RESEARCH&DEVELOPMENT OF AMERICA, INC.
5420 DANIELS STREET STE A, CHINO CA., 91710 · (800) 634-9166 · (909) 628-4722 · FAX (909) 591-2198
www.yoshimura-rd.com
FENDER ELIMINATOR KIT
070BG191350
Benelli
TNT 135
THIS PRODUCT IS NOT DOT APPROVED.
Yoshimura R&D of America, Inc. is not liable or responsible for any resulting event caused by the
!
!
installation of this product. Check with local laws and regulations for compliance prior to
installation and use. This product is not intended for use on public highways.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Benelli TNT 135 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Yoshimura Benelli TNT 135

  • Page 1 TNT 135 THIS PRODUCT IS NOT DOT APPROVED. Yoshimura R&D of America, Inc. is not liable or responsible for any resulting event caused by the installation of this product. Check with local laws and regulations for compliance prior to installation and use. This product is not intended for use on public highways.
  • Page 2 Yoshimura LED Rear Turn Signal Kit w/ Relay 070BGUNVTBKT Universal Turn Signal Bracket Kit ** Not shown on diagram. *** The Yoshimura Universal Turn Signal Bracket Kit is to be used with aftermarket stud-mounted turn signals and is sold separately.
  • Page 3 Removal 3. Connect the Yoshimura license plate light wires to the stock license plate light as follows: 1. Remove passenger seat. Red -to- Red / White 2. Locate and disconnect license plate light Black -to- Black connector. a) Strip the stock fender light wire ends 3.
  • Page 4 5. Route license plate light wires through loops on (No. 1) 19135-FEBKT, fender eliminator bracket and through hole in undertail where the rubber cover was previously removed. 6. Re-connect license plate light connectors. 7. Re-install passenger seat. 8. Check for proper function of license plate light, turn signals, brake light, and that all brackets and components are secure prior to riding.
