Installation and maintenance instructions for
GRAF rainwater storage tank Carat XXL
16.000 - 122.000 liter
Order no.: 380000 - 380026
The points described in these in-
structions must be observed under
all circumstances. All warranty
rights are invalidated in the event
of non-observance. Separate in-
stallation instructions are enclosed
in the transportation packaging for
all additional articles purchased
from GRAF.
The tank must be checked for any
damage prior to insertion into the
trench under all circumstances.
Missing instructions can be down-
loaded on www.graf.info or can be
requested from GRAF.
mail@graf.info
www.graf.info
Table of contents
1.
1.1
1.2
2.
3.
4.
5.
5.1
5.2
5.3
5.4
6.
6.1
6.2
6.3
6.4
6.5
6.6
7.
11 / 50
12
12
12
13
14
16
16
17
17
18
18
19
19
19
19
19
20
20
20
