Firmtech FB155BC User Manual

Bluetooth embedded module
Hide thumbs Also See for FB155BC:
Table of Contents

Advertisement

Quick Links

Download this manual
Bluetooth Embedded Module
FB155BC(HID) User Guide
Version 1.0
FIRMTECH Co., Ltd.
Homepage :
http://www.firmtech.co.kr
Mail :
contact@firmtech.co.kr
Tel : +82-31-719-4812
Fax : +82-31-719-4834

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FB155BC and is the answer not in the manual?

Questions and answers

Related Manuals for Firmtech FB155BC

Summary of Contents for Firmtech FB155BC

  • Page 1 Bluetooth Embedded Module FB155BC(HID) User Guide Version 1.0 FIRMTECH Co., Ltd. Homepage : http://www.firmtech.co.kr Mail : contact@firmtech.co.kr Tel : +82-31-719-4812 Fax : +82-31-719-4834...
  • Page 2 User Guide Version 1.0 Revision History FB155BC(HID) Revision History Revision Date Change Descriptions 04-11-2013 - Write a draft Page 2 / 23...
  • Page 3 Any part or whole of products or operation description shall not be copied, reproduced, translated, nor transformed into readable form by electronic device or machines, without prior consent in writing by FIRMTECH Co., Ltd. There might be some misprinting or technical faults in the products and operation description which are subject to change without prior notice.

  • Page 4: Table Of Contents

    6 Smart HID Interface Board (Jig Board) ....................... 14 7 Performance of Products ............................15 8 Current Consumption ..............................16 9 Preliminary Product Components .......................... 17 10 How to Use - FB155BC(HID) ........................... 18 11 Approval Information ..............................23 11.1 MIC ..................................23 11.2 FCC compliance Information........................23 11.3 CE ....................................

  • Page 5: What Is Bluetooth

    User Guide Version 1.0 1 What is Bluetooth? FB155BC(HID) 1 What is Bluetooth? 1.1 Features of Bluetooth Objectives of Bluetooth : To Realize Wireless Communication for Short Distance with Low Power  Consumption, High Reliability, and Low Cost. Frequency in Use: To Use ISM(Industrial, Scientific, Medical) Band which does not require any ...

  • Page 6: Product Overview

    Provides the most compact size among Class 2 EDR. Stable Data Transmission / Receipt ※ We request the new users of FB155BC(HID) to read the information on this description carefully before they start to use the products. Page 6 / 23...

  • Page 7: Product Components

    3 Product Components 3.1 FB155BC (HID) MODEL PICTURE Q’TY (EA) FB155BC (HID) (On-board chip antenna) <Table 3-1 Basic Components of FB155BC(HID)> 3.2 Smart HID Interface Kit (Option) MODEL PICTURE Q’TY (EA) Smart HID Interface Board ( Model : FBDx5xHID )
  • Page 8 User Guide Version 1.0 3 Product Components FB155BC(HID) <Table 3-2 Components of Smart Interface Kit > ※ If you find any of above components is defective, or not included in the package, please contact the seller you purchased. Page 8 / 23...

  • Page 9: Product Appearance

    User Guide Version 1.0 4 Product Appearance FB155BC(HID) 4 Product Appearance 4.1 FB155BC (HID) Dimension <Figure 4-1 FB155BC-HID Dimension> 4.2 FB155BC (HID) PIN Assign <Figure 4-2 FB155BC-HID PIN Assign> Page 9 / 23...
  • Page 10 User Guide Version 1.0 4 Product Appearance FB155BC(HID) Name of Signal Features I / O Level Ground 3.3V DC Input STATUS STATUS LED Output MULTI FUNCTION Multi Function Control Input (Full-up) None Connect HID STATUS HID Status Output Transfer Data (Data out)

  • Page 11: Interface (Pin Connection)

    User Guide Version 1.0 5 Interface (Pin Connection) FB155BC(HID) 5 Interface (Pin Connection) 5.1 Port Connection <Figure 5-1 Pin Connection> <Figure 5-2 I/O Pin Connection Diagram> Page 11 / 23...

  • Page 12: Port Description

    User Guide Version 1.0 5 Interface (Pin Connection) FB155BC(HID) 5.1 Port Description - STATUS (No. 3) Shows the Bluetooth Connection status of FB155BC(HID) Connection Status Signal Status Description Shows the unconnected status in the standby mode When not Connected HIGH (3V)
  • Page 13 User Guide Version 1.0 5 Interface (Pin Connection) FB155BC(HID) <Figure 5-3 MULTI FUNCTION Event Last Connect Request Timing > <Figure 5-4 MULTI FUNCTION Event Hard Reset Timing> Note : If the Multi Function signal gets full-up, it may function erroneously.

  • Page 14: Smart Hid Interface Board (Jig Board)

    User Guide Version 1.0 6 Smart HID Interface Board (Jig Board) FB155BC(HID) 6 Smart HID Interface Board (Jig Board) <Figure 6-1 Smart HID Interface Board (Jig Board)> Page 14 / 23...

  • Page 15: Performance Of Products

    18 x 20 mm Support Bluetooth Profile HID Device Input Power 3.3V Current Consumption 48 mA (Max) Operating Temperature -10℃ ~ 50℃ Communication Speed 115,200 bps Antenna Chip Antenna Interface UART (TTL Level) <Table 7-1 FB155BC(HID) Performance> Page 15 / 23...

  • Page 16: Current Consumption

    User Guide Version 1.0 8 Current Consumption FB155BC(HID) 8 Current Consumption Current Consumption (mA) Status Standby Inquiry scan & Page scan (Slave) Page scan (Slave) Connected Data Transmission Data Reception Data Transmission / Reception Power Save <Table 8-1 Current Consumption>...

  • Page 17: Preliminary Product Components

    Set Value Device Name FB155 HID Pin Code (Pass key) 0000 Uart (baud rate-data bit-parity bit-stop bit) 115200-8-N-1 ROLE SLAVE Connection Mode MODE4 (AT command) Debug Char 0x02 <Table 9-1 Preliminary Configuration Setting Value for FB155BC(HID)> Page 17 / 23...

  • Page 18: How To Use - Fb155Bc(Hid)

    Report via UART when FB155BC(HID) is connected with the other Bluetooth device. To generate an HID Report, external MCU or HID Report to UART program is required. Firmtech offers a test board and Smart HID Interface Kit providing sample source as options.
  • Page 19 User Guide Version 1.0 10 How to Use - FB155BC(HID) FB155BC(HID) - Pointer Report Format (Mouse) Byte Value Description 0 (first byte in packet) 0x08 Length of packet in bytes (8) 0x00 Type of packet: Forward HID Report 0xa1 HID input Report Header...
  • Page 20 User Guide Version 1.0 10 How to Use - FB155BC(HID) FB155BC(HID) 0x2E 0x37 0x2F 0x38 0x30 0x27 0x31 0x1E 0x32 0x1F 0x33 0x20 0x34 0x21 0x35 0x22 0x36 0x23 0x37 0x24 0x38 0x25 0x39 0x26 0x3B 0x33 0x3D 0x2E 0x5B...
  • Page 21 User Guide Version 1.0 10 How to Use - FB155BC(HID) FB155BC(HID) 0x2A 0x25 0x2B 0x2E ( Shift+8 ) ( Shift+= ) < 0x3A 0x33 0x3C 0x36 ( Shift+; ) ( Shift+, ) > 0x3C 0x36 0x3F 0x38 ( Shift+. )
  • Page 22 It transmits the “Pressed” value when a key on the keyboard is pressed and transmits the “Released” value to FB155BC (HID) when the key on the keyboard is released. In the above example, users are required to transmit 0x1e - the value of the number “1” in the ASCII to Keycode table when the Keycode 1 in the UART HID Report ID Format.

  • Page 23: Approval Information

    End users cannot modify this transmitter device. Any unauthorized modification could void the user’s authority to operate this device. 11.3 CE Hereby, FIRMTECH Co., Ltd, declares that this FB155BC is in compliance with the essential requirements and other relevant provisions of directive 1999/5/EC. 11.4 TELEC 11.5 SIG...
