INSTALLATION INSTRUCTIONS
Thank you for purchasing SRT-2
Electric Tarp Conversion. Agri-Cover, Inc. proudly
TM
manufactured this tarp using superior quality materials and workmanship. With proper
care, your tarp will provide years of service.
NOTICE TO INSTALLER: Even if familiar with product, read instructions prior to
installation as improvements may be made without notice. Always handle components
with care. If you have questions or problems, have serial number ready and call
customer service. When done, these instructions must be given to the consumer.
NOTICE TO CONSUMER: Before using this product read operating, maintenance and
safety sections. Save these instructions for future reference.
FOR YOUR RECORDS
DATE PURCHASED:
WHERE PURCHASED:
TARP SERIAL NUMBER:
(Located on motor and gearbox)
Questions? (800) 233-4655
agricover.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AGRI-COVER ACI SRT-2
Summary of Contents for AGRI-COVER ACI SRT-2
- Page 1 INSTALLATION INSTRUCTIONS Thank you for purchasing SRT-2 Electric Tarp Conversion. Agri-Cover, Inc. proudly manufactured this tarp using superior quality materials and workmanship. With proper care, your tarp will provide years of service. NOTICE TO INSTALLER: Even if familiar with product, read instructions prior to installation as improvements may be made without notice.
- Page 2 PREPARATION • Prior to tarp system assembly, park truck or trailer on level ground. • Box must be square and straight, center must not be pulled together or spread apart. • Remove or grind smooth any sharp edges or points contacting tarp and/or cables. •...
- Page 3 SAFETY INFORMATION DANGER: Mounting replacement tarp to a structurally weak or damaged roll tube can result in serious injury or death. Before installing replacement tarp, inspect mounting surface of roll tube. Be aware several mounting holes in close proximity may compromise roll tube strength and integrity.
- Page 4 1: ATTACHING MOTOR A. Place and weld motor mount slide frame to center of belly dump’s cross frame. B. Mount motor to motor mount carriage with (3) 5/16” x 3/4” hex bolts and washers. C. Slide motor on motor mount slide frame with motor facing front of trailer. D.
- Page 5 2: INSTALLING U-JOINT A. Temporarily attach U-joint with extension to drive shaft using cotter and clevis pins. Do not bend cotter pin tabs. B. Remove clevis and cotter pins holding PVC spacer on cartridge protruding from spool. Slide U-joint with extension into PVC spacer and cartridge. C.
- Page 6 3: ELECTRICAL A. Locate and clean suitable locations to apply caution stickers. B. Refer to included instructions to complete wiring.
- Page 7 • Check the tightness of mounting bolts and electrical connections, remove any dirt or corrosion that may have accumulated on the electrical connections. • Always use genuine Agri-Cover, Inc. replacement parts, use serial number to easily order replacement tarp. Serial number is located at rear...
- Page 8 Goods to be returned must have a pre-authorized RA # (Return Authorization Number) – obtained by calling the number above. Mark the number on the package and ship it freight prepaid to address below. Agri-Cover will pay freight to return goods to sender.
