Page 1: Table Of Contents
® 12. Troubleshooting for Aquarius System 13. Environmental Specifications ® 14. Aquarius Options Copyright © 2020 White Knight Fluid Handling | A Graco company Version 1.0.0 | 29 Apr 2020 info@heateflex.com https://wkfluidhandling.com P: 626.599.8566 | Subject to change without notice...
Page 2 Corner Stretch Wrap Block Box or Crate Strap Foam Pallet Copyright © 2020 White Knight Fluid Handling | A Graco company Ver. 1.0.0 | 29 Apr 2020 | P. 2 info@heateflex.com https://wkfluidhandling.com P: 626.599.8566 | Subject to change without notice...
Page 3: Receiving Procedures
If there are any shortages or questions regarding this shipment, please notify us within ten (10) days. Copyright © 2020 White Knight Fluid Handling | A Graco company Ver. 1.0.0 | 29 Apr 2020 | P. 1 info@heateflex.com...
Page 5 (Optional) We are confident in our product quality and reliability, and we offer technical support. Copyright © 2020 White Knight Fluid Handling | A Graco company Ver. 1.0.0 | 29 Apr 2020 | P. 3 info@heateflex.com...
Page 6: Factory Performance Test
At 95°C, the unit may trigger the High Temperature Alarm. High Temperature Alarm indicates that adjustments are possibly required. Make adjustments as indicated in the TROUBLESHOOTING GUIDE. Copyright © 2020 White Knight Fluid Handling | A Graco company Ver. 1.0.0 | 29 Apr 2020 | P. 4 info@heateflex.com https://wkfluidhandling.com...
Page 7 Alarm will trigger and the controller will disable the heaters and send the unit into STANDBY mode. iii) Return the “High Temperature Alarm Set Point” to the original setting. Copyright © 2020 White Knight Fluid Handling | A Graco company Ver. 1.0.0 | 29 Apr 2020 | P. 5 info@heateflex.com https://wkfluidhandling.com...
Page 8 ® f. Aquarius pump air cooling systems are tested to ensure optimal pump performance. Copyright © 2020 White Knight Fluid Handling | A Graco company Ver. 1.0.0 | 29 Apr 2020 | P. 6 info@heateflex.com https://wkfluidhandling.com P: 626.599.8566 |...
Page 9: Basic Safety Precautions
• If it becomes necessary to work on the unit with the power applied, keep one hand free at all times (behind you). Copyright © 2020 White Knight Fluid Handling | A Graco company Ver. 1.0.0 | 29 Apr 2020 | P. 7 info@heateflex.com...
Page 10 Whenever servicing this unit, at least 300 lumens of light is required; otherwise use portable lighting that does not have to be held. Copyright © 2020 White Knight Fluid Handling | A Graco company Ver. 1.0.0 | 29 Apr 2020 | P. 8 info@heateflex.com...
Page 11 9. Caution Hot Surface Caution label for hot surface. 10. High Power Label for high power. Copyright © 2020 White Knight Fluid Handling | A Graco company Ver. 1.0.0 | 29 Apr 2020 | P. 9 info@heateflex.com https://wkfluidhandling.com P: 626.599.8566 |...
Page 12: Pre-Installation Preparation
Heateflex assumes no risk for noncompliance. Heateflex does not warranty any equipment that does not use Heateflex interlock safety devices. Copyright © 2020 White Knight Fluid Handling | A Graco company Ver. 1.0.0 | 29 Apr 2020 | P. 10 info@heateflex.com...
Page 13: Installation Instructions
Remote EMO is to be used. (Maximum input resistance is 600 Ohms) Copyright © 2020 White Knight Fluid Handling | A Graco company Ver. 1.0.0 | 29 Apr 2020 | P. 11 info@heateflex.com...
Page 14 Aquarius DIW Heaters Owner’s Manual Copyright © 2020 White Knight Fluid Handling | A Graco company Ver. 1.0.0 | 29 Apr 2020 | P. 12 info@heateflex.com https://wkfluidhandling.com P: 626.599.8566 | Subject to change without notice...
Page 15 For more detailed information on the Aquarius control system and operation screens please refer to the PF3000 controller manual. Copyright © 2020 White Knight Fluid Handling | A Graco company Ver. 1.0.0 | 29 Apr 2020 | P. 13 info@heateflex.com https://wkfluidhandling.com...
Page 16: System Shut Down Procedure
Aquarius ® system, such as electrical power, pneumatic air (CDA) and DIW. Copyright © 2020 White Knight Fluid Handling | A Graco company Ver. 1.0.0 | 29 Apr 2020 | P. 14 info@heateflex.com https://wkfluidhandling.com P: 626.599.8566 |...
Page 17: Suggested Operational Inspection
The system should be disinfected on the same schedule and with the same procedures as the main DIW distribution network. Copyright © 2020 White Knight Fluid Handling | A Graco company Ver. 1.0.0 | 29 Apr 2020 | P. 15 info@heateflex.com...
Page 18: Aquarius
Aquarius ® plumbing, which is essential in maintaining high purity requirements. Copyright © 2020 White Knight Fluid Handling | A Graco company Ver. 1.0.0 | 29 Apr 2020 | P. 16 info@heateflex.com https://wkfluidhandling.com P: 626.599.8566 |...
Page 19 1. Provide an open “Recirculation Signal” to the system to initiate the “Demand” mode. Note: If Recirculation System is disabled, “Recirculation Signal” has no affect on recirculation. Copyright © 2020 White Knight Fluid Handling | A Graco company Ver. 1.0.0 | 29 Apr 2020 | P. 17 info@heateflex.com...
Page 20 See plumbing schematic for setting. 5) Proceed with the Pump Air Cooling System Calibration procedure. Copyright © 2020 White Knight Fluid Handling | A Graco company Ver. 1.0.0 | 29 Apr 2020 | P. 18 info@heateflex.com...
Page 21 Note: regulated air pressure of the pump air cooling system is dependent on the air supply source pressure. Please provide a stable supply of air to the pump air cooling system. Copyright © 2020 White Knight Fluid Handling | A Graco company Ver. 1.0.0 | 29 Apr 2020 | P. 19 info@heateflex.com...
Page 22: Troubleshooting For Aquarius
D. Verify that an adequate supply of air is present to the solenoid valves. E. Verify that the solenoid valves are operational. F. Verify that the air operated valves (AOV) are operational. Copyright © 2020 White Knight Fluid Handling | A Graco company Ver. 1.0.0 | 29 Apr 2020 | P. 20 info@heateflex.com https://wkfluidhandling.com...
Page 23 E. Verify that the recirculation liquid level (L/L #2) sensor is functional. For more information, please refer to the PF3000 controller manual. Copyright © 2020 White Knight Fluid Handling | A Graco company Ver. 1.0.0 | 29 Apr 2020 | P. 21 info@heateflex.com...
Page 24: Environmental Specifications
For daily energy consumption information, reference the Quality Control documentation. Copyright © 2020 White Knight Fluid Handling | A Graco company Ver. 1.0.0 | 29 Apr 2020 | P. 22 info@heateflex.com...
Page 25: Aquarius Options
Aquarius system, which eliminates stagnant fluid in the system. Low Resistivity Alarm is provided. Copyright © 2020 White Knight Fluid Handling | A Graco company Ver. 1.0.0 | 29 Apr 2020 | P. 23 info@heateflex.com https://wkfluidhandling.com P: 626.599.8566 |...
Page 26 The RUN key must be pressed first in order to utilize the “Remote Stop” function. Copyright © 2020 White Knight Fluid Handling | A Graco company Ver. 1.0.0 | 29 Apr 2020 | P. 24 info@heateflex.com...
Page 27 DIW usage and reinforces high purity requirements by discouraging bacteria growth from forming in the process fluid and Aquarius ® plumbing. Copyright © 2020 White Knight Fluid Handling | A Graco company Ver. 1.0.0 | 29 Apr 2020 | P. 25 info@heateflex.com https://wkfluidhandling.com P: 626.599.8566 |...
Page 28 435.783.6128 support@wkfluidhandling.com https://wkfluidhandling.com/support/ Heateflex® Heater Patent No.: 4,756,781, 4,835,365, 4,875,957, 2685505 (Japan) Part No. IM1000-1708 Copyright © 2020 White Knight Fluid Handling | A Graco company Version 1.0.0 | 29 Apr 2020 info@heateflex.com https://wkfluidhandling.com P: 626.599.8566 | Subject to change without notice...
