Page 1 Notices No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, mechanical photocopying, recording or otherwise, without the prior written permission of the manufacturer. The information within this manual is subject to change without notice. The manufacturer shall not be held liable for technical or editorial errors or omissions contained in herein;...
Page 2: Important Safety Information
Important Safety Information Safety Instructions Your system is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that the safety instructions marked on the product and in the documentation are followed.
Page 3: Care During Use
Care During Use • Do not walk on the power cord or allow anything to rest on it. • Do not spill anything on the system. The best way to avoid spills is to not eat or drink near your system. •...
Page 4: Battery Disposal
Do not put rechargeable batteries or products powered by non-removable rechargeable batteries in the garbage. Contact the Samsung Helpline for information on how to dispose of batteries that you cannot use or recharge any longer. Follow all local regulations when disposing of old batteries.
Page 5: General Requirements
Power cord sets for use in other countries must meet the requirements of the country where you use the computer. For more information on power cord set requirements, contact your authorized dealer, reseller, or service provider. General Requirements The requirements listed below are applicable to all countries: •...
Page 6: Regulatory Compliance Statements
Regulatory Compliance Statements Wireless Guidance Low power, Radio LAN type devices (radio frequency (RF) wireless communication devices), operating in the 2.4 GHz Band, may be present (embedded) in your notebook system. The following section is a general overview of considerations while operating a wireless device.
Page 7 In environments where the risk of interference to other devices or services is harmful or perceived as harmful, the option to use a wireless device may be restricted or eliminated. Airports, Hospitals, and Oxygen or flammable gas laden atmospheres are limited examples where use of wireless devices may be restricted or eliminated.
Page 8: United States Of America
United States of America USA and Canada Safety Requirements and Notices Do not touch or move antenna while the unit is transmitting or receiving. Do not hold any component containing the radio such that the antenna is very close or touching any exposed parts of the body, especially the face or eyes, while transmitting.
Page 9 recommended that the user limit exposure time if the antenna is positioned closer than 20cm (8 inches). Use On Aircraft Caution Regulations of the FCC and FAA prohibit airborne operation of radio- frequency wireless devices because their signals could interfere with critical aircraft instruments.
Page 10 If necessary, the user should consult the dealer or an experienced radio/television technician for additional suggestions. The user may find the following booklet helpful: “Something About Interference.” This is available at FCC local regional offices. Our company is not responsible for any radio or television interference caused by unauthorized modifications of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by our company.
Page 11: Fcc Part
FCC Part 68 This equipment compiles with part of the FCC rules. On the back of this equipment is a label that contains, among other information, the FCC registration number and ringer equivalence number (REN) for this equipment. If requested, this information must be provided to the telephone company.
Page 12 an identification of the business or other entity, or other individual sending the message and the telephone number of the sending machine or such business, other entity, or individual. (The telephone number provided may not be any number for which charges exceed local or long-distance transmission charges.) In order to program this information into your fax machine, refer to your communications software user manual.
Page 13 Canada Unintentional Emitter per ICES-003 This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the radio interference regulations of Industry Canada. Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limitesapplicables aux appareils numériques de Classe B prescrites dans le règlement sur le brouillage radioélectrique édicté...
Page 14 Telecommunications per DOC notice (for products fitted with an IC-compliant modem) The Industry Canada label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operation, and safety requirements. The Department does not guarantee the equipment will operate to the users’...
Page 15: European Union Ce Marking And Compliance Notices
European Union European Union CE Marking and Compliance Notices Products intended for sale within the European Union are marked with the Conformité Européene (CE) Marking, which indicates compliance with the applicable Directives and European standards and amendments identified below. This equipment also carries the Class 2 identifier.
Page 16 Wireless devices that may be in your system are only qualified for use in the European Union or associated areas if a CE mark and the Alert Symbol is on the system label. The power output of the wireless device or devices that may be embedded in you notebook is well below the RF exposure limits as set by the European Commission through the R&TTE directive.
Page 17 The product may be used outdoors, but for outdoor transmissions over a distance of 300m or more, a license from the BIPT is required. This restriction should be indicated in the manual as follows: Dans le cas d'une utilisation privée, à l'extérieur d'un bâtiment, au-dessus d'un espace public, aucun enregistrement n'est nécessaire pour une distance de moins de 300m.
Page 18 public or private emergency services. DTMF signaling also provides faster call setup. This equipment has been approved to Council Decision 98/482/EEC—“CTR 21” for Pan-European single terminal connection to the Public Switched Telephone Network (PSTN). However, due to differences between the individual PSTNs provided in different countries, the approval does not, of itself, give an unconditional assurance of successful operation on every PSTN termination point.
Page 19: Weee Symbol Information
WEEE SYMBOL INFORMATION Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life.
Page 20: Using Your Documentation
Using Your Documentation Congratulations on your purchase of a notebook computer with the Windows® XP operating system. Whether you are new to using a portable computer or are an experienced user, this user’s manual can help you get the most from your computer. Manual Documentation Conventions Information Icons Three icons and their associated messages appear in this manual.
Page 21: Software User Documentation
CD-ROM Device Naming Convention In many installation programs you will have to get a program from the CD-ROM device. The program installation sequence assumes that the CD is drive d:\, however this is not always the case. The name of the CD-ROM drive is the letter following the letter assigned to your last HDD.
Page 22: Getting Started
Getting Started Introducing Your Computer Front View Status Indicators (p15) LCD Panel Keyboard (p8) Power Button AVS Button (p54) Wireless LAN Button Etiquette Mode Button Volume Contorl Button Speaker (L) Speaker (R) Touchpad / Touchpad Button (p12) Status Indicators (p15) LCD Latch Multi Card Slot (p32) Remote Control Sensor...
Page 23: Right View
Right View CD Drive (Optional, p24) USB Port (2.0) Monitor Port Headphone Jack / S/PDIF Jack Line In Jack Microphone Jack Left View PC Card Slot (p35) Fan Vent LAN Port (p64) 1394 Port (6 Pin) Modem Port (p63) USB Port (2.0) 4 Users Manual...
Page 24: Back View
DC Jack Bottom View Battery Latches HDD Compartment Cover Removing or disassembling the hard disk drive will void your warranty. To replace the hard disk drive, please contact your nearest Samsung Service Centre. Battery TV Output Port (S-Video) Security Lock Port...
Page 25: Turning The Computer On And Off
Turning the Computer On and Off To turn on the computer 1. Insert the battery and connect the AC adapter according to the Installation Guide. 2. Slide the LCD latch to the right and open the LCD panel. 3. Press the power button. To turn off the computer 1.
Page 26 3. Click Turn Off. If the computer has not turned off properly due to a system error, press <Ctrl>+<Alt>+<Delete>. When [Windows Task Manager] dialog box appears, click Shut Down > Turn Off to turn off the computer. Your unsaved work may be lost/damaged.
Page 27: Using The Keyboard
Using the Keyboard Your computer has an 88-key keyboard. By pressing designated key combinations, you can have access to all the key functions of a full-sized keyboard. The keyboard is supplied according to the corresponding country. Refer to the keyboard figure for the corresponding country. <United Kingdom>...
Page 28 <United States> Function Windows The keys on the keyboard can be grouped into the following categories: • Full-sized Alphanumeric typewriter keys are arranged like a standard typewriter keyboard and are used for text entry. The Windows keys on either side of the spacebar open Windows menus and perform other special functions. •...
Page 29: Using The Numeric Keypad
Using the Numeric Keypad Your keyboard includes a numeric keypad, which is a group of keys that you can set to type numbers and mathematical symbols, such as the plus sign. A number or symbol on the corner of each keypad key shows its numeric function. Num Lock LED Press <Fn+Num Lock>...
Page 30: Using Special Function Keys
Places the computer into standby mode. To resume from standby mode, press the power button. (p103). Shows the remaining battery charge. Appears only when the Samsung Display Manager program is installed. Switches the display between the LCD and external display device when an external display device is connected.
Page 31: Using The Touchpad
Using the Touchpad In Windows, you always see a small graphical image on the screen that indicates the location where you can take the next action. This image is called a pointer, and is usually displayed in arrow shape ( Touchpad Touchpad Buttons The touchpad on your computer allows you to move the pointer on the LCD screen,...
Page 32 You can perform various actions with your touchpad as described below. Action Move Click Double-Click Right-Click Drag Function Process Move the pointer Place your finger on the touchpad and slide your finger to a destination. Select an object, open a menu, or Place the pointer over an object, execute a button then press left touchpad button...
Page 33 Action Scroll Please use the touchpad only with your finger. Using sharp devices may damage the touchpad. Operating the touchpad or touchpad button while starting your system may increase the time required for starting Windows. 14 Users Manual Function Process Display upper/lower/left/right part Place your finger on the right edge of the content within a window...
Page 34: Reading The Status Indicators
Reading the Status Indicators Shows the operating status of the computer. Num Lock Turns on when the numeric keypad is activated. Caps Lock Turns on when all alphabet characters you type will be in upper case. Scroll Lock Turns on when it is set to scroll the screen up and down while the cursor position does not change in some applications.
Page 35: Adjusting Lcd Brightness
Maintaining your LCD brightness settings after turning the system off and on 1. Turn the system on. When the Samsung Logo appears, press the <F2> key to enter Setup. 2. In the Boot menu, change the Brightness Mode Control option to User Control.
Page 36: Adjusting The Volume
Adjusting the Volume To adjust using keyboard Press <Fn>+< > or <Fn>+< Adjusting the Volume using the Volume Control Button Adjust the volume by using the Volume Control Button ( To adjust using volume adjustment program Click the Volume icon( level.
Page 37: Using The Remote Control (Optional)
Using the Remote Control (Optional) Using the remote control for the computer is described below. To use the remote control, install the supplied battery into the remote control first. Installing Battery Move the groove ( ) position by using a coin and open the battery cover.
Page 38: Remote Control Buttons
Remote Control Buttons Power / Standby Button Press to turn the computer on or to enter Hibernation. Playback Control Button Direction Button Press to move to an item. BACK Button Press to return to the previous step. MUTE Button Press to mute the sound. Buttons indicated by (*) do not work in some applications.
Page 39: Introducing Windows
Introducing Windows Understanding the Desktop The desktop is the working area on the computer. It consists of the large workspace and a taskbar at the bottom. Shortcut Icons Start Menu Start Button Start Button Taskbar Recycle Bin Language Bar 20 Users Manual Taskbar System Tray with Clock Opens the Start menu.
Page 40: Understanding The Start Menu
Understanding the Start Menu The Start menu includes everything that is required to start Windows. From the Start menu it is possible to run a program, open a file, assign system users with Control Panel, receive support by clicking Help and Support, and search desired items from the computer or Internet by clicking Search.
Page 41: Understanding A Window
Understanding a Window A window is the basic component in working with the computer. The My Computer window, which is a window for the computer's hard drive, will be used as an example here to show the basic composition of a window. Click Start >...
Page 42: Help And Support Center
Help and Support Center provides references and troubleshooting information regarding computer use. Click Start > Help and Support. Please refer to help and support centre before calling the Samsung helpline. Windows XP Tour You can tour elementary functions provided by Windows XP.
Page 43: Using The Computer
Using the Computer Using the CD Drive You have one of following drives installed in your computer. RW-Combo Drive DVD Super Multi Drive A CD-ROM drive is optional. For more detailed product specifications, refer to the product catalog. To insert a CD 1.
Page 44 To eject a CD 1. Stop any process that accesses the CD drive and ensure the CD access LED is turned off. 2. Press the eject button on right side of the CD drive. 3. When the tray slides out, remove the CD from the tray. 4.
Page 45 To use the Windows Media Player Window Media Player enables you to play and manage audio and video files. To launch the Windows Media Player, click Start > All Programs > Accessories > Entertainment > Windows Media Player. Running the program the first time displays the set up screen. Define the settings according to the instructions displayed on the screen.
Page 46 Above procedure applies only to the video CDs that has a .dat file as the execution file. Playing procedure may be different according to video CDs. To write data on a CD (Optional) If your computer has CD-RW functionality, you can copy data to a blank CD or create an audio CD.
Page 47 5. Click Write these files to CD in the CD drive window. 6. When the CD Writing Wizard appears, enter the CD label, and click Next. The data begins copying. 7. When copying is completed, a ‘completed’ message appears and the CD drive window opens automatically.
Page 48 Enjoying Home Theater (S/PDIF Port) Your computer supports 5.1 channel output, which is a basic function for home theater systems, and DVD drives. It provides 3D surrounding sound and vivid screen. What is a home theater system? Home theater system usually consists of a TV, DVD, 5.1 channel speaker, and digital amp and provides a high-resolution screen (MPEG2) and 3D surrounding sound (Dolby 5.1 or DTS).
Page 49 Step 1. Connect 5.1 channel speaker system to your computer 1. Connect the S/PDIF jack of the system and a 5.1 channel amplifier. 2. Connect speakers to the amplifier. (Refer to speaker’s manual.) 3. To view through a TV, connect the TV and change the current display device to TV in the Display Properties.
Page 50 Step 3. Enable S/PDIF output on the DVD program To use 5.1 channel speakers, you need to install the CyberLink Power DVD program from the CyberLink DVD Solution Installation CD (or System software Media) provided with your computer, then change the settings as per the following. The CyberLink PowerDVD program is optional and may not be provided depending on the model.
Page 51: Using The Multi Card Slot
Using the Multi Card Slot Using the Multi Card Slot, you can use memory cards such as a Memory Stick, Memory Stick Pro, SD Card, MMC, or xD Card. A memory card is used as a removable disk and is useful for exchanging data between a computer and a digital device such as a digital camera.
Page 52: To Remove A Memory Card
1. Insert a memory card into the Multi Card Slot. 2. Click Start > My Computer. The inserted memory card is displayed. Example : Memory Stick 3. You can write data to the memory card. If the memory card is not formatted yet, format the memory card before use.
Page 53: To Format A Memory Card
To format a memory card You can use a memory card after the format operation. The procedures to format a memory card are described below. Since format operation deletes all data in the memory card, please make sure that there is no important data in the memory card before formatting. To protect the data in the memory card Set the write protection tab of the Memory Stick or SD memory card to the Lock position.
Page 54: Using The Pc Card Slot
Using the PC Card Slot Various different functions can be added by inserting PCMCIA cards into the system. This system supports 16/32 bit, type I or II PCMCIA card types. The PC card slot does not support a ZV card or a PCMCIA III card. To insert a PCMCIA card Before using the PC Card slot, remove the slot protector.
Page 55: To Remove A Pcmcia Card
To remove a PCMCIA card 1. Double-click Safely Remove Hardware icon ( ) on the taskbar. 2. On the [Safely Remove Hardware] dialog box, select the appropriate PCMCIA card and click Stop. 3. When [Stop a Hardware Device] dialog box appears, click OK. 4.
Page 56: Using Easybox
Use EasyBox program to make use of Windows' complicated function easily and conveniently. Learn about EasyBox Double-click the EasyBox( (Or select Start > All Programs > Samsung > EasyBox > EasyBox.) • System: System management features are available, including disk defragmenter, disk cleanup, computer scheduling and system restore.
Page 57: Configuring Firewall
The Windows Firewall prevents unauthorized users from gaining access to your system via the network or the Internet. 1. Click Start > All Programs > Samsung > EasyBox > EasyBox. 2. Click Security from the top menu bar. 3. Select Windows Firewall Settings from the Security menu on the left.
Page 58: Using Samsung Update Plus
Update Plus, your computer has to be connected to the Internet. To Update Samsung Software and Drivers 1. Select Start > All Programs > Samsung > Samsung Update Plus > Samsung Update Plus. If this is the first time you are running the program, a window will appear asking you if you agree to the agreement in the window.
Page 59 Here you will be able to find the latest available updates. To change the automatic update settings, click the Configuration button in Figure 2 and change the settings. Samsung Update Plus does not provide updates for additionally installed software and device drivers. 40 Users Manual...
Page 60: Using Avstation Premium
TV Station is only available for systems supporting the TV function. • For detailed usage, refer to the program help. Start and Screen Layout To launch the program, select Start > All Programs > Samsung > AVStation premium > AVStation premium. Alternatively double-click the AVStation premium icon ( MUSIC You can play a music file or an audio CD.
Page 61: Music Station
What is EDS (Enhanced Digital Sound)? EDS (Enhanced Digital Sound) is a sound quality enhancement technology developed by Samsung Electronics. You can listen to clearer sound if you enable the EDS function when playing music or video on AVStation premium.
Page 62: Playing An Audio Cd
The procedures to play an audio CD are described below. 1. Launch AVStation premium and insert an audio CD into the CD drive. 2. In the Audio CD window, select Play Audio CD using Samsung AVStation and click the OK button.
Page 63: Playing A Music File
Playing a Music File If a music file is registered to the MUSIC Library, you can easily play the music file. For the procedures to register tracks to the Library, refer to (p45). 1. Move to MUSIC Station and double-click on All Music. 2.
Page 64 Adding Music Files to the Library MUSIC Library is a library holding music files used by MUSIC Station. The procedures to add music files saved on the computer to the Library are described below. You can add files, folders or search and add files. As an example, the procedures to add a folder are described below.
Page 65: Photo Station
PHOTO Station Launch AVStation premium and click PHOTO on the Station Bar. Viewing an Image The procedures to view images registered to the PHOTO Library one by one and through a SlideShow are described below. For the procedures to register image files to the Library, refer to (p49). 1.
Page 66 3. Double-click on an image. The selected image is zoomed in on. • Viewing an Image not registered to the Library Click File > Open, select an image file to view and click Open. The selected image file is registered to the Library and displayed in the Image Viewer window.
Page 67: Editing An Image
Editing an Image You can change the shape of an image, edit an image or apply special effects to an image. The image editor functions are described below. 1. Select an image to edit in the Image Viewer window, and select the Image Editor tab.
Page 68 Adding Images to the Library The PHOTO Library is a library holding image files to be used by PHOTO Station. The procedures to add image files saved on the computer to the Library are described below. You can add files, add folders or search and add files. As an example, the procedures to add folders are described below.
Page 69: Movie Station
What is EDI (Enhanced Digital Image)? EDI (Enhanced Digital Image) is a visual quality enhancement technology developed by Samsung Electronics. You can view a clearer and sharper picture by enabling the EDI function when watching TV or playing a video on AVStation premium.
Page 70 2. In the 'What do you want Windows to do?' window, select Play DVD Video using Samsung AVStation and click the OK button. 3. The DVD title is played. If a DVD title is already in the DVD drive, double-click the DVD title in the DVD / VCD folder of the Library.
Page 71 Click on Capture Current Screen ( desired image appears on the screen and click the OK button. Captured images are saved in the C:\Program Files\Samsung\AVStation Premium 3.7\Data\Captured Images folder. In addition, you can view captured images in the PHOTO Station > Captured Images folder.
Page 72 Adding Videos to the Library The MOVIE Library is a library holding video files to be used by MOVIE Station. The procedures to add video files saved on the computer to the Library are described below. You can add files, add folders or search and add files. As an example, the procedures to add folders are described below.
Page 73 Using AVStation now / AVStation premium Viewer Using these programs, you can play music, photographs, video and movies in full screen. You can enjoy multimedia using AVStation now when the computer is off and using AVStation premium Viewer when the computer is on. Before You Start! •...
Page 74: Start / Exit Avstation Now
Start / Exit AVStation now Starting Press the AVS button ( Exiting Move the mouse pointer to the top screen and click the Exit ( Alternatively press the Power button of the computer. For models with the remote control, press the Power / Standby button on the remote control to exit.
Page 75 Start / Exit AVStation premium Viewer Starting Select Start > All Programs > Samsung > AVStation premium > AVStation premium Viewer from Windows. Alternatively press the AVS button ( Exiting Move the mouse pointer to the top of the screen and click the Exit ( 56 Users Manual ) of the computer from Windows.
Page 76: Screen Layout
Screen Layout MUSIC You can play a music file or audio CD. PHOTO You can view a photograph or image file one by one or in a SlideShow. MOVIE You can play a video, DVD or VCD title. Settings You can set the Music, Photo and Movie settings. To move to the start screen while using the program, press the AVS button or <ESC>...
Page 77: Using The Remote Control
Using the Remote Control The basic uses of the remote control are described below. For more detailed information on the button functions, refer to ”Using the Remote Control (Optional)” on page 18. A remote control is optional and is only provided for some models. •...
Page 78 2. Click on All Music and double-click a file in the right pane. The music file is played. Playing an Audio CD 1. Launch AVStation now and insert an audio CD into the CD drive. 2. In the AVStation now start screen, click on Music. 3.
Page 79 PHOTO Station The procedures to view images registered to the PHOTO Library one by one and through a SlideShow are described below. (For the procedures to register image files to the Library, refer to p49.) 1. Launch AVStation now and click on Photo. 2.
Page 80: Playing A Movie File
To view an image in Full Sreen or through a SlideShow. Click on the SlideShow or Full Screen button below the zoomed in image. To return to the previous status in SlideShow or Full Screen, press the <Esc> key or double-click on the screen. In AVStation now, press the <Esc>...
Page 81 Playing a DVD 1. Launch AVStation now and insert a DVD title into the DVD drive. 2. In the AVStation now start screen, click on Movie. 3. Click on DVD/VCD and double-click on the DVD title. The DVD title is played. 62 Users Manual...
Page 82: Connecting To The Internet
Connecting to the Internet Connecting with a Modem Before You Start: • Use a standard non-digital phone line to connect. • Contact an internet service provider (ISP) for instructions on how to connect to and disconnect from the Internet. 1. Connect a telephone line to the computer’s modem port. 2.
Page 83 Connecting Through a Wired LAN 1. Connect a LAN cable to the computer’s LAN port. 2. Click Start > Control Panel. 3. Click Network and Internet Connections in the [Control Panel] window. 4. Click Network Connections in the [Network and Internet Connections] window. 5.
Page 84 6. On the General tab, select “Internet Protocol(TCP/IP)” and click Properties. 7. To use DHCP: On the General tab, select “Obtain an IP address automatically” and “Obtain DNS server address automatically”. Click OK. To use a static IP: On the General tab, select “Use the following IP address” and fill in the IP address, Subnet mask, Default gateway, Preferred DNS server, and Alternative DNS server fields.
Page 85 Connecting Through a Wireless LAN (Optional) A wireless network (Wireless LAN) environment is a network environment that enables communication between multiple computers at home or a small-size office through wireless LAN devices. Using the wireless network connections between the systems, you can use normal network functions such as sharing of files, folders and printers.
Page 86: Connecting To An Access Point (Ap)
2) Computer-to-computer (ad hoc) This is also called a peer-to-peer network. In computer-to-computer wireless networks, you can wirelessly connect 2 or more computers that have wireless LAN modules. For details, see “Connecting to computer- to-computer networks (peer-to-peer or ad hoc)” on page 68. Connecting to an Access Point (AP) This section describes how to connect to an AP.
Page 87 When a network key is not defined for a selected AP, click on Link to display the warning message box. Then click Connect again in the box. Now when Connected in AP is displayed, and you can access the network. Checking the connection status Move the mouse pointer over the Wireless Network Connection ( the taskbar, and the connection status is displayed.
Page 88 Select 'Computer-to-computer (ad hoc) networks only', and click Close. 5. In the Wireless Networks tab, click Add. 6. Enter the network name (e.g. samsung), and unselect 'The key is provided for me automatically'. Enter the encryption key in the Network key field, and click OK.
Page 89 7. Check that the configured network name (e.g. samsung) is in the ’Preferred networks’ item, and click OK. Now your wireless network setup has been completed. Step 2. Connecting to the configured computer 1. Right-click on the Wireless Network Connection ( select View Available Wireless Networks.
Page 90: Wireless Network Setup Using The Wireless Lan Setup Program
3. Enter a cryptographic key in the network key box and click Connect. If the network key is not configured in ”Connecting to computer-to-computer networks (peer-to-peer or ad hoc)” on page 68, just click Connect, without any keystrokes. When connected to the wireless network, the system displays Connected in the selected network of the Network Connection window.
Page 91 3. In Available Networks, click on Refresh. 4. Select the name of an access point to connect to from the available network list and click on Connect. If a network does not appear, click on Refresh. 5. Enter a WEP key and click the OK button. The Wireless Security Settings window may differ depending on the security settings of the AP.
Page 92: Using Samsung Network Manager
Using Samsung Network Manager Samsung Network Manager is a program that has been developed to enable users to use the network easily. Samsung Network Manager provides the following features. • You can easily set up the network and printer settings.
Page 93 2. Run Samsung Network Manager. Select Start > All Programs > Samsung > Samsung Network Manager > Samsung Network Manager or double click the Samsung Network Manager( 3. Click the Add button. 4. Select a network location icon and enter the name of the location (e.g. Home).
Page 94 Setting up the IP Address To allocate an IP address automatically (DHCP), select Get IP Automatically. To use a static IP address, unselect Get IP Automatically and enter an IP address. For IP address information, ask your network administrator. 7. When the Printer Setting window appears, click Finish. To add a printer, click Add Printer.
Page 95: Using The Network After Moving Location
Taskbar and click View Available Wireless Networks. 2. Click Search AP from the Wireless menu to search for wireless LAN APs. Select an available wireless network (e.g. SAMSUNG) and click the Connect button. For information on available wireless LAN APs, ask your network administrator.
Page 96: Sharing Internet Access
2. Select an icon that represents the corresponding location from the Saved Locations window and then click Move. 3. When the network settings of the selected location are applied, the new location and the network connection information are displayed in The detailed Information for window.
Page 97 Setting Up a Sharing Server 1. Run Samsung Network Manager on the computer to be used as the sharing server. 2. Click the Add button. 3. Select a network location icon and enter the name of the location (e.g. Home).
Page 98 When the Shared Server setting is completed, set up the shared client. Setting Up the Sharing Client 1. Run Samsung Network Manager on the computer to be used as a sharing client. 2. Click the Add button. 3. Select a network location icon and enter the name of the location. Click the Next button.
Page 99: Network Status Diagnosis
Network Status Diagnosis You can diagnose the network status when the network is not properly connected. 1. Run Samsung Network Manager. 2. Select Auto Diagnosis from the Manage menu. 3. The Network Connections figure window appears. Click the Start button to start the network diagnosis.
Page 100: Using Network Services
Using Network Services While the computer is connected to the network, you can use network services to share files, folders, and printers. Network services are provided for the computers that are connected to the network through wired or wireless network connections. For details, see “Connecting Through a Wired LAN”...
Page 101 Step 1. Configuring Sharing 1. Right-click the target file or folder to share in My Computer, and select Sharing and Security. 2. Click 'IF you understand the security risks but want to share files without running the wizard, click here'. It has the same security effect as that of the 'Network Setup Wizard'.
Page 102 Step 2. Using Shared Files or Folders This section describes how to access shared files or folders if your computer is a member of the same workgroup. 1. Double-Click My Network Places of desktop under Other Places. 2. Click 'View workgroup computers', and click the desired computer to access the shared file.
Page 103: Sharing Printers
Sharing Printers This section describes how to share a printer between computers connected to a network. To share a printer, complete the following procedures: • Step 1. Configure printer sharing in the computer connected to the printer. • Step 2. Add and use the shared printer in other computers on the network. Step 1.
Page 104 Step 2. Adding and Using a Shared Printer. 1. From a different computer that wants to use the shared printer, click Start > Printers and Faxes. 2. Click Add a printer. 3. In the Add Printer Wizard, click Next. 4. Select 'A network printer, or a printer attached to another computer', and click Next.
Page 105: Bluetooth Functions
Using Bluetooth Devices (Optional) Bluetooth is a wireless communication technology that allows access to devices nearby such as a computer, mobile phone, printer, keyboard or mouse without a cable connection. Bluetooth enables file transmissions, Internet access, a private area network function, and access to a keyboard, mouse and printer between devices supporting the Bluetooth function without a cable connection.
Page 106: Bluetooth Software Setup
For more information about using the Bluetooth function, refer to the online help of the Bluetooth Device. Bluetooth Software Setup Bluetooth software is installed on computers supporting Bluetooth. For first time use, set up the Bluetooth software as follows. 1. Right-click the Bluetooth icon( mouse(or touchpad) and select Start Using Bluetooth from the pop-up menu.
Page 107 If you change the service settings, the driver necessary for the additionally selected services are installed. At this point, a warning message may appear informing you that there is no Microsoft logo. Since it does not affect the operation, continue the installation. 3.
Page 108: Using Bluetooth
Using Bluetooth Describes how to exchange files between computers supporting Bluetooth and how to use other Bluetooth devices. Bluetooth Help Bluetooth Help provides detailed procedures on using Bluetooth functions. Double-click on My Bluetooth Settings on the Desktop and press the <F1> key (Help).
Page 109 Exchanging Files between Bluetooth computers The procedures to exchange files and folders between Bluetooth computers are described below. 1. On the computer that is sending a file (hereafter Computer A), right-click the Bluetooth icon ( Transmission > Search for Device. 2.
Page 110 The Bluetooth PIN Code is a password used for the connection between two Bluetooth devices, the user just enter the same PIN Code (E.g. same numbers) on both Bluetooth devices to make a connection. 4. After a short while, the Bluetooth PIN Code required dialog box appears on Computer B, enter the code that you have entered in Step 3 above.
Page 111 Connecting Keyboard, Mouse, Joystick and Headset devices The procedures to use Bluetooth HID devices (keyboard, mouse, joystick, etc.) or a headset, etc. on the computer are described below. The Bluetooth PIN Code is a password used for the connection between two Bluetooth devices, the user just enter the same PIN Code on both Bluetooth devices to make a connection.
Page 112: Use Instructions
• The Bluetooth function of a Bluetooth PDA, mobile phone, mouse or keyboard may be turned off. To use them in connection with a Samsung computer supporting Bluetooth, you must check if the Bluetooth function of the device to connect to is turned on.
Page 113: Customizing Your Computer
Customizing Your Computer Using System Setup The System Setup (BIOS) program enables you to configure your computer hardware and set security and power-savings options. The settings you choose are stored in battery-maintained CMOS memory that saves the information even when the computer’s power is turned off.
Page 114: Starting System Setup
Starting System Setup To start System Setup, turn on your computer and then press <F2> and hold until the System Setup screen appears. Table 2. System Setup Menus Menu Function Main Changes the basic system. Advanced Configures advanced features on your computer. Security Enables security features, including passwords.
Page 115: Changing Booting Priority
Changing Booting Priority You can select the booting priority among the devices such as the hard drive, CD-ROM drive, etc. The following example describes how to configure the hard drive as the first booting device when the CD-ROM drive is configured as the first booting device by default.
Page 116: Configuring The Password
Do not lose or forget your password. If you have forgotten your password, contact the Samsung service center. 1. Select the Security menu in the System Setup. To enter System Setup, see “Starting System Setup” on page 95.
Page 117 Activating the Booting Password Before activating the booting password, the supervisor password must have been configured. Set the Password on boot option to [Enabled]. From now on, system booting will not proceed without the password. Deactivating the Password 1. On the password to delete, press <Enter>. (e.g. supervisor password) 2.
Page 118: Configuring Resolution And Color Depth
Configuring Resolution and Color Depth Screen resolution is the number of pixels displayed on the screen. High resolution makes the overall screen area large, although individual items appear small. Color quality is determined by the number of bits used to represent a pixel on the screen. High color quality displays more number of colours on your screen.
Page 119: Using External Display Devices
To connect a TV, connect the TV to the TV output port of the system. 2. If you press the <Fn>+<F4> key combination once, the Samsung Display Manager screen appears where you can select a screen.
Page 120: Using Dual View To View Extended Screen
Using Dual View to View Extended Screen Dual View is a function that enables you to view a computer screen over two display devices. This is convenient when needing a wide screen for work. In Dual View mode, you can select the screen resolution and colour quality for each display device, as if there were two separate graphics cards.
Page 121 secondary display device is indicated as '2'. Now you can view the screen through two monitors. When you use Dual View, configuring the LCD as the 'Primary' monitor is recommended. If the screen of the secondary display device is displayed at 640x480 pixels, with 256 colours, change the settings to the desired screen resolution and colour quality in the [Display Properties] dialog box.
Page 122: System Management
System Management Using Power Management Options Your computer includes Power Management options that can help the battery charge last longer and extend the life of the battery. Power-management options will slow down or shut off system components when the components are not being used. Power management may slow down system performance.
Page 123 3. Click the Power Schemes tab to display the basic power management options. By default, the power scheme is configured to BatteryMgr-normal mode. BatteryMgr-normal mode extends the battery life and optimizes the Intel Speedstep function. Since the CPU power consumption is automatically optimized to conserve power when the computer is operating on battery power, an application may be executed slower than when it is operating on AC power.To use BatteryMgr-normal mode after reinstalling Windows, install the...
Page 124 You can also reserve Turning Computer Off, Hibernation state, Hold Mode, etc. by selecting System > Computer Scheduling in the EasyBox program. (see “Using EasyBox” on page 37.) If you change the power settings in the Battery Manager program, the settings of the 'Power Options Properties' window are automatically changed accordingly ("Using the Battery Manager"...
Page 125 Standby Mode (Power Management or Manual Method) Standby is used mainly for conserving battery power in your notebook computer. It also gives you the benefit of getting right back to your work without waiting for the computer to restart. Standby turns off your monitor and hard disks, placing your entire system in a low-power state.
Page 126 Advanced Power Management Schemes This section discusses the advanced power management schemes. There are two buttons that you can use to manually conserve power. To enter the power management window complete the following: 1. Click Start > Control Panel > Performance and Maintenance. 2.
Page 127: Using The Battery
Using the Battery Please refer to the following instructions when running the computer on battery power without connecting the AC power. Precautions • Use only chargers specified in the User Manual. • Never heat the battery pack, put it near or in a fire or use at a temperature higher than 60°C, as this may cause fire.
Page 128: Monitoring The Battery Charge
To use the shortcut key to view If you press the <Fn>+<F2/ battery charge appears on the screen for a while. It appears only when the Samsung Display Manager program is installed on your computer. To view on the battery Press the PUSH button on the battery.
Page 129 To view through the Control Panel Select Start > Control Panel > Performance and Maintenance > Power Option > Power Measure tab.Then you can view the current power source and the current remaining battery charge. Using the battery Battery is an expendable supply, so when you use it for a long time, the capacity/battery life is shortened.
Page 130 You can easily change the power mode by selecting an optimized power mode and manually optimizing the battery use time by setting each option. Click on Start > All Programs > Samsung > Samsung Battery Manager > Samsung Battery Manager.
Page 131: Battery Calibration
• Maximum Performance Mode : This mode is appropriate for conditions that require maximum system performance.Therefore, the battery usage time may be reduced in this mode. • Custom Mode : In this mode, a user can configure a detailed configuration to save the battery usage time.
Page 132: Upgrading Memory
Upgrading Memory This computer has one or more memory module(s). Two memory module sockets are provided so that you can replace memory or install an additional memory module. Removing the memory module Before removing or replacing the memory module, turn the system off completely and remove the battery and AC adapter.
Page 133: Adding A Memory Module
Adding a memory module 1. Align the new memory module connectors accordingly and slide it into the slot at ° a 30 angle. Ensure the notch on the memory module corresponds with the notch on the socket. 2. Push the memory module in until the module clicks into place. If the memory module is not fixed completely, gently push the memory down while pressing the memory module tabs outward.
Page 134: Using The Security Lock Port
Using the Security Lock Port The security lock is a device used to physically 'fix' the system when using it in a public place. The locking device needs to be purchased separately. The shape and methods of use may differ depending on the manufacturer. Please refer to the manual provided with the security lock for proper use.
Page 135: Tips For Using Your Computer
Tips for Using Your Computer The following information helps you avoid potential problems as you use your computer: Do not try to disassemble your computer. Opening the system chassis voids your warranty. Only an authorised manufacturer service center can replace or add any parts inside the chassis.
Page 136: Travelling With Your Computer
• A walkie-talkie must be kept more than 1 meter away from the device. Since a walkie-talkie transmits a very strong signal, it may cause a computer malfunction. Travelling with Your Computer Air Travel If you are travelling by air, follow these tips: •...
Page 137: Storing The Computer For Long Periods
Sweet liquids leave a sticky residue that may jam the keyboard despite your efforts to dry it. • If you spill liquid on the LCD panel, clean it immediately with a soft cloth and denatured alcohol or a proprietary LCD screen cleaner. Do not use water, window cleaner, acetone, aromatic solvent, or dry, rough towels to clean it.
Page 138: Troubleshooting
Since this program enables you to diagnose your system with one-click, try to diagnosis your system with Magic Doctor. Click Start > All Programs > Samsung > Magic Doctor > Magic Doctor. (p142) Windows Help and Support Run Windows Help and Support to find problem that may be affecting your computer.
Page 139 System Recovery Precaution: Before you start restoring your windows operating system insure you backup all data on your hard drive. Samsung is NOT responsible for any data loss. 120 Users Manual...
Page 140: Questions And Answers
Questions and Answers This section provides information on possible problems, solutions and other references for system use. Windows Related Q1 The system does not shutdown properly. When the system does not shutdown normally, press and hold the Power button until the system manually shuts off. If the Power-Saving Mode is configured into the Power button, press and hold for more than 4 seconds to shut the system off.
Page 141: Display Related
Display Related Q1 The LCD screen is too dark or too bright Turn on the LCD backlight or adjust the screen brightness. Press <Fn>+<F5> to turn on the LCD backlight or press <Fn>+< screen brightness. Q2 The screen saver disturbs screen viewing during Media Player or video file operation.
Page 142 Q6 The desktop momentarily appears as a broken image when zooming in or out of the Media Player screen when Media Player is running. Since zooming in or out of the Media Player screen changes the screen resolution, the desktop may momentarily appear as a 'broken image' during this operation. Q7 The playback screen of a DVD title or an MPEG file is only displayed on the LCD.
Page 143 For it to operate properly, it is recommended to connect a TV and then booting up the computer. Q12 Pressing the shortcut key on the keyboard does not show the Samsung Display Manager icon.
Page 144: Sound Related
Sound Related Q1 How to install and uninstall the sound driver To install or uninstall the sound driver from this system, please follow the procedures below. • Sound Driver Components The sound driver consists of the following 3 components and the 3 components are automatically installed during the installation.
Page 145 • Installing the Sound Driver after a Windows XP Reinstallation If you install the sound driver after reinstalling Windows XP, the Add Hardware Wizard (Modem Device) window may appear during the sound driver installation. This happens because the High Definition Audio - KB888111 Hotfix, which has been installed on your system, has changed the settings to search for both sound and modem devices.
Page 146: Modem Related
Modem Related Q1 I cannot hear the modem sound. Check that the telephone line is properly connected to the modem. Check that the modem driver is installed properly. Click Start > Control Panel > Performance and Maintenance > System. Select Hardware tab > Device Manager > Modems in the System Properties window, and check if there is a yellow exclamation mark on the installed modem icon.
Page 147 In the Modem tab of the Modem Properties window, clear the 'Wait for dial tone before dialing' check box. When the configuration is completed, click OK. Q3 How do I use my modem when dialing from overseas? Check that the modem is correctly configured according to the current country. Because the values for communication may differ according to the country, you may not be able to connect via the modem due to an incorrect modem configuration.
Page 148: Wired Lan Related
Wired LAN Related Q1 <Wake On LAN> function <Wake On LAN> is a function that activates the system in rest mode when a signal (such as ping or magic packet commands) arrives from network (wired LAN). To use <Wake On LAN> function: Select My Network Places >...
Page 149: Wireless Lan Related
Wireless LAN Related Q1 The Wireless LAN device is operating properly, but I cannot connect to the Internet or to another computer. This is due to an incorrect configuration, or a configuration error. Check the following check lists: If you are using a computer-to-computer (Ad Hoc) network connection, check that the name of the configured network (SSID) is correct.
Page 150 Q3 I cannot share an Internet connection. It may require some time to synchronize the computers to share an Internet connection after the Internet connection sharing configuration is completed. If you cannot share Internet connection even after a longer period, restart the computer.
Page 151 Verify whether the AP is operating properly. - When the AP is not operating normally, turn off the AP and after a short while turn it on again. - Verify whether the AP's firmware is the most recent version. (Contact the AP manufacturer or the place where you purchased the AP for details of the AP firmware.) Verify whether the AP has been properly connected to the network.
Page 152 Q5 In the Windows XP 'Available wireless networks' window, the Wireless Network Connection is displayed as 'Not Available'. Check if the wireless LAN is turned on. Check if there is additional program for a wireless LAN connection installed. Windows XP supports wireless LAN connections through the Wireless Zero Configuration (WZC) service.
Page 153 Check the TCP/IP properties of the computers to be connected through the computer-to-computer (Ad Hoc) network. All of the computers to be connected through a computer-to-computer (Ad Hoc) network should be configured so that their IP addresses are within the same subnet range. - If the TCP/IP Settings are configured to DHCP, the address is automatically configured to an address within the subnet IP range.
Page 154 Q10 The wireless LAN does not work properly when there is a device operating on an adjacent frequency in the vicinity of the product. Channel interference may occur when a wireless video transceiver or a microwave oven is being used.If you experience channel interference from other equipment, it is recommended changing the channel to connect to the AP.
Page 155 For more detailed network authentication procedures, ask your AP (Access Point) administrator. Q12 After PROSet is installed, The “AEGIS Protocol (IEEE 802.1x) v2.2.1.0” appears in the [Local Area Connection Properties] window. The AEGIS Protocol is a security authentication protocol that is automatically installed when PROSet is installed and does not affect the operation of other programs.
Page 156: Games And Programs Related
Games and Programs Related Q1 3D game is not executed, or some functions are not working. In the '2D' or 'Software Renderer' of the graphics option provided by the game, change the related settings and run it again. Q2 While playing a game, pressing the <Fn>+<F4 / the screen is not properly displayed.
Page 157 Q6 The game play screen frequently stops and starts. This may occur when the PowerMizer Setting is set to 'Maximum Power Saving Function' or 'Balanced'. Right-click on the Desktop and select Properties from the pop-up menu. In the [Display Properties] window, select the Settings tab > Advanced > GeForce Go xxxx tab.
Page 158: Security Center
Security Center Q1 To change the popup window display settings when connected to the Internet. In the Windows XP SP2 environment, you can decide whether to display a popup window when connected to the Internet, for user convenience and security. To display most of the popup windows when connected to the Internet: Click on Internet Options in Start >...
Page 159 Q3 When you see a Windows Security Alert icon ( of the task bar. With the Security Center feature added, Windows XP SP2 checks the Firewall, the automatic updates configuration and installation of virus-checking programs to display a Windows Security Alert icon on the right part of the task bar when it judges that the computer is vulnerable to attacks from the Internet.
Page 160 If Windows does not recognize the existence of an anti-virus program even when it has been installed, your computer could be vulnerable to attacks from the Internet. You should install an anti-virus program that your computer is able to identify. Check the following programs which Windows can detect and select one from the list.
Page 161: Using Magic Doctor
Magic Doctor is troubleshooting software provided by Samsung Computer. A user can diagnose system problems via one-click or by selecting diagnostic items. 1. Click Start > All Programs > Samsung > Magic Doctor > Magic Doctor. 2. Click on an icon at the top of the screen.
Page 162: Restoring The System
Restoring the System This description is only for models running Window XP. The System Restore function allows you to restore your computer to an earlier copy (called restore point), and restores the settings if a problem occurs.The System Restore function is provided by Windows XP to enable the resolution of various problems without reinstalling Windows XP completely.
Page 163 2. Select "Create a restore point", and click Next. Since changes made after the Recovery Point may not be maintained, please back-up all necessary files to another location before performing system recovery. 3. In the Restore point description box, type a name to identify the restore point, and than click Create.
Page 164: Returning Your Computer To An Earlier Restore Point
Returning your computer to an earlier restore point The procedures to return your computer to an earlier restore point when a problem has occurred are described below. 1. Click Start > All Programs > Accessories > System Tools > System Restore. 2.
Page 165: Undoing The Last Restoration
4. Confirm the selected restore point and click Next. System Restore shuts down Windows, and starts the restoration processes. 5. After the restoration is complete, Windows restarts. In the [System Restore completed] dialog, click OK.Your computer has been restored to the selected restore point.
Page 166: Reinstalling Software
Reinstalling Software If you have reinstalled the Windows operating system, or the system and program do not operate properly, you can re-install the driver and program using the system software Media. This computer is optimized for Microsoft Windows XP, therefore drivers for other operating systems are not included on the System Software Media.
Page 167: Installing Drivers And Programs
Installing drivers and programs 1. Click Standard Installation in the main window of the System Software Media. (Standard Installation is recommended) 2. The system is scanned to display the drivers and programs that need to be installed. 3. Click OK. The drivers and programs are automatically installed as factory defaults.
Page 168: Reinstalling Windows Xp
Reinstalling Window may delete the data on the hard disk drive such as files, programs, etc. In order to minimize damage from data loss, please remember to always back up data. Samsung Electronics is not liable in the case of data loss, please consult your warranty statement for clarification.
Page 169 • Standard installation: You can change the settings for partitioning, the installation folder, etc. during the Windows installation. However, reinstalling Windows may delete the data on the hard disk drive such as files, programs, etc. In order to minimize damage from data loss, please remember to always back up data.
Page 170 6. After the installation process copies the necessary folders for the Windows installation, restart the system, and the message “Press any key to boot from CD” is displayed. You do not need to enter anything. In a moment, the Windows XP installation screen will appear to proceed with the installation.
Page 171 If You Cannot Run Windows If you cannot run Windows, you have to boot the system with the system recovery CD, and reinstall Windows. If you boot the system from the system recovery CD, you can install Windows only with the user installation option. You cannot install with the standard installation option.
Page 172: System Specification
The system specifications are subject to change without notice. For detailed system specifications, refer to the product catalog. The capacity of the hard disk drive with Samsung Recovery Solution will be displayed as less than the specified capacity. (operation) : 20% ~ 80%...
Page 173: Product Specification
PROSet may be required depending on the network settings. For driver update, visit www.samsung.com and for information on the PROSet installation, refer to "Wireless Network Setup Using the Wireless LAN Setup Program" (p71). For more information, ask your network administrator.
Page 174 Abbreviations A ..Amperes AC ..Alternating current ACPI ..Advanced Configuration and Power management Interface APM ..Advanced Power Management ATA.
Page 175 ISA ..Industry Standard Architecture KB ..Kilobytes kg ..Kilograms LAN..Local-area network lb..
Page 176 Glossary AC adapter The AC (or alternating current) adapter regulates current coming into your computer from the wall outlet. The current at the wall outlet is alternating current and needs to be changed by the adapter to DC (direct current) before your computer can use it for power.
Page 177 CardBus CardBus technology enables the computer to use 32-bit PC Cards. Hardware in the computer and the Windows operating system provide support for the 32-bit cards. The voltage of 32-bit cards (3.3 volts) is lower than that of 16-bit cards (5 volts).
Page 178 Hard drive Also called fixed disk. A hard drive is connected to the computer and can be installed or removed. Data written to a hard drive remains until it is overwritten or corrupted. The 2.5-inch hard drive in your computer was designed for use in a notebook computer.
Page 179 PC Card PC Card stands for personal computer card. The Personal Computer Memory Card International Association (PCMCIA) defines the standards used to develop all PC Cards. PC Card types include: modems, Ethernet adapters, SCSI adapters, ATA cards, and memory cards. PC slot The PC slot is the hardware slot in the computer where the PC Card is placed.
Page 180 Shadow RAM A write-protected area of RAM that contains a copy of the BIOS. As the computer boots, the BIOS is copied from its permanent location in ROM to RAM. The BIOS can be executed much faster in RAM than in ROM. The BIOS remains in shadow RAM until you turn off the computer.
Page 181: Contact Samsung World Wide
- Customer Care Center ☎ : 902 10 11 30 [PORTUGAL]Contacte SAMSUNG GLOBAL Se tem algumas dъvidas ou comentбrios sobre os produtos Samsung, contacte por favor a nossa linha de apoio a clientes Samsung. - Customer Care Center ☎ : 808 200 128 Web Site: www.samsung.com/uk...
Page 182 - Customer Care Center ☎ : (RUSSIA) 8-800-200-0400 - Customer Care Center ☎ : (UKRAINE) 8-800-502-0000 - Customer Care Center ☎ : 800-810-5858 / (010) 64751880 Web Site: www.samsung.com.cn - Customer Care Center ☎ : 1800-29-3232 / 02-689-3232 Web Site: www.samsung.ru Web Site: www.samsung.com/ur...
