- Page 1 Model: K0073 Smart Robot Car Kit Quick Start Guide...
- Page 2 Smart Robot Car Kit User Guide...
- Page 3 Smart Robot Car Kit User Guide...
- Page 4 Smart Robot Car Kit User Guide DC motors installation Step 1: Place the DC motor in the position marked on the chassis For example, the Front L and Front R marks should be matched between the motor and chassis Step 2: Install the DC motor 8 x M3*30 round head screws 4 x DC motors 8 x M3 nuts...
- Page 5 Smart Robot Car Kit User Guide After you complete the first 2 steps, your robot car should look like this: Step 3: Repeat the steps above, until 4 motors are all installed.
- Page 6 Smart Robot Car Kit User Guide Wheels installation 4 x Wheels After a successful motors and wheels installation, your robot car should look like this (from the down side of the chassis):...
- Page 7 Smart Robot Car Kit User Guide Pan and Tilt servos installation NOTE: Servo accessories do not fit as perfectly with the screw as nuts, and you might need to screw harder. Step 1: Mount the Pan servo accessory Flip the chassis over from the last step and find the center position of the servo before mounting 1 x Servo 1 x Servo accessory...
- Page 8 Smart Robot Car Kit User Guide Step 3: Mount the accessory of the Tilt servo 2 x Pan and Tilt brackets 2 x Pan and Tilt accessory screws Step 4: Mount the tilt servo and the camera module holder Find the center position of the servo before mounting 1 x Servo accessory 1 x Pan and Tilt bracket 2 x PTZ self-tapping screws...
- Page 9 Smart Robot Car Kit User Guide Step 5: Mount the servo and camera holder 1 x Servo accessory 1 x M2*4 round head screw Step 6: Mount the camera module Note the orientation of the Camera Module 1 x Camera module...
- Page 10 Smart Robot Car Kit User Guide Ultrasonic Module installation Step 1: Mount the ultrasonic sensor to its plastic holder 1 x Holder for HC-SR04 Ultrasonic Module 1 x HC-SR04 Ultrasonic Module Step 2: Mount the ultrasonic module to the chassis You can adjust the direction of the Pan-Tilt servo to the left and right to better install the nuts of the ultrasonic module and line follower...
- Page 11 Smart Robot Car Kit User Guide Mount the Line tracking module 2 x M3 nuts 1 x Line Tracking module 2 x M3*30 socket screws 2 x M3*6 round head screws...
- Page 12 Smart Robot Car Kit User Guide Install Raspberry Pi and Driver Controller board Step 1: Install Raspberry Pi Motherboard * Note: Pi is not included, bring your own Pi for this step. You might need to flip the chassis over to better install the nuts.
- Page 13 Smart Robot Car Kit User Guide Step 3: Install driver controller board 4 x M2.5*11 socket screws 4 x M2.5*6 round head screws 1 x Motor drive expansion board After you install the Raspberry Pi motherboard, ribbon cable, and the driver expansion board, you robot car should look like this:...
- Page 14 Smart Robot Car Kit User Guide Battery container installation Step 1: Install the Battery container 2 x M3 nuts 1 x Battery container 2 x M3*6 socket screws 2 x M3*5*4 countersunk head screws Step 2: Insert two 18650 batteries 2 x 18650 batteries...
- Page 15 Smart Robot Car Kit User Guide Ultrasonic module wiring 20cm 4-Pin cable Tracking module wiring 20cm 5-Pin cable...
- Page 16 Smart Robot Car Kit User Guide Pan and Tilt servos wiring Connect the cables in the orientation shown in the illustration below. Note the positions of the yellow and brown wires Battery container wiring...
- Page 17 Smart Robot Car Kit User Guide DC motors wiring J2 connector for Front DC motors J1 connector for Rear DC motors Camera module wiring Note the orientation of the FPC cable...
- Page 18 Dear Customer: Thanks for using the UCTRONICS Smart Robot Car Kit K0073 for Raspberry Pi. You can contact us at the email address below. Please don't hesitate to let us know if you need any support from us. We love helping our customers learn and play with our products.
