Fridge Defend® by ARP
v5.x ARP & ARP + Fan Control
User Guide
Please click here for Online ARP Video Operation Manual
User Web Search Engine:
Click Here for Web Search before Contacting ARP Control
WARNING: The operator of the ARP Control is responsible for knowing the status of the
control at all times, including the self-test functions. The ARP Control is designed to turn itself
on if a power interruption occurs. A power interruption can be as simple as using the RV
Master Power Switch to turn off power during storage of the RV. In this situation, when the
power is restored to the RV, the ARP Control will turn itself on incase the operator forgets to
check the control. The operator must perform the Test of ARP Relay described in this manual
before each outing to confirm function of the ARP Control. Also, brown outs and transient on
the RV 12VDC supply can turn off the ARP Control, these power interruption are due to many
factors which go beyond the scope of this document to describe. Due to brown outs and
transients one needs to confirm that the ARP is functioning on a regular basis.
©
2020 ARPC L.L.C. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fridge Defend and is the answer not in the manual?

Questions and answers

Related Manuals for ARP Fridge Defend

Summary of Contents for ARP Fridge Defend

  • Page 1 Master Power Switch to turn off power during storage of the RV. In this situation, when the power is restored to the RV, the ARP Control will turn itself on incase the operator forgets to check the control. The operator must perform the Test of ARP Relay described in this manual before each outing to confirm function of the ARP Control.

  • Page 2: Table Of Contents

    24 hour self-test. Power surges can turn off the ARP Control just the same as any equipment in an RV, thus it is the operators responsibility to insure that the control is functioning properly.

  • Page 3: Graphical Reference

    MODE FUNCTIONS – The ARP must be turned off to enter any of the startup modes. 2.1 ARP Control Mode – See 2 & 3 below for other startup modes. 2: DISPLAY BUTTON ARP User Guide 1.2 View Boiler Temperature 1.3 View Fan Temperature...

  • Page 4: Introduction

    __________________________________________________________________________________________ BUTTON FUNCTION The following terms are used in the text to indicate how to make changes to the ARP control using the push buttons: Momentarily Press: This indicates that the operator depresses the button and then immediately releases in order to make a change.

  • Page 5: Arp Function

    Note: Every time the ARP has 12VDC applied to the red wire, the control will turn on. In ARP mode, fan control is active for the v5.1 control. The ARP control will turn on/off the fan when the fan temperature sensor reaches the fan set-point. Please...

  • Page 6: View Fan Temperature

    Make sure to return the ARP Control to the desired mode of operation when tests are completed. Press and hold the SetUp button to test the ARP relay. Your fridge must shut off during this test. The display will flash every other second until the SetUp button is held down again to go to the next test.

  • Page 7: Controller Function Test

    ARP will turn off the refrigerator and rapidly flash *O*F*8 until the operator resets the control by turning off the ARP. For the v5.1 control, an audible alarm will sound alerting the operator that the fridge has an error. Please consult an RV repair facility to restart your fridge if this event occurs.

  • Page 8: Excessive Overheat Condition *H*O*8

    RV repair person if in doubt. MODE FUNCTIONS The ARP Control has 3 modes of operation that are initiated upon startup of the control. Restated, turn off the ARP Control (see 1.10) before attempting to enter into different startup mode functions.

  • Page 9: No Set-Point Mode

    ARP and the optional fan control. CONCLUSION The ARP Control will protect your fridge by limiting the boiler temperature. The control has a number of functions that allow the operator to test the operation of the control. Please see the Installation Guide, Troubleshooting Guide, &...
  • Page 10 This manual has been provided courtesy of My RV Works, Inc. www.myrvworks.com You can find more RV service manuals here: www.myrvworks.com/manuals Over the years of running a mobile RV repair service, having a dedicated place to access service manuals for all the different appliances and components found on RVs was something that I always had a desire to create.
