www.voptech.com
Bluetooth/USB HD Conference Omnidirectional
Speakerphone UC200 Series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UC200 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for voptech UC200 Series

  • Page 1 Bluetooth/USB HD Conference Omnidirectional Speakerphone UC200 Series...

  • Page 2: Table Of Contents

    Content Delivery Content ..........................4 LED Status Description ........................ 5 USB200U ............................6 3.1 Buttons Description ........................6 3.2 Function Description ........................7 3.2..1 Power on/off ......................... 7 3.2.2 Turn on/off the speaker ..................... 7 3.2.3 Mute/unmute the microphone ..................7 3.2.4 Volume up/down ........................
  • Page 3 5.2.2 Turn on/off the speaker ....................14 5.2.3 Mute/unmute the microphone ..................14 3.2.4 Volume up/down ........................ 14 5.2.5 AUX mode ..........................14 5.2.6 Connecting USB to PC ....................15 5.2.7 Battery level query ......................15 5.2.8 Connecting wireless adapter ..................15...

  • Page 4: Delivery Content

    1. Delivery Content USB Speakerphone Type C USB Line Carry Pouch Wireless Adapter (UC200W)

  • Page 5: Led Status Description

    2. LED Status Description Blue Bluetooth Connected Green USB Connected Microphone Mute White Battery Rating Orange Battery’s low Purple Speaker Closed Blue light flashing Bluetooth Pairing White light flashing Battery Charging...

  • Page 6: Usb200U

    3. USB200U 3.1 Buttons Description Button Description Function/Operation Power Press for 3 seconds to turn on/off the power Multifunctional Press to turn on/off the speaker Microphone Press to mute/unmute the microphone Volume down Press to turn down the volume...

  • Page 7: Function Description

    3.2 Function Description 3.2..1 Power on/off  Power on: Press for 3 seconds to turn on the power. The white LED lights up from the left to right. Once the USB connection is successful, the green LED is on.

  • Page 8: Connecting Usb To Pc

    Then turn on the power of the active speaker. 3.2.6 Connecting USB to PC  Use standard Type-C USB line, the USB end connects to the PC, the other end connects to the speakerphone.  Green LED is always on when the speakerphone turns on.

  • Page 9: Usb200B

    4. USB200B 4.1 Buttons Description Button Description Function/Operation Power Press for 3 seconds to turn on/off the power Multifunctional 1. Bluetooth on/off: Double click to turn on/off the Bluetooth. 2. Press to answer the call when there is an incoming call.

  • Page 10: Function Description

    4.2 Function Description 4.2..1 Power on/off  Power on: Press for 3 seconds to turn on the power. The white LED lights up from the left to right. Once the USB connection is successful, the green LED is on.

  • Page 11: Connecting Usb To Pc

    Then turn on the power of the active speaker. 4.2.6 Connecting USB to PC  Use standard Type-C USB line, the USB end connects to the PC, the other end connects to the speakerphone.  Green LED is always on when the speakerphone turns on.

  • Page 12: Connecting The Speakerphone's Bluetooth

    4.2.10 Connecting the speakerphone’s Bluetooth  Mobile phone connecting the speakerphone’s Bluetooth: double click to turn on the Bluetooth, Blue LED will be flashing. Then turn on the Bluetooth of the mobile phone, search “BT_BLU5.0” and connect to it. Blue LED is always on when the Bluetooth is connected successfully.

  • Page 13: Usb200W

    5. USB200W Button Description Function/Operation Power Press for 3 seconds to turn on/off the power Press to query the battery level Multifunctional Click to turn on/off the speaker Microphone Press to turn on/off microphone Double click to query the...

  • Page 14: Function Description

    5.2 Function Description 5.2..1 Power on/off  Power on: Press for 3 seconds to turn on the power. The white LED lights up from the left to right. Once the USB connection is successful, the green LED is on.
  • Page 15 5.2.6 Connecting USB to PC  Use standard Type-C USB line, the USB end connects to the PC, the other end connects to the speakerphone.  Green LED is always on when the speakerphone turns on.
