ARCO
USER MANUAL
3,8 / 3,5 kg
2-3
COLOUR:
persons
w/ wo apron
poliester
RIP - STOP
min.
max.
UV
4,3 / 4,0 kg
2
ALU
entrances
RESISTANT
FRAME
3000 mm H
O
w/ wo apron
2
TECHNICAL SPECIFICATIONS:
Flysheet:
Sleeping area:
Floor:
Frame:
Pins:
Seams:
Tent capacity:
Weight:
Min. weight = the tent with frame poles
Max. weight
the tent with accessories, e.g. pins,
repair kit, guy lines, bag, manual, guarantee.
Dimensions:
3
YEAR
ALU
PINS
GUARANTEE
polyester rip-stop PU „UV Resistant" (3000 mm H
0)
2
polyamide
PE fabric (10 000 mm H
0)
2
aluminium 7001 T6 ø 9,5 mm
aluminium 7001 T6
all taped
2 - 3
without aprons: weight min./max. 3.50 kg. / 4.00 kg.
with aprons: weight min./max. - 3.80 kg. / 4.30 kg..
305 x 235 x 107 cm (external)
150 x 215 cm (sleeping area)
TENT DIMENSIONS:
Advertisement
Table of Contents
Summary of Contents for Marabut Arco
- Page 1 Tent capacity: 2 - 3 Weight: without aprons: weight min./max. 3.50 kg. / 4.00 kg. ARCO with aprons: weight min./max. - 3.80 kg. / 4.30 kg.. Min. weight = the tent with frame poles Max. weight the tent with accessories, e.g. pins, repair kit, guy lines, bag, manual, guarantee.
- Page 2 Bend the upper pole to mount its other end in the opposite corner. Similarly mount the other frame pole. a MARABUT tent, you can be sure that even after the guarantee Marabut Sp z o.o. Stiffen the intersection of the frame poles using the connector (Fig.
