Addendum – Rapido
Rapido
Addendum –
High-Speed Operators
High-Speed Operators
This addendum is to be used in conjunction with the Installation & Instruction Manual.
Commercial & Industrial
High-Speed
Heavy-Duty
Operator
Commercial & Industrial
High-Speed
Heavy-Duty
Operator
(For fast doors with high performance and speed managing requirements)
(For fast doors with high performance and speed managing requirements)
RSH
RSH
READ AND FOLLOW ALL INSTRUCTIONS.
SAVE THESE INSTRUCTIONS.
GIVE TO END-USER.
Serial #
Model #
Wiring Diagram #
Project #/Name
Door #/Name
For technical support, please call 1-800-361-2260 or visit
www.manaras.com
for more information

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Rapido RSH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Manaras Opera Rapido RSH

  • Page 1 Addendum – Rapido Rapido Addendum – High-Speed Operators High-Speed Operators This addendum is to be used in conjunction with the Installation & Instruction Manual. Commercial & Industrial High-Speed Heavy-Duty Operator Commercial & Industrial High-Speed Heavy-Duty Operator (For fast doors with high performance and speed managing requirements) (For fast doors with high performance and speed managing requirements) READ AND FOLLOW ALL INSTRUCTIONS.

  • Page 2: Table Of Contents

    ABLE OF ONTENTS Installation Instructions............................... 3 General Specifications and Dimensions (RSH)..............................4 Limit Switches & Limit Cams: Adjustment & Functionality..........................5 Limit Switch Adjustments: Open and Close Cam Settings........................5 Limit Switch Functionality..................................5 Limit Switch Adjustment Using Manual Hand Chain..........................6 Low Voltage (Controls) and High Voltage (Power) Connections......................7 Main Power Supply Connection................................7 Electrical Drawings......................................8 1 Phase 120VAC Rapido Operator and BOARD 070..........................8...

  • Page 3: Installation Instructions

    Installation Instructions IMPORTANT INSTALLATION INSTRUCTIONS WARNING TO REDUCE THE RISK OF SEVERE INJURY OR DEATH TO PERSONS: 1. READ AND FOLLOW ALL INSTALLATION INSTRUCTIONS. 2. Install only on a properly operating and balanced door. A door that is operating improperly could cause severe injury. Have qualified service personnel make repairs to cables, spring assemblies and other hardware before installing the operator.

  • Page 4: General Specifications And Dimensions (Rsh)

    General Specifications and Dimensions (RSH) SUPPLY VOLTAGE..........115 V single-phase CONTROL VOLTAGE.........24 V class 2 transformer, 2 amp fuse type ACG MOTOR..............Continuous duty, 1 horsepower MOTOR VOLTAGE..........208 V three-phase OPERATOR OUTPUT SPEED......88 RPM NET WEIGHT (Operator only)......96 Lbs (44 Kg) STANDARD WIRING TYPE.......C2 (momentary contact to open/stop and constant-pressure-to-close) APPLICATION............Ultra high-end heavy duty v-belt drive for sectional doors DUTY..............>100 cycles/day Figure 1 - RSH (Rapido...

  • Page 5: Limit Switches & Limit Cams: Adjustment & Functionality

    Limit Switches & Limit Cams: Adjustment & Functionality WARNING To reduce risk of SEVERE INJURY or DEATH to persons: • Do not attempt to make limit switch adjustments unless power has been electrically disconnected. • The adjustment of the deceleration limit may affect the door's stop position. Limit Switch Adjustments: Open and Close Cam Settings This operator is equipped with the ACCU-CAM feature, for precise and quick one-handed limit setting adjustments.

  • Page 6: Limit Switch Adjustment Using Manual Hand Chain

    Limit Switch Adjustment Using Manual Hand Chain Table 1 - Limit Switch Adjustment Procedures Limit Switch Adjustment Procedures 1. Using the hoist, manually raise the door to a nearly opened position or desired open position. 2. Pull the cam-retaining bracket from the Open side, see Figure 2, and rotate the Open cam Open Limit manually until it activates the Open Limit Switch sufficiently so that a “click”...

  • Page 7: Low Voltage (Controls) And High Voltage (Power) Connections

    NOTICE • The installer MUST test for proper connection and functionality of the operator and its accessories before leaving the job site. • The installer should also perform a demonstration for the end-user. Low Voltage (Controls) and High Voltage (Power) Connections 1.

  • Page 8: Electrical Drawings

    Electrical Drawings 1 Phase 120V Rapido Operator and BOARD 070 Figure 4 - EDWG14070VFD03 For technical support, please call 1-800-361-2260 or visit www.manaras.com for more information...

  • Page 9: Phase 240Vac Rapido Operators And Board 070

    1 Phase 240V Rapido Operators and BOARD 070 Figure 5 - EDWG14070VFD04 For technical support, please call 1-800-361-2260 or visit www.manaras.com for more information...

  • Page 10: Warranty

    Warranty Manaras-Opera warrants its operators to be free from defects in material and workmanship under normal and proper use for a period of two years from date of invoice, unless otherwise stated. Mechanical, electrical and electronic accessories are warranted for one year from date of invoice, unless otherwise stated. Wearing parts such as clutch pads, v-belts, and brake bands are excluded from warranty.

  • Page 11: Notes

    Notes For technical support, please call 1-800-361-2260 or visit www.manaras.com for more information...
  • Page 12 Reg. T.M. of 9141-0720 Québec Inc. ADD1011 REV 8 – 2016/08/26...
