Summary of Contents for MAKSPOWER HC12.8V100Ah
- Page 1 NO. : HC20-PKLI20011 Manual for REV ： R1.1 RV 100 Ah battery Product Manual RV Battery LiFePO4 Battery Pack special size for RV 12.8V100Ah Product Manual Size:355mm *175mm*192mm Distributor: Bruenech AS www.makspower.no e-mail: sales@makspower.no...
-
Page 2: Table Of Contents
5 Bluetooth function interface..........5 6 Heating function description ........... 5 7 Extra Tips ............... 5 8 Tests ................6 9 Cautions ................. 7 10 Other Technical Indicators ........... 11 11 Products Liability ............12 1 Product Specification Distributor: Bruenech AS www.makspower.no e-mail: sales@makspower.no... - Page 3 NO. : HC20-PKLI20011 Manual for REV ： R1.1 RV 100 Ah battery Product Manual RV Battery Items Specification HC12.8V100Ah（26650-4000mAh-3.2V-4S25P） Product Model Normal Voltage 12.8V Rated Capacity 100±1Ah(C Energy 1.28KWh Weight About 11kg±1kg 355mm *175mm*192mm Size ≤20mΩ Internal Resistance(AC) Charge Voltage Max 14,4 volt.
-
Page 4: Characteristics Curve
NO. : HC20-PKLI20011 Manual for REV ： R1.1 RV 100 Ah battery Product Manual RV Battery 2 Characteristics Curve Distributor: Bruenech AS www.makspower.no e-mail: sales@makspower.no... -
Page 5: User's Manual
Over-charge warning for each cell 3.50±0.05V Over-charge protection for each cell 3.85±0.05V Over charge Over-charge release for each cell 3.60±0.05V Over-charge release method Under the release voltage Over Over-discharge warning for each cell 2.50±0.05V Distributor: Bruenech AS www.makspower.no e-mail: sales@makspower.no... -
Page 6: Bluetooth Function Interface
Working mode: In the charging state, when the solar panel has output current to charge the battery or external charging equipment, and the charging current is less than 5 A, the heating film will not be started under any circumstances, and the battery can be charged; Distributor: Bruenech AS www.makspower.no e-mail: sales@makspower.no... -
Page 7: Tests
20%).Charge voltage is 14.6±0.05V, Standard cutoff voltage is about V; Standard current is I (A). 8.2 Standard Charge Charge the battery with Lithium ion battery special test cabinet, supply standard voltage, standard current until current down to 0.05I (A). Distributor: Bruenech AS www.makspower.no e-mail: sales@makspower.no... -
Page 8: Cautions
Do not transport or store the battery together with metal objects such as hairpins, ➢ necklaces, etc. ➢ Do not strike, trample, throw, fall and shock the battery. ➢ Do not directly solder the battery and pierce the battery with a nail or other sharp Distributor: Bruenech AS www.makspower.no e-mail: sales@makspower.no... - Page 9 After receiving the battery, you should first check the packing carefully. During the handling process, please ensure there’s no shock on the battery. ➢ Please check the battery case and accessories if there’s any damage or leakage, if so, please contact us immediately. Distributor: Bruenech AS www.makspower.no e-mail: sales@makspower.no...
- Page 10 ➢ When the battery power is low, please charge it in time. This could ensure longer cycle life. If the battery can’t be charged in time and let it under power shortage Distributor: Bruenech AS www.makspower.no e-mail: sales@makspower.no...
- Page 11 B+/B- and P+/ P- voltage, then the board would be failed if the voltage difference is very high. Then please do testing in detail on protection circuit, if not pass, please change another new protection circuit. ➢ Battery suffered fierce collision, with character-external battery case damaged or Distributor: Bruenech AS www.makspower.no e-mail: sales@makspower.no...
-
Page 12: Other Technical Indicators
Solution: The protection circuit is damaged; you need to replace the protection circuit. 10 Other Technical Indicators If you need battery protection parameters and other related parameters, please contact our sales or technical staff, we will provide you as soon as possible. Distributor: Bruenech AS www.makspower.no e-mail: sales@makspower.no... -
Page 13: Products Liability
If the phenomenon such as incorrect using method or wrong circuit connection, or input power data, working index are inconsistent with the Manual, cause damage to product, load and its accessories, we are not responsible for it. Distributor: Bruenech AS www.makspower.no e-mail: sales@makspower.no...
