EVA Logik NST003 Manual

Glass break alarm

NST003 Glass Break Alarm Manual

1. Status LED

2. Siren

3. Battery compatment

4. Switch

SPECIFICATIONS :

Alarm: >120dB SPL/30cm

Power Supply: 2 * AAA batteries

Dim.: 78*78*16.49mm

1. Easy to install - no wiring, stick the alarm on any window or glass surface, warning words

visible outside.

2. Turn the unit upside down and open the battery compartment install AAA*2pcs batteries

noting polar (not included) and close the compartment.

3. Place switch to the "-/+" (low/high sensitivity selection) position to set up a defensive.

4. Low-battery indicator light, If you see the indicate red LED always on, then need replace

new battery.

1. To arm the unit, open the battery compartment at the front of unit, install 2pcs AAA

batteries and close it. Sliding the power switch to the "-/+" position, and the device will

emit a powerful 120-decibel alarm when the window or glass door is tampering or

breakage and the alarm siren will sound continuously 60second.

2. LED blink every 4 seconds when switched "-/+".

- +

Table of Contents

Do you have a question about the NST003 and is the answer not in the manual?

Page 1 NST003 Glass Break Alarm Manual 1. Status LED 2. Siren 3. Battery compatment 4. Switch SPECIFICATIONS : Alarm: >120dB SPL/30cm Power Supply: 2 * AAA batteries Dim.: 78*78*16.49mm INSTALLATION : 1. Easy to install - no wiring, stick the alarm on any window or glass surface, warning words visible outside.
Page 2 3. You can adjust the sensitivity of the sensor by using the "+(high)/-(low)" switch. As a standard you should use the "+" testing. But depending on the surranding sounds or when used on a sliding glass door, the alarm might be triggered without reason. In such cases reduce the sensitivity to "-".
