Summary of Contents for BSS Audio EasyLock
- Page 1 Installation instruction Motor-driven blocking device EasyLock 108360 VdS - Class C G 107 102 Version Page 1 8360Err_en.doc...
- Page 2 Any Technical changes are reserved. infringement obliged to compensation. All rights reserved! Installation company instruction Motor-driven blocking device EasyLock Item No: 108360.0 Version: 2.0a / 20.02.2008 MA Document: 108360Err_en.doc...
-
Page 3: Table Of Contents
Motor-driven blocking device EasyLock 8360.0 Installation instruction Contents General information ................... 4 Mechanic assembly / Safety ................... 4 Features of the blocking device ................4 Additional features with universal connection box........... 4 Installation ....................5 Assembly of the blocking device................5 Assembly of the counterpart ................... -
Page 4: General Information
Motor-driven blocking device EasyLock 8360.0 Installation instruction 1 General information The blocking device 8360 is designated for the following applications: • To prevent persons from accessing the armed area of a burglar alarm system • For access control applications in order to allow access only to authorized persons •... -
Page 5: Installation
Motor-driven blocking device EasyLock 8360.0 Installation instruction 2 Installation The most advantageous installation place is as near as possible to the existing striking plate of the lock since in this position it will have minimum effects if the door gets distorted. The blocking device can be installed at any position. -
Page 6: Assembly Of The Counterpart
Motor-driven blocking device EasyLock 8360.0 Installation instruction 2.2 Assembly of the counterpart The counterpart is assembled in the door leaf. It needs to be assembled in a way that the locking bolt can extend to the limit stop without contact. The maximum distance between the flange and the counterpart amounts to 5 mm. -
Page 7: Switching On
Motor-driven blocking device EasyLock 8360.0 Installation instruction 3 Switching on The switching on is performed via a 4-pin cable. Two leads are required for the voltage distribution - nominal 12 V DC. The drive is performed with a static signal 0 V-active. -
Page 8: Connection
Motor-driven blocking device EasyLock 8360.0 Installation instruction 3.2 Connection To connect the blocking device you can use the armed or not armed output of a burglary alarm center or a timely limited release signal for the entrance control applications. When activating the input, the blocking device will close, when deactivating, the blocking device will open. -
Page 9: Connection Of Several Blocking Devices
Motor-driven blocking device EasyLock 8360.0 Installation instruction 3.2.1 Connection of several blocking devices You can connect several blocking devices in series so that they will close one after another. The low tension side can be used by switching on LEDs to display the status. -
Page 10: Electrical Emergency Opening
Motor-driven blocking device EasyLock 8360.0 Installation instruction 4.1 Electrical emergency opening The blocking device offers the following electrical emergency opening options: Automatic opening of the blocking device after interrupting and switching on the distribution voltage again Independent from the fact if the control signal is fed, the blocking device will always open up after feeding the distribution voltage. -
Page 11: Replacing The Bolt
Motor-driven blocking device EasyLock 8360.0 Installation instruction 4.4 Replacing the bolt If the locking bolt is broken off you have the option to replace it without disassembling the blocking device. You need to perform the following steps: • Unscrew the screw cap from the housing... -
Page 12: Drilling Template
Motor-driven blocking device EasyLock 8360.0 Installation instruction 5 Drilling template Attention: Drilling template on a scale of 1:1 If required copy this page and cut out the drilling template! 8360Bohr.eps Illustration 5.1 6 Technical data Operating nominal voltage / voltage range 12 V DC / 8 ...
