Available for the firmware version 3.0.5 and further.
Control elements.
The device has three control buttons for navigation: "UP", "DOWN", "PLAY/STOP".
"UP" and "DOWN" buttons navigate over the menu, shift images in single image mode. Besides,
keeping the "DOWN" button pressed in play mode puts the device into performance preparation mode.
Operating conditions.
The device can be in following conditions:
▪
Turned off;
▪
Being charged;
▪
Menu (sequences or single images);
▪
Battery level indication. Battery level should be considered as a relative one, for it depends on a
displayed image and a battery condition;
▪
Preparation for performance;
▪
Play in performance mode.
If the battery level is low, the device automatically shuts itself down to avoid deep discharge. Inactive,
the device shut itself down as well:
▪
in a menu or battery level indication – after 10 minutes;
▪
in timeline mode or single image mode – after 20 minutes;
▪
in performance preparation mode – after 1 hour
In performance mode the automatic shutdown doesn't occur.
Button operation.
Initially the device is turned off. To turn it on press and hold the "PLAY/STOP" button for 1 second. LEDs
successively light up from the bottom up. After the device is on, it goes into menu indication mode.
Manual to iPixel v3.
Advertisement
Summary of Contents for Ignis Pixel v3
- Page 1 Manual to iPixel v3. Available for the firmware version 3.0.5 and further. Control elements. The device has three control buttons for navigation: “UP”, “DOWN”, “PLAY/STOP”. “UP” and “DOWN” buttons navigate over the menu, shift images in single image mode. Besides, keeping the “DOWN”...
- Page 2 To turn it off press and hold “PLAY/STOP” button not less than for 1 second. LEDs successively go out from top to bottom. After the turned off device is plugged in to the charger or a PC, the battery indicator lights up. The red indicator shows the device is being charged, the green indicator shows the devise is charged.
- Page 3 Timeline mode is on the left figure, single image mode is on the right. The device has protection from accidental touching the buttons during a performance. It allows to protect your performance program from any faults. For this you should select a required mode (a sequence or a single image), get it into play, and hold the “DOWN' button.
- Page 4 Radio channel operation. The devices can synchronize their modes with each other, as well as be operated from remote controls. It allows to start and stop different devices in different modes simultaneously. Radio can be turned off, if synchronization of the device is not required. On default radio is on, total control mode is off, group work mode is on, slave mode is not active.
- Page 5 Total control, group work, and slave modes can be activated simultaneously, thereby giving space for flexible settings of the devices and having complete access to all devices of the group, not interfering into the work of other devices. A quick way to switch total control mode is provided for. Being in timeline mode or single image mode, press and hold both “UP”...
- Page 6 Sequences and pictures loading. Pictures are to be uploaded through the Ignis Pixel Utility. The device places up to 80 pictures and up to 10 timelines (sequences).
- Page 7 Settings of the device and status of the system. Through the system menu some parameters can be adjusted, as well as the state of the device can be checked out. You can adjust parameters of the radio, choose a group the device belongs to, set the brightness of the performance preparation mode indicator.
-
Page 8: Appendix 1. Description Of The Points Of System Menu
Appendix 1. Description of the points of system menu: If the indication is red – the parameter is not active, if green – it's active. System menu is arranged into basic menu and several submenus. Examples of the indication in the system menu. From left to right: ▪... - Page 9 Description of the points in the basic system menu. 1. Status and settings of the radio; 2. Choosing of a radio channel; 3. Choosing of a group; 4. Brightness of the performance preparation indicator; 5. System condition. Description of the points in the submenu. Submenu 1 –...
- Page 10 In this submenu a brightness of the indicator is to be set (as an option, the indicator can be turned off, if the position 1 is selected). For better obviousness a selected brightness of the indicator is displayed in the last (the top) LED.
