
Page 256 ■ Returning your computer to an earlier restore point The procedures to return your computer to an earlier restore point when a problem has occurred are described below. 1. Start > All Programs > Accessories > System Tools > System Restore. 2.
Page 257 Reinstalling Software If you have reinstalled the Windows operating system, or the system and program do not operate properly, you can re-install the driver and pro- gram using the system software CD. ■ Running the system software CD Insert the system software CD into the CD-ROM drive. The initial screen appears automatically.
Page 258 ■ Installing drivers and programs 1. Click Standard Installation in the main window of the System Software CD. (Standard Installation is recommended) 2. The system is scanned to display the drivers and programs that need to be installed. 3. Click OK. The drivers and programs are automatically installed as factory defaults.
Page 259 Reinstalling Window may delete the data on the hard disk drive such as files, programs, etc. In order to minimize damage from data loss, please remember to always back up data. Samsung Electronics is not liable in the case of data loss, please consult your warranty statement for clarification.
Page 260 Quick Installation : This re-installs Windows with the user data and the system configuration intact. The user data in the already existing Windows folders may be preserved as the existing Windows folders are overwritten. 3. The description for the standard installation appears. Click Yes. The installation starts, and the system will be restarted after a while.
Page 261 ■ If You Cannot Run Windows If you cannot run Windows, you have to boot the system with the system recovery CD, and reinstall Windows. If you boot the system from the system recovery CD, you can install Windows only with the user installation option. You cannot install with the standard installation option.
Page 262: Windows Related
Q&A This section provides information on possible problems, solutions and other references for system use. Windows Related Q1The system does not shutdown properly. A When the system does not shutdown normally, press and hold the Power but- ton until the system manually shuts off. If the Power-Saving Mode is config- ured into the Power button, press and hold for more than 4 seconds to shut the system off.
Page 263 Display Related Q1 The LCD screen is too dark or too bright. A Adjust the LCD screen brightness. Use the <Fn> + < Q2 The screen saver disturbs screen viewing during Media Player or video file operation. A Unselect Tools > Option > Player > Allow screen saver during playback in the Media Player.
Page 264 1. Right-click over the Desktop and select Properties. 2. In the [Display Properties] window, click the Settings tab > Advanced > ATI Overlay tab. 3. Select the Theater Mode option, and then configure the Overlay Display Mode to ‘Theater Mode’ or ‘All The Same’ and then click on Apply. Then you can view the video on both the LCD and CRT screens.
Page 265 Modem Related Q1 I cannot hear the modem sound. A1 Check that the telephone line is properly connected to the modem. A2 Check that the modem driver is installed properly. 1. Click Start > Control Panel > Performance and Maintenance > System.
Page 266 Q3 How do I use my modem when dialing from overseas? A1 Check that the modem is correctly configured according to the current country. Because the values for communication may differ according to the country, you may not be able to connect via the modem due to an incorrect modem configura- tion.
Page 267 Wired LAN Related Q1 <Wake On LAN> Function. A <Wake On LAN> is a function that activates the system in rest mode when a sig- nal (such as ping or magic packet commands) arrives from network(wired LAN). ▶ To use <Wake On LAN> function 1.
Page 268 Wireless LAN Related Refer to (P.4-11) “Configuring the Network Environment Settings for Wireless LAN Network (WLAN)” for the basic uses of a wireless LAN. Q1 The Wireless LAN device is operating properly, but I cannot connect to the Internet or to another computer. This is due to an inappropriate configuration.
Page 269 Q3 I cannot share an Internet connection. A1 It may require some time to synchronize the computers to share an Internet connection after the Internet connection sharing configuration is completed. If you cannot share Internet connection even after a longer period, restart the computer. A2 Check if the connection between the network adapters is configured to bridge.
Page 270 A5 Verify whether the AP has been properly connected to the network. Verify whether the network is operating normally by connecting the wired network cable, which has been connected to the AP, to your computer. A6 Check the network key settings (encryption key). When automatic code conversion (a passphrase function) has been selected and data communication is not functioning even with a normal wireless connection, it is recommended entering the network key (encryption key) manually.
Page 271 A3 Initialize the device driver. Click Start > Control Panel > Performance and Maintenance > System > Hardware tab > Device Manager > Network adapters, and select the wireless LAN adapter. Right-click the network adaptor and select 'Disable' from the popup menu. Then right-click over the network adaptor and select 'Enable' after a short wait to check that the device is operating properly.
Page 272 Q7 When using a computer-to-computer (Ad Hoc) network, sometimes I cannot search the access point. A It may happen occasionally when you are using a computer-to-computer (Ad Hoc) network connection. Even if you cannot find some access points, the computer-to-computer (Ad Hoc) network is operating properly. Click Refresh to view the latest search result.
Page 273 A3 If the AP is configured to ‘Use network authentication (Shared Key)’ If the AP is configured to authentication shared mode, all computers to be con- nected should be configured as follows: If you are using Windows XP, select network authentication(shared mode) in the wireless network settings.
Page 274: Game/Program Related
Game/Program Related Q1 3D game is not executed, or some functions are not working. A Change the graphic setting of the game to ‘2D’ or ‘Software Renderer’, then exe- cute the program again. Q2 I launched a game right after installing it, and the game is not executed.
Page 275 Q5 <Fn>+< A While displaying video of VCD or MPEG, or the display setting is Dual View, you cannot toggle display devices. Also the installation of NetWare Client 32 program disables the function of <Fn>+< Q6 While playing a game, pressing the <Fn>+< work or the screen is not properly displayed.
Page 276 (Intel chipset models) A This may happen when using the DFGT function. 1. Right-click over the Desktop and select Graphics Option > Graphics Properties > Device tab. 2. Click Notebook and click ‘Power Schemes Settings'. 3. Unselect 'Intel¢Á Dual-Frequency Graphics Technology'. 4.
Page 277 Security Center Q1 To change the popup window display settings when connected to the Internet. In the Windows XP SP2 environment, you can decide whether to display a popup window when connected to the Internet, for user convenience and security. A1 To display most of the popup windows when connected to the Internet: 1.
Page 278 Q3 When you see a Windows Security Alert icon appear on the right part of the task bar. With the Security Center feature added, Windows XP SP2 checks the Firewall, the automatic updates configuration and installation of virus-checking programs to display a Windows Security Alert icon on the right part of the task bar when it judges that the computer is vulnerable to attacks from the Internet.
Page 279 A5 If Windows does not recognize the existence of an anti-virus program even when it has been installed, your computer could be vulnerable to attacks from the Internet. You should install an anti-virus program that your computer is able to identify. Check the following programs which Windows can detect and select one from the list.
Page 280 HDTV Related Q1 On a component TV, the Full Screen DOS Mode screen does not display. A A component TV does not support the Full Screen DOS Mode screen due to an output power problem of the TV. Please use DOS mode in a window when using a component TV.
Page 281 Q5 The screen does not display on the component TV. (ATI chipset models) A This happens when the TV does not support the component TV mode configured in the video driver. 1. Click Display Properties > Settings > Advanced > Display tab > YPbPr button. 2.
Page 282 Appendix Appendix Appendix System specifications, software types and safety instructions are provided here.
Page 283: System Specifications
System Specifications The system specifications will be described below. The system specifications may differ depending on the derived models. with an Intel Graphics Chipset Item Intel Pentium M 1.6 GHz ~ / Dothan (FSB533) / Celeron M Cache memory 2 MB (Dothan) / Celeron 1MB Main memory 256/512/1024 MB DDR2 SDRAM, 2 DDR2 socket Main Chipset...
Page 284 with an ATI Graphics Chipset Item Specification Intel Pentium M 1.6 GHz ~ / Dothan (FSB533) / Celeron M Cache memory 2 MB (Dothan) / Celeron 1MB Main memory 256/512/1024 MB DDR2 SDRAM, 2 DDR2 socket Main Chipset Intel 915PM (Alviso PM) / 82801FBM (ICH6-M) Hard Disk (HDD) 2.5", UltraDMA100, S.M.A.R.T 9.5mmH CD Drive...
Page 285: Wireless Lan Specifications
Wireless LAN Specifications Intel(R) PRO/Wireless 2200BG Network Connection Item Physical Specifications Power Specification Network Specifications * This piece of equipment supports the Wi-Fi wireless LAN security standard, WPA (Wi-Fi Protected Access) and CCX (Cisco Compatible eXtensions). To connect to a wireless network consisting of the WPA and CCX certificates, Windows patch (KB826942) or PROSet may be required depending on the network settings.
Page 286: Network Connection
Intel(R) PRO/Wireless LAN 2915 ABG Network Connection Item Physical Dimensions Specifications operation temperature and humidity Power Saving Mode Power Receiving Mode Specification Transmission Mode Power Compatibility Operating System Network Specifications Media Access Protocol Security * This piece of equipment supports the Wi-Fi wireless LAN security standard, WPA (Wi-Fi Protected Access) and CCX (Cisco Compatible eXtensions).
Page 287: Registered Trademarks
Copyright Samsung Co., Ltd. owns the copyright to this manual. No part of this manual may be reproduced or transmitted in any form or by any means, electronically, mechanically, or through audio, without the consent of Samsung Co., Ltd. The information in this document is subject to change without prior notice.
Page 288: Safety Instructions
Safety Instructions Instructions for Setup ● Set up the system on a stable work surface. If the system is dropped it may be damaged or it may inflict injuries on the user. ● Do not use loose power outlets or damaged power cables.
Page 289 Instructions for careful handling ● Handle with care so as not to damage the data in the hard disk. - Since the hard disk is fragile and sensitive to external conditions, it may be damaged from temperature changes or impact during operation.
Page 290 ● Use only authorized parts and do not disassemble, repair or modify the computer unless at an authorized dealer. Use authorized service centers as the system may be damaged. ● Do not touch the power strip with wet hands. There is a danger of electric shock. ●...

Samsung NP-P40 User Manual

Quick Links

Related Manuals for Samsung NP-P40

Summary of Contents for Samsung NP-P40

Table of Contents
