Industrial computers POSYC 3401/3402
Smitec S.p.A., viale Vittorio Veneto 4, 24016 San Pellegrino Terme (BG), Italy, www.smitec.it
Installation, use and maintenance manual
BEFORE STARTING UP THE INDUSTRIAL COMPUTERS POSYC 3401/3402, CARE-
FULLY READ THIS MANUAL AND FOLLOW ALL INSTRUCTIONS, IN ORDER TO EN-
SURE MAXIMUM SAFETY
INDUSTRIAL COMPUTERS
The technical data and the drawings in this manual might have been modified later; always
refer to the latest version.
Ver. 1.03
POSYC 3401/3402
Installation, use and maintenance manual - EN
1
Advertisement
Table of Contents
Summary of Contents for Smitec POSYC 3401
- Page 1 Industrial computers POSYC 3401/3402 Installation, use and maintenance manual - EN Smitec S.p.A., viale Vittorio Veneto 4, 24016 San Pellegrino Terme (BG), Italy, www.smitec.it Installation, use and maintenance manual BEFORE STARTING UP THE INDUSTRIAL COMPUTERS POSYC 3401/3402, CARE- FULLY READ THIS MANUAL AND FOLLOW ALL INSTRUCTIONS, IN ORDER TO EN-...
-
Page 2: Table Of Contents
5.3.1.2 Side view ........................... 10 5.3.1.3 Rear view (recommended panel cut)................. 11 5.4 Hardware features ..........................12 5.4.1 Basic hardware ......................... 12 5.4.1.1 POSYC 3401 ........................12 5.4.1.2 POSYC 3402 ........................12 5.5 Order codes ............................13 5.6 Accessories ............................13 6 Connections and LEDs ........................... -
Page 3: Preface
Industrial computers POSYC 3401/3402 Installation, use and maintenance manual - EN 1 Preface This manual provides all necessary information for the installation, use and maintenance of industrial comput- ers POSYC 3401/3402. The instructions included in this manual are addressed to the following professionals:... -
Page 4: General Warnings
MANUAL. THE EQUIPMENT CANNOT BE USED FOR PURPOSES DIFFERENT THAN THE ONES DESCRIBED IN THIS MANUAL; SMITEC S.p.A. SHALL NOT BE HELD RESPONSIBLE FOR ANY DAMAGES, INCON- VENIENCES OR ACCIDENTS DUE TO THE NON-COMPLIANCE WITH THESE PRESCRIPTIONS. In order to make the manual consultation easier, the following symbols have been adopted: Indication of “PROHIBITED ACTION”. - Page 5 Industrial computers POSYC 3401/3402 Installation, use and maintenance manual - EN The safety prescriptions aim at establishing a series of behaviors and obligations to be complied with, while performing the activities described later on in this manual. These prescriptions constitute the prescribed method of operating the device, in a way that is safe for person- nel, equipments and environment.
-
Page 6: Safety Instructions
It is absolutely forbidden to use the equipment for different purposes than the ones de- scribed in this manual. The technical data and the drawings in this manual might have been modified later; always refer to the latest version. All upgrades can be requested to SMITEC S.p.A. directly. -
Page 7: Product Description
Industrial computers POSYC 3401/3402 Installation, use and maintenance manual - EN 4 Product description The POSYC is an ARM-based computer designed primarily as a human-machine interface (HMI) process-con- troller, with I/O (depending on the model) and integrated FLXIO bus controller. -
Page 8: Technical Data
POSYC computer produced at the date of writing of this document. With the aim of improving or updating the product technologically, SMITEC S.p.A. reserves the right to change the technical features of the POSYC computer without notice. -
Page 9: Mechanical Characteristics
5.3.1 Mechanical dimensions 5.3.1.1 Front view The computers Posyc 3401/3402 need to be fixed on a stable and rigid panel provided with 4xM3 metal thread- ed hole, min. 1.5mm deep. Use 4xM3x10mm Fe/Zn (not countersunk head type) screws, min. class 8.8, tight- ened at 1Nm. -
Page 10: Side View
Industrial computers POSYC 3401/3402 Installation, use and maintenance manual - EN 5.3.1.2 Side view Ver. 1.03... -
Page 11: Rear View (Recommended Panel Cut)
Industrial computers POSYC 3401/3402 Installation, use and maintenance manual - EN 5.3.1.3 Rear view (recommended panel cut) Ver. 1.03... -
Page 12: Hardware Features
Industrial computers POSYC 3401/3402 Installation, use and maintenance manual - EN 5.4 Hardware features The hardware whose features are described is the minimum guaranteed in the product and functionally tested; some peripherals possibly present in addition to the purchased product are not guaranteed neither for production continuity nor for functionality. -
Page 13: Order Codes
Hardware base PC without I/O, 1 Ethernet, FLXIO bus not isolated AUDION (UL) 5.6 Accessories The POSYC 3401/3402 industrial computers come with a power connector. The same can be ordered sepa- rately as well as other accessories not included in the POSYC. Below is the list of order codes. -
Page 14: Connections And Leds
Earth protection connection ETH 1 Ethernet communication port 1 ETH 2 Ethernet communication port 2 (only for POSYC 3401) 24V digital inputs and outputs (only for POSYC 3401) FLXIO communication port 1 FLXIO communication port 2 FLXIO communication port 3 Ver. 1.03... -
Page 15: Side Panel View
RESET USB AB POSYC 3401/3402 Name Function Socket for micro SD card USB AB AB type USB micro port (for SMITEC internal use only) RESET Reset button USB 1 Port 1 USB 2.0 USB 2 Port 2 USB 2.0 Red LED: indication of operating status of the device (depends on the application) -
Page 16: Pwr Connector
Industrial computers POSYC 3401/3402 Installation, use and maintenance manual - EN 6.3 PWR connector The connector used to power the POSYC 340X, has spring contacts to facilitate wiring of individual cables. Connector type: Phoenix Contact FK-MCP 1,5/2-STF-3,81 (1851232) * **... - Page 17 Industrial computers POSYC 3401/3402 Installation, use and maintenance manual - EN CAUTION Use a cable with a suitable cross-section, sized correctly according to the through-current. A cable with a section smaller than that required may cause fire due to overheating phenom- ena generated by the cable itself.
-
Page 18: Ethernet Ports
Industrial computers POSYC 3401/3402 Installation, use and maintenance manual - EN 6.4 Ethernet ports Depending on the model, there are one or two 10/100 Mbps Ethernet ports that use standard RJ45 Ethernet connectors. The Ethernet port has two LEDs. The first one, in green color, marked with the letter L, indicates if the door is connected. -
Page 19: Flxio Port
6.5 FLXIO port The POSYC 3401/3402, are equipped with three FLXIO doors; the ports are isolated in the model 3401 unlike the model 3402. This proprietary field bus is based on an RS485 electrical interface and allows a reliable real- time control of complex applications. -
Page 20: I/O Connector
Installation, use and maintenance manual - EN 6.6 I/O connector The connector used for the wiring of the digital I / O of the POSYC 3401/3402 is detachable and has spring- loaded contacts to facilitate the wiring of the individual cables:... - Page 21 Industrial computers POSYC 3401/3402 Installation, use and maintenance manual - EN I/O port Signal VI (24V inputs power supply) VO (24V outputs power supply) GI (GND) GO (GND) IO5 (Input 5) IO1 (Input/output 1) IO6 (Input 6) IO2 (Input/output 2)
-
Page 22: Installation
Industrial computers POSYC 3401/3402 Installation, use and maintenance manual - EN 7 Installation During installation of the POSYC 340X computer, falls and violent shocks must be avoided which could compromise the smooth operation. Avoid touching the input / output connectors on the computer panel directly unless you are equipped with suitable static electricity protection equipment;... -
Page 23: Electrical Connections
Industrial computers POSYC 3401/3402 Installation, use and maintenance manual - EN 7.3 Electrical connections The essential connections for POSYC operation are power and ground; make these two connections by fol- lowing the polarity, conductors and connectors indicated in the “Connections” chapter. Before switching on the appliance, check that the power supply voltage is within the parameters specified. -
Page 24: Use
Industrial computers POSYC 3401/3402 Installation, use and maintenance manual - EN 8 Use 8.1 Touch screen The use of the POSYC computer is very similar to a normal desktop computer; the only substantial difference is the touch screen pointing device which, however, allows an even more intuitive use of the computer. -
Page 25: Micro Sd Card
Industrial computers POSYC 3401/3402 Installation, use and maintenance manual - EN 8.3 Micro SD card The positioning of the micro SD card and the simplicity of extraction / insertion allows a quick replacement both in case of failure and off-line software update. -
Page 26: Ordinary Maintenance
Industrial computers POSYC 3401/3402 Installation, use and maintenance manual - EN 9 Ordinary maintenance 9.1 Cleaning the touch screen sensor The cleaning of the touch-screen sensor must take place rather frequently to avoid the stratification of the dirt derived from the hands or from materials that were accidentally in contact with its surface and to maintain the best possible visibility of the display. -
Page 27: Analytical Index
Industrial computers POSYC 3401/3402 Installation, use and maintenance manual - EN 10 Analytical index Absorbed power..........8 USB ports..........12, 24 ARM ..............7 Weight ............... 9 Battery.............. 26 Boot devices ............ 25 CFast card ............25 Cleaning............26 Current consumption.......... 8 Display .............
