- Page 1 ™ ATDA-8000 Series Torque Data Analyzers User Guide...
-
Page 2: Table Of Contents
CONTENTS Unit Specifications ....................2 Safety Requirements ....................3 Screen and Button Diagrams Main Screen ..................... 4 Settings Screen ....................5 Report Screen/ Results Screen ................6 Basic Functions Description of Settings Screen Functions ............7-8 Operating Instructions Basic Navigation ....................9 Transducers Transducers and Torque Measurement Cable .......... -
Page 3: Safety Requirements
SAFETY REQUIREMENTS READ AND SAVE THESE INSTRUCTIONS WARNING! • When operating power tool • Ensure that owner/operator has read outdoors, use an extension cord all Safety Requirements and User suitable for outdoor use. Manuals prior to operating. • Keep out of reach of children. •... -
Page 4: Screen And Button Diagrams
SCREEN AND BUTTON DIAGRAM Figure 1: Main Screen 1. Power Button 2. Data Display/Touch Screen Mode / Units / Zero / Clear / Enter Buttons 4. Auto or Manual Buttons 5. Settings Button 6. Clear Test Run Button 7. Battery Indicator 8. -
Page 5: Settings Screen
Figure 2: Settings Screen 1. Sample Auto Clear Setting 7. Mode Setting 2. Results Auto Clear Setting 8. Sign Lock 3. Samples Per Set 9. Frequency Setting 4. Threshold Setting 10. Peak Blank % Setting 5. 6 Sigma % Adjustment 11. -
Page 6: Report Screen/ Results Screen
Figure 3: Results Screen Results Screen illustrates Target Torque Value, Test PASS/FAIL, High/Low/Average, Standard Deviation and Six Sigma percentage, Recorded samples and indicates Pass/Fail... -
Page 7: Basic Functions
BASIC FUNCTIONS The ATDA-8000 has three screens: Main Screen, Results Screen, and Settings Screen. Prior to using the instrument you should enter the SETTINGS SCREEN and program the operation of the instrument. Settings Screen/Menu The following are your screen selection choices in the SETTINGS SCREEN: Sample Auto Clear audit. - Page 8 enter the +/- % that the tool will be tested captured. With Sign Lock ON, the initial by. Press Save after entering values. direction is set as the default direction; a negative torque value indicates a reading Units taken in the counter-clockwise direction and a positive reading indicates a reading Various engineering units, cycle from taken in the clockwise direction.
-
Page 9: Operating Instructions
This unit is designed to operate semi readings in the set are stored, the unit will automatically. Once the settings are process the readings, providing the user complete, the user merely selects Done, with High, Low, Average, Standard Devia- the system will cycle to the Main Screen tion and percentage of Six Sigma. - Page 10 In the MAIN SCREEN you have four choices: Auto, Manual, Settings, and Clear Test Run. By selecting Manual the system will be put into a quick check mode and will not have the ability to save readings to the results screen.
-
Page 11: Transducers
AIMCO. The line of Auditor™ “Intelligent” and industry-standard transducers is manufactured with the proper connector-style for ease of use with the ATDA 8000. For assistance with this please contact your AIMCO Distributor or authorized AIMCO Sales Representative at 1-800-852-1368. -
Page 12: Rundown Kits
Auditor Stationary Transducers ™ Square Max Torque Weight W X H X D Drive Transducer in-lb/ft-lb AISI-200025 1.13 79 x 95 x 83 3.13 x 3.75 x 3.25 AISI-200100 11.3 1.13 79 x 95 x 83 3.13 x 3.75 x 3.25 AISI-200500 56.5 1.13... -
Page 13: Auditor™ Tool Manager
AUDITOR TOOL MANAGER / DATA MANAGER SOFTWARE Auditor™ Tool Manager Software Tool Manager Software is included with the purchase of ATDA 8000 Series torque testers and is imbedded into the unit. Create a database of tools and store test results with this easy-to-use software integrator to/from tester to PC. - Page 14 8000 series systems can accommodate. Hydraulic tools, measurement of pressure observed through a pressure transducer and more can be audited with these products. Specific needs and training for these higher level functions/capabilities require specialized hardware. Please consult your authorized AIMCO Auditor™ representative to receive further details.
-
Page 15: Auditor™ Data Manager
Auditor™ Data Manager Software Auditor Data Manager Software is included with the purchase ATDA-8000 series torque analyzers. This software is imbedded into the unit. The View Data tab allows you to look at the collected data. This data can be exported to Excel as a .csv file and displayed by Excel charts. - Page 16 AIMCO CORPORATE HEADQUARTERS AIMCO CORPORATION DE MEXICO SA DE CV 10000 SE Pine Street Ave. Cristobal Colon 14529 Portland, Oregon 97216 Chihuahua, Chihuahua. 31125 Phone: (503) 254–6600 Mexico Toll Free: 1-800-852-1368 Phone: (01-614) 380-1010 LIT-MAN873 Rev.07/2020 Printed in USA ©2020 AIMCO...
