Automatic Divider Round
POLO Auto Premium 15-22-30-30S-52
During the working phase the automatic divider rounder must
always works with the ring and rounding plate . It must be
used just by one operator.
Clean everyday even better repeatedly the rounding plate support surface and
both sides of the rounding plate
User's manual
MANUAL
INDEX
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Merand POLO Auto Premium 15
Summary of Contents for Merand POLO Auto Premium 15
- Page 1 User’s manual Automatic Divider Round POLO Auto Premium 15-22-30-30S-52 MANUAL During the working phase the automatic divider rounder must always works with the ring and rounding plate . It must be used just by one operator. Clean everyday even better repeatedly the rounding plate support surface and...
- Page 2 INDEX PAGE 1 INSTRUCTIONS – PRECAUTIONS – GENERAL NOTICE- SAFETY - PAGE 1 INTRODUCTION SYMBOLS – PLATES - WARRANTY PAGE 2 NOISE LEVELS - CORRECT AND UNCORRECT USE - RISKS – GENERAL PAGE 3 RULES – OPTIMUM ENVIRONMENTAL CONDITIONS – LIGHTING TECHNICAL DATA –...
- Page 3 ATTENTION Do not operate the machine under the influence of alcohol, drugs or any medicine that may alter the physical conditions of the operator. Keep away hair and other parts of the body from the rotating parts, pulleys and gears. Keep clean and in order danger and safety signs GRAPHICAL SYMBOLS USED IN THIS MANUAL Particularly important warnings to carry out operations in a correct manner or to carry out...
-
Page 4: Manufacturer Data
MANUFACTURER DATA AGENT DATA AFTER SALE DATA NOISE LEVELS The measurement of the noise was made during the idling of the machine at max. speed, in conformity to the ISO 11201 rule, so placing the measurement tool microphone at a supporting plan height of 1,6 mt. and 1 mt. in front of the machine. - Page 5 Premium 15 Premium 22 Premium30 Premium 30S Premium Divisions no. Max. and min. weights - divisions 80-260 gr 50-180 gr 40-135 gr 25-90 gr 12-35 gr Max. dough capacity (kg.) 2,08 Machine dimensions cm. 64x64x142 64x64x142 64x64x142 64x64x142 64x64x142 Machine weight kg. Installed power in Kw 1,55 1,55...
-
Page 6: Electrical Connection
Place the machine on a flat floor. Settle it adjusting the feet by the special key supplied with the machine. Leave enough space around the machine to facilitate working operations and maintenance. ELECTRICAL CONNECTION The electrical connection must be carried out by qualified personnel. Check that the power supply has the same rating as indicated on the machine identification plate. - Page 7 Make at least one working cycle without using the dough. ANY DAMAGE TO MACHINE DUE TO INCORRECT USAGE OR DUE TO MODIFICATION IS NOT COVERED BY GUARANTEE. CONTROL BOARD FIG.2-3 MAIN SWITCH START PUSH-BUTTONS KNIVES CLEANING PUSH-BUTTON SCREEN...
- Page 8 SAFE AND CORRECT USE OF THE MACHINE The machine to meet the different working needs permits the pressing time adjustment. The control panel is extremely easy and intuitive. Once the machine is switched on (by turning the switch 5-fig.3) it appears on the screen “program nr.
-
Page 9: Machine Cleaning And Maintenance
MACHINE CLEANING AND MAINTENANCE CLEAN THE MACHINE AT LEAST ONCE A WEEK AND IF NECESSARY ALL DAYS During the maintenance the machine must be disconnected from the power supply. All these operations included the parts replacement or problems to electrical plant must be carried out by qualified personnel. If the machine is under guarantee you have to get in touch immediately with the manufacturing firm. - Page 10 MOTOR BELT TENSION – OIL FILLING UP Remove the left side panel. Check the belt tension . If necessary use nut 9 to tighten the belt. Once the regulation is complete re-assemble carefully the panel. For the oil filling up remove the back panel , unscrew the tank cap and add recommended oil : ESSO NUTO H32 .
- Page 11 Let the dough rest for more time before using it with the machine. With hard dough press a little more and with more force . This will give to the dough a more uniform thickness POSSIBLE TECHNICAL PROBLEMS AND SOLUTIONS PROBLEM SOLUTION The machine does not start...
