7.1 Barometer Mode- Setting
Barometer Mode
Current Temperature display
Hold [M]
[M] Factory Default
Storm Alert
[M] [M]
[M] Air Pressure
Sea Pressure
Calibration
Calibration
Barometer Setting Sequence
[S/S] / [L/R] Hold [S/S] / [L/R]
Increase/
Increase/Decrease
Decrease
the number at a
the number
higher speed

8.0 Compass Mode - Tips and Precautions

Compass Navigation
Direction
Direction
Bearing
direction of
Magnetic North
navigation
Pole Pointer
direction
Current time
Compass Mode
Barometer setting
- In Barometer mode, press and hold [M] to enter
setting mode. Press [M] to select among the
settings.
- When Storm alert is ON, 30 second beep alert
will be given and " " will shown in Current
and World time mode when the watch predicts
the upcoming weather is stormy.
- Before calibrate the sea level pressure, consult
the nearest observatory to get the sea and air
pressure of your current position.
Important: Storm alert is triggered when pressure
drops quickly with a certain period of time. But
sometimes, a very fast pressure changes maybe
due to altitude changes. This pressure changes
due to altitude variation may result in exactly the
same pattern as storm altert false alarm may
occur.
Note:
- Input an incorrect pressure during the
adjustment procedure may results an incorrect
pressure reading in the future.
Keep the Watch away from Magnetic sources,
like:
- Speakers,
- Motors,
- Mobile phones and etc.
Avoid measuring direction when:
- Close to a magnetic object
- Close to metallic object
- Close to an electrical appliance
- Inside a moving object.
Perform compass calibration or magnetic
declination compensation process when:
- The Watch is using for the first time,
- The battery has been replaced,
- The bearing direction digits are flashing, and
the compass bearing and compass
direction are flashing
- The compass uses in a location that is apart
from the place in which the compass had
been calibrated,
- The user intends to regulate the precision of
the digital compass.

8.1 Compass Mode - Compass Directions and Bearings

N
object D
NW
N
E
object B
point
A
SE
Compass Directions object C
0°
angular
difference
object D 0°
315°
90°
object B
point
A
135°
object C
Compass Bearings
NOTE:
- This Watch includes both compass directions and compass bearings.

8.2 Compass Mode - Compass Display

the north
pole pointer
NO key has been
Compass
operated for
direction
1 minute
Compass
bearing
[S/S] or [L/R]
Current
Time
Compass Mode
NOTE:
- If NO key has been operated for about 1 minute, the Watch will go to IDLE Mode automatically. Press
[S/S] or [L/R] to resume the compass to normal operation .
- If distortion is detected, the compass bearing and compass direction are flashing. See 8.4 to restore
the compass to normal operation when distortion occurs.
Marks Compass Directions Compass Bearing
N North
349° - 11°
NNE North Northeast 12° - 33°
NE Northeast 34° - 56°
ENE East Northeast 57° - 78°
79° - 101°
E East
ESE
East Southeast 102° - 123°
SE Southeast
124° - 146°
SSE
South Southeast 147° - 168°
S South 169° - 191°
192° - 213°
SSW South Southwest
SW Southwest 214° - 236°
WSW
West Southwest 237° - 258°
West
W 259° - 281°
282° - 303°
WNW West Northwest
NW Northwest 304° - 326°
North Northwest 327° - 348°
NNW
Compass Idle Distortion
